American DJ DP-20A User Instructions

American DJ

MAIN FEATURES:

• 4 Channel Dimmer Pack
• 600 watts per channel
• 5 amp per channel
(15A max)
• 2 plugs per channel
• Sudden Current Protection
• Warm Up Function
• Suitable for resistive load
and inductive load
• Dimming Sensitivity Knob
• Power outlets very easy to
set up and operate
• Designed to mount on truss
or stands
• 8" x 6.5" x 4.5"
• 7 lbs.
CONTROLS & COMPONENTS
(FRONT)
• 8 AC PLUGS
• 4 FUSES
(BACK)
• AC INPUT 120V/60HZ
• 8 PIN DIN CABLE OUTPUT-
connect to another DP-20A
• 8 PIN DIN CABLE INPUT-
connected to DP-8A or DP-12
(TOP)
• 4 LED LIGHTS- Indicates which
channels are on
(RIGHT SIDE)
• DIMMING SENSITIVITY KNOB
White plastic wheel inside right
side vents. Adjust with screw
driver for desired sensitivity.
User Instructions
®
DP-20A
zero-crossing circuitry, and A/C plugs and sockets. It
uses the same 8 pin din connector as the DP-8A™, DP-
12™, and DP-20™. The DP-20A™can be mounted on
truss or pipe with a C-Clamp. Each channel is fused with
a 5A fuse.
FOR SERVICE: Contact your local
DC V+20V OUTPUT
NC
1
2
3
G
©American DJ® Los Angeles, CA 90058
THANK YOU FOR PURCHASING THIS
AMERICAN DJ™ PRODUCT
Now with
design and 2 plugs per
channel, the DP-20A™ has
all the same features of the
DP-20™ by American
DJ™. The DP-20A™ is a
0-10V analog, 4 Channel,
15A max, 600W per chan-
nel dimming power pack.
Each channel includes
warm-up feature, take out,
NC
DP-8A
OR
4
DP-12
a new case
Dealer.
American DJ®
Sample Set- up
Channels 1-4
DP-20A
Channels 5-8
DP-20A
Channels 1-4
DP-20A
DP-20A
9-12
DP-20A
5-8
