HP Compaq nc2400 Quickspecs

HP Compaq nc2400 Quickspecs

Hp compaq nc2400 notebook pc
Hide thumbs Also See for Compaq nc2400:

Advertisement

Quick Links

Download this manual See also: Troubleshooting Manual, Maintenance and Service Manual
QuickSpecs
Overview
1.
Volume Mute Button with LED
2.
Volume Scroll Zone with Up/Down LED Indicators
3.
Pointstick
4.
HP Fingerprint Sensor
5.
Speaker
6.
Left and Right Pointstick Buttons
7.
Hard Drive Activity LED
8.
Battery Charging LED
9.
Power/Standby LED
DA - 12439
North America — Version 18 — August 1, 2007
HP Compaq nc2400 Notebook PC
HP Compaq nc2400 Notebook PC
HP Compaq nc2400 Notebook PC
HP Compaq nc2400 Notebook PC
HP recommends Windows Vista
HP recommends Windows Vista
HP recommends Windows Vista
HP recommends Windows Vista
Business
Business
Business
Business
10. Wireless On/Off LED
11. Optical Drive (select models)
12. USB 2.0 Port (powered on select models)
13
RJ-11 (modem) Jack
14. Power Connector
15. Power Button with LED
16. HP Info Center Button with LED
17. Wireless On/Off Button with LED
18. Presentation Mode Button with LED
® ® ® ®
Page 1

Advertisement

loading

Related Manuals for HP Compaq nc2400

Summary of Contents for HP Compaq nc2400

  • Page 1 14. Power Connector Left and Right Pointstick Buttons 15. Power Button with LED Hard Drive Activity LED 16. HP Info Center Button with LED Battery Charging LED 17. Wireless On/Off Button with LED Power/Standby LED 18. Presentation Mode Button with LED DA - 12439 North America —...
  • Page 2 HP Mobile Data Protection System 3D Touch-sensitive controls Security features include integrated HP Fingerprint Sensor, Trusted Platform Module (TPM) Embedded Security Chip*, and optional integrated Smart Card Reader Protected by a three-year standard parts and labor warranty – certain restrictions and exclusions apply.

  • Page 3: Standard Features

    QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Standard Features Processors Processors Processors Processors Intel Core Duo Processor U2500* (1.20-GHz, 533-MHz FSB, 2-MB L2 cache) Intel Core Solo Processor U1400* (1.20-GHz, 533-MHz FSB, 2-MB L2 cache)
  • Page 4 Touch-sensitive Controls Touch-sensitive Controls Touch-sensitive Controls Touch-sensitive Controls Provide easy access to the following features: HP Info Center, Wireless On/Off, Presentation Mode, Volume Up/Down, and Volume Mute. Pointing Device Pointing Device Pointing Device...
  • Page 5 RJ-45 RJ-45 (NIC) USB 2.0 USB 2.0 USB 2.0 USB 2.0 Two (including one powered USB 2.0 port to support HP External MultiBay II on units without an integrated optical drive) Docking Connector Docking Connector Docking Connector Docking Connector IEEE 1394a Port...
  • Page 6 Manager Manager provide data and system file protection for HP business PCs to enable fast recovery if the system becomes corrupted or if important information is accidentally deleted. HP Backup and Recovery Manager can perform scheduled or manual backups of the entire drive or individual files and folders.
  • Page 7 Standard Features HP ProtectTools Security HP ProtectTools Security HP ProtectTools Security HP ProtectTools Security HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP Manager Manager Manager Manager ProtectTools Security Manager is an extensible client security console that delivers enhanced security capabilities through add-on software modules.
  • Page 8 MultiBay II Devices MultiBay II Devices MultiBay II Devices MultiBay II devices used in the optional HP External MultiBay II may be swapped with the system powered (optional) on (hot) under Microsoft Windows XP Professional, Windows XP Home, or Windows 2000 (except MultiBay II secondary hard drive).
  • Page 9 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Standard Features nc2400 nc2400 nc2400 nc2400 Processor Processor Processor Processor Intel Core Duo Processor U2500* (1.20-GHz, 533-MHz FSB, 2-MB L2...
  • Page 10 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Standard Features nc2400 nc2400 nc2400 nc2400 Processor Processor Processor Processor Intel Core Duo Processor U2500* (1.20-GHz, 533-MHz FSB, 2-MB L2...
  • Page 11 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Standard Features nc2400 nc2400 nc2400 nc2400 Processor Processor Processor Processor Intel Core Duo Processor U2500* (1.20-GHz, 533-MHz FSB, 2-MB L2...
  • Page 12 PA851A External MultiBay II 80-GB 5400 rpm MultiBay II Hard Drive PH357A Other Storage Other Storage Other Storage Other Storage HP USB Digital Drive + 256-MB Secure Digital Card DL702AA HP USB Diskette Drive DC361B Communications Communications Communications Communications Intel PRO/Wireless 3945ABG 802.11 a/b/g WLAN option kit...
  • Page 13 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Options Security Security Security Security HP PCMCIA Smart Card Reader DC350B HP/Kensington Cable Lock PC766A Input/Output Devices Input/Output Devices...
  • Page 14 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Memory Up to 2048-MB of 533-MHz DDR2 SDRAM One DIMM slot DIMM sizes supported: 512-MB, 1024- or 2048-MB Standard Memory...
  • Page 15 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Storage Removable Media Drive Support Removable Media Drive Support Removable Media Drive Support Removable Media Drive Support Quantity Supported...

