- Page 1 OWNERS MANUAL...
- Page 2 Dear Customer, Thank you for your purchase of a amplifier from Premier Builders Guild. As a discerning guitarist, you know the road to great tone begins with great components. Our Classic Design, carefully selected parts and hand-built approach combine to make an extremely versatile instrument. Please take the time to read this manual.
-
Page 3: Front Panel Functions
Front Panel Functions 1. Input Jack- High impedance input to the amplifier. Plug in your instrument here. 2. Treble Control- Adjusts the high frequency response. In the full counter-clockwise position, high frequencies are bypassed to ground. In the full clockwise position, high frequencies are allowed to pass to the next gain stage. -
Page 4: Rear Panel Functions
12. Reverb Send- The reverb drive control determines the amount of signal applied to the reverb tank. Low settings will create a very open, small room reverb effect with a short decay time. Advancing the control clockwise increases the signal applied to the driver and a very saturated effect with a sharp attack and a long decay can be obtained. -
Page 5: Fuse Chart
7. Effects Return- Use this jack to connect the output of your effects to the amplifier. 8. Traditional / Modern- This switch affects the internal negative feedback circuit located in the preamp section. The effect is subtle and becomes more apparent as you familiarize yourself with various settings. “The Modern settings is our standard Two-rock negative feedback circuit, it is most effective when using high output humbucking or active pickups. - Page 6 (Tube Complement) V1- Preamp 12AX7 V2- Reverb return, Mixing Stage 12AX7 V3- Reverb drive 12AT7 V4- Tremolo 12AX7 V5- Phase inverter 12AX7 V6, V7- SED Winged “C” 6L6, Output V8, V9- 5AR4 Tube rectifier Each fine production tube is tested and matched to our exacting specifications. External bias adjustment and test points are located on the chassis near the output tube sockets.
- Page 7 WARNING! No user serviceable parts inside! Refer to qualified service person only. LINE CORD- For your safety, connect to grounded A/C receptacle only. amplifiers are brought to you by Premier Builders Guild. We know your new amplifier will provide many hours of enjoyment and inspiration in the years to come.
- Page 8 DO NOT expose to rain or any other moisture. DO NOT use cleaning solvents. Wipe exterior with a clean, dry cloth only. Refer servicing to a qualified service technician. This is a product of Premier Builders Guild 619 MARTIN AVENUE, SUITE 6 ROHNERT PARK, CA 94928 707-584-8663 www.two-rock.com...
