INTRODUCTION

Thank you for purchasing this American DJ® Product. The DP-1219™ has been tested and is ready to use. There is no assembly
required. The DP-1219™ is a high-performance 12 channel dimmer console. This unit offers a wide variety of features including light dim-
ming, music control, and 16 preset built-in programs. To ensure that your DP-1219™ give you optimum performance, be sure to read this
manual thoroughly before operating this unit.

FRONT PANEL:

3
4
1. Power switch
2. Channel indicator
3. Single channel dimmer control - Set it to "0" position, dimmer level is 0 percent; Set it to "10" position,
dimmer level is 100 percent.
4. Flash key - Channel output is 100 percent dimmer level when pressed, with the exception of
being in STAND-BY mode.
5. Mode selector - There are 6 modes in this unit, indicated by operating mode indicator (20). When the power
is on, this unit is in hold dimmer. Each press changes the operating modes in order of: Hold Dimmer,
Hold Sound, Program Sound, Program Speed, Auto Speed, Auto Sound, Hold Dimmer.
6. Program Selector - This switch is effective only when this unit is in Program Sound or Program
Speed mode, indicated by internal operating program indicator (7).
7. Internal operating program indicator (1 - 16)
8. Stand-by indicator - the indicator lights when receiving directive signals, without pack, however,
full on is effective.
9. Stand-by control key - Press to activate stand-by.
10. Full-on control key - in any mode, pressing the key allows all outputs to be fully on, including stand-by
11. Speed x10 control key - Pressing the key allows the speed faster 10 times.
12. Master dimmer indicator
®
12 Channel Dimmer Panel
©American DJ® Los Angeles, CA 90058
User Instructions
2 20 19 18 17 12
5 6 8
9
7
13 14
1
15
16
10 11
mode.