  • Page 16: Technical Specifications

    QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Technical Specifications System Unit System Unit System Unit System Unit Dimensions Dimensions Dimensions Dimensions (HxWxD) 0.976 (at front) x 11.1 x 8.38 in (25 (at front) x 282 x 213 mm)
  • Page 17 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Technical Specifications HP 65W Smart AC HP 65W Smart AC HP 65W Smart AC HP 65W Smart AC Dimensions...
  • Page 18 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Technical Specifications 55Wh Primary 6-Cell 55Wh Primary 6-Cell 55Wh Primary 6-Cell 55Wh Primary 6-Cell Dimensions Dimensions Dimensions Dimensions (H x W x L) 0.8 x 2.3 x 8.1 in (2.1 x 5.9 x 20.6 cm)
  • Page 19 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Technical Specifications 12.1-Inch Color TFT 12.1-Inch Color TFT 12.1-Inch Color TFT 12.1-Inch Color TFT Active Area Active Area Active Area Active Area (W x H) 10.3 x 6.4 in (26.1 x 16.3 cm)
  • Page 20 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Technical Specifications 60-GB 4200 rpm 60-GB 4200 rpm 60-GB 4200 rpm 60-GB 4200 rpm Drive Weight Drive Weight Drive Weight Drive Weight 0.13 lb (59 g)
  • Page 21 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Technical Specifications DVD/CD-RW Combo DVD/CD-RW Combo DVD/CD-RW Combo DVD/CD-RW Combo Dimensions Dimensions Dimensions Dimensions 0.37 x 5.51 x 5.04 in (0.95 x 14.0 x 12.8 cm)
  • Page 22 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Technical Specifications Max Media Capacity Max Media Capacity 8.5 GB Max Media Capacity Max Media Capacity (write) Transport Transport...
  • Page 23 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Technical Specifications Integrated Broadcom Integrated Broadcom Integrated Broadcom Integrated Broadcom Ethernet Features Ethernet Features Ethernet Features Ethernet Features 10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
  • Page 24 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Technical Specifications Synchronous primary channel data signaling rates: Synchronous primary channel data signaling rates: Synchronous primary channel data signaling rates:...
  • Page 25 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Technical Specifications Output Power Output Power (for CKK) 17.5 dBm Output Power Output Power Output Power Output Power Output Power Output Power (for OFDM;...
  • Page 26 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Technical Specifications Data Rates Data Rates 802.11b: 1, 2, 5.5, 11 Mbps Data Rates Data Rates 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps...
  • Page 27 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Technical Specifications 5 5 5 5 Configuration Utility Configuration Utility Configuration Utility Configuration Utility Choice of Configuration Utility: Microsoft Windows XP Wireless Network Connection Manager...
  • Page 28 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Technical Specifications Antenna type Antenna type High efficiency dual band antenna with spatial diversity, mounted in the Antenna type...
  • Page 29 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Technical Specifications Range Range Up 33 ft (10 m) Range Range Electrical Interface Electrical Interface Electrical Interface Electrical Interface USB 2.0 compliant...
  • Page 30 QuickSpecs HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC HP Compaq nc2400 Notebook PC Technical Specifications Environmental Data Environmental Data Environmental Data Environmental Data Eco-Label Certifications Eco-Label Certifications Eco-Label Certifications Eco-Label Certifications This product has received or is in the process of being certified to the...
  • Page 31 This product is in compliance with the Restrictions of Hazardous Substances Additional Information Additional Information (RoHS) directive – 2002/95/EC. This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE) Directive – 2002/96/EC. Keyboard complies with ISO standard: ISO 9995, EN 29241-4, and ISO/IEC 15412 Input devices of this product comply with ISO 9241, part 9.
  • Page 32 HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner. Hewlett-Packard Hewlett-Packard Hewlett-Packard...
  • Page 33 HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
