Installation Instructions:
8,000-12,000 BTU TTW
Do This First
(for existing sleeve)
Note that the air conditioner dimensions are: 24"wide,
14½" high, and 18½" deep (without front). Install Air
Conditioner according to these installation instructions
to achieve the best performance. Save these installation
instructions for future reference.
CAUTION: When installation is complete, replacement
unit MUST have a rearward
1/4" to 5/16"
slope as shown.
SleeveWall _ _1_
UNIT
LEVEL
Items in Kit
You may not need all parts in the kit. Discard unused
parts.
Tapered Spacer Blocks
Centering/Support Blocks
Plastic Divider
Stuffer Seal
Seal
Seal
Seal
Seal
Seal
Trim Frame (side legs)
Trim Frame (top & bottom legs)
Ground Wire (green)
Nut for grounding screw
Grounding Screw
Grille (plastic)
Nuts (plastic)
Screw w/washer
17" Long
41_"x 3_"x 1_"
1/8" x 4½"x 14½"
1 "x 1_"x 84"
l_"x 1½"x 26½"
l_"x l_"x 14"
1_"x 3/8" x 26½"
l_"x 3/8"x 14"
l"x 3/4"x 14"
Qty.
2
2
1
1
2
2
2
2
1
2
2
1
1
1
1
4
4
2. Remove old Air Conditioner from wall sleeve and
prepare wall sleeve as follows:
-- Clean interior (do not disturb seals).
-- Wall sleeve must be securely fastened in wall before
installing Air Conditioner. Drive more nails or screws
through sleeve, into wall, if needed.
-- Repair paint if needed.
3. If not existing, drill a 3/16"clearance hole for ground-
ing screw through left side of wall sleeve, in a clear area
about 3 inches maximum (to suit) back from front edge
of sleeve as shown below. Next attach ground wire
inside sleeve, using grounding screw and nut. Pull loose
end of ground wire out front of sleeve, and temporarily
bend it down and around lower edge of sleeve.
Wall sleeve to unit 3/16"
Hole
sleeve grounding
II
How to Install
1. Identify the wall-sleeve brand for your installation,
from the chart below.
Brand
White-Westinghouse
Frigidaire
Carrier (52F Series)
General Electric/
Hotpoint
Whirlpool
Wall Sleeve Dimensions
(inches)
Width Heigbtht
25½ 15¼ 17_
16,
or 22
26 15%
25_ 16½
Fedders/Emerson 27 16%
Sears/Kenmore 25_A 167A
Emerson/Fedders 26_A 15%
Carrier (51S Series) 25_A 167A
Friedrich 27 16%
167A
171A
or 23
16%
or 193/4
18%
15
18%
16%
NOTE: All wall sleeves used to mount the newAir
Conditioner must be in sound structural condition and
have a rear grille that securely attaches to sleeve, or
rear flange that serves as a stop for the Air Conditioner.
4. Prepare the wall sleeve for installation of the new unit
per the following Brand instructions.
#1 Emerson 15" Deep
#2 Fedders 19_A"Deep
#3 Fedders or Friedrich 16_A"Deep
#4 General ElectriciHotpoint 167A"Deep
#5 Sears or Carrier (51S Series) 18%" Deep
#6 Whirlpool 17_,4" Deep
#7 Whirlpool 23" Deep
#8 White-Westinghouse/Frigidaire/ 16"+ 17½"Deep
Carrier (52F Series)
#9 White-Westinghouse/Frigidaire 22" Deep
5. Install new unit into wall sleeve.
6. To attach ground wire to the new unit, remove the
screw from the left side front.
7. Assemble and install the
Trim Frame (see instruction).
P/N 66121627
