Using Virtual Media in a two-level cascade
configuration
For Virtual Media to work properly in a two-level cascade configuration, you must have:
•
A console switch with Virtual Media as the primary console switch
•
A console switch with Virtual Media as the secondary console switch
•
An interface adapter with Virtual Media connecting each server to the console switch
For more information on cascading, see Cascading console switches (on page 25).
Item
1
2
3
4
5
6
7
Description
Local user
USB media device
Console switch (HP Server Console Switch with Virtual
Media or HP IP Console Switch with Virtual Media)
Secondary console switch (HP Server Console Switch with
Virtual Media)
USB 2.0 interface adapter with Virtual Media
PS2 interface adapter with Virtual Media
Server
Using Virtual Media 63
