MODEL : SSF-1100/2200/3300
DIGITAL VOICE RECORDER
User Guide Manual
Thank you for purchasing PORTABLE DIGITAL AUDIO PLAYER from DIASONIC TECHNOLOGY Co.
Please carefully read the Instruction manual for safe use of the product. We recommend that you to
keep this instruction manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SSF-2200 and is the answer not in the manual?

Questions and answers

Related Manuals for JNC SSF-2200

Summary of Contents for JNC SSF-2200

  • Page 1 MODEL : SSF-1100/2200/3300 DIGITAL VOICE RECORDER User Guide Manual Thank you for purchasing PORTABLE DIGITAL AUDIO PLAYER from DIASONIC TECHNOLOGY Co. Please carefully read the Instruction manual for safe use of the product. We recommend that you to keep this instruction manual for future reference.

  • Page 2: Information To The User

    Any unauthorized reproduction of recorded files for any other purposes than personal use is strictly prohibited by the relevant laws and regulations. Note This instruction manual is required for the effective use of JNC MP3 Player. Pay special attention not to lose the manual as it is not provided separately from the unit.

  • Page 3: Safety Precautions

    Safety Precautions Warning Keep the batteries out of reach of the children. If a child swallowed a battery, please consult a doctor immediately. Do not have the battery shorted, disassembled, heated or put in fire. This may cause leakage, heat, explosion or fire.

  • Page 4: Warranty

    Preface Safety Precautions Functions and Features Parts and Components Basic Function Buttons FM Radio Mode Menu Main Menu Record in Recording Mode Connecting External Device Installation of Windows 98SE Driver Uninstallation of Windows 98SE Driver Managing Folders and Files Deleting Files Downloading Files Formatting Files Firmware Upgrade...

  • Page 5: Functions And Features

    Functions and Features DIGITAL VOICE RECORDER UP TO 16,960 MIN RECORDING TIME(SP MODE AND 1GB) 8FOLDERS TO ORGANIZE FILES STORE UP TO 128 FILES FOR EACH FOLDER CONTINUE FOLDER FUNCTION: AUTOMATICALLY MOVE TO NEXT FOLDER IF INDEX IS FULL. VARIABLE RECORDING MODE (SHQ/HQ/SP IN MP3 FORMAT AND USER MODE IN MPEG1 LAYER3) MIC SESITIVITY ADJUSTABLE IN RECORDING.
  • Page 6 ID3 TAG SUPPORT(ARTIST/TITLE) SCROLL SPEED CONTROLLING MULTI LANGUAGE SUPPORT 5EQ (NORMAL/CLASSIC/LIVE/POP/ROCK) SYNC FUNCTION: AUTOMATICALLY RECOGNIZE THE END AND BEGINNING OF THE MUSIC FROM EXTERNAL AUDIO DEVICE IN RECODING THRU CONNECTING AUDIO CABLE AND RECORD. USER EASILY UPGRADES NEW FIRMWARE PROVIDED BY MAKER EASY-TO-USE BUTTON FOR QUICK NAVIGATION THROUGH FOLDERS AND OPTIONS SET UP THE ALARM TO PLAY AUTOMATICALLY AS A REMINDER TO...
  • Page 7 USB JACK NECK STRAP HOLDER EARPHONE MIC & LINE-IN JACK INTERNAL MIC REC/PAUSE DC JACK STOP ERASE HOLD MENU VOLUME + VOLUME -...
  • Page 8 FOLDER MODE INDEX INFORMATION FILE PLAY/STOP/PAUSE INFORMATION /REC/REW/FF SYNC/BIT RATE REPEAT /EQ/SPEED TIME HOLD TIMER ON/OFF ALARM ON/OFF ARS ON/OFF 3D SOUND ON/OFF REPEAT INTRODUCTION PLAY BACK L/R SPECTRUM BATTERY STATUS...
  • Page 9 1) PUT BATTERIES (LR03 TYPE) 2) BATTERY POWER STATUS INDICATOR FULL CHARGED SOME POWER CUSTOMED THINKING OF CHANGING BATTERY CHANGE BATTERY CHECK THE POLARITIES OF THE BATTERIES IF LCD DISPLAY DOESN’T TURN ON AFTER INSERTING NEW BATTERIES.
  • Page 10 3) TYPICAL BATTERY LIFE TIME (VOICE MODE) BATTERY TYPE RECORDING PLAYBACK VIA SPEAKER PLAYBACK VIA EARPHONE (VOLUME:MEDIUM) (VOLUME:MEDIUM) (VOLUME:MEDIUM) 2 AAA LR03 APPROX. 13HRS APPROX. 13HRS APPROX. 23HRS BATTERY LIFE MAY BE DIFFERENT FROM ABOVE MENTIONED TIME ACCORDING TO BATTERY BRAND & CONDITION. DO NOT USE DIFFERENT TYPE AND BRAND BATTERY TOGETHER.

  • Page 11: Reserved Recording

    TO TURN ON, HOLD THE KEY FOR 2-3 SECONDS. TO TURN OFF, HOLD THE STOP KEY AGAIN WITH LONG KEY (over 3secs). IF USB CABLE IS CONNECTED, AUTOMATICALLY POWER IS ON. IF YOU PUT THE BATTERY TO DDR-5000 FOR THE FIRST TIME, “A”...
  • Page 12 BY PRESSING MENU BUTTON FOR 1-2 SECONDS, MODE MENU WILL DISPLAY. FOR MOVING TO THE MODE WANTED, PRESS “REW/FF” BUTTON. SELECT THE MODE BY PRESSING “PLAY/PAUSE” BUTTON. VOICE MUSIC L-IN ENC FM ENC B-MARK FOLDER THIS IS FOR PLAYING THE FIRST FEW SECONDS OF EVERY TRACK FOR QUICK REVIEW OF VOICE FILES OR MUSIC.
  • Page 13 A CURRENT SPEED DISPLAYS ON THE LCD BY PRESSING “REC/PAUSE” BUTTON FOR 2-3SECONDS DURING PLAYBACK. TO SELECT DESIRED SPEED (STANDARD(100%), FAST(120%) OR SLOW(80%)) BY PRESSING “REC/PAUSE” BUTTON FOR 2-3SECONDS DURING PLAYBACK. IF STOP, SPEED IS BACK TO STANDARD. WHEN FILE PLAYS BACK, REPEAT MODE CHANGES BY PRESSING “ERASE”...
  • Page 14 Buttons...
  • Page 16 IF THERE IS NO KEY OPERATION WITHIN 5SECS, SET UP THE STATION WILL BE RELEASED. EARPHONE WORK AS AN EXTERNAL ANTENNA FOR INCREASING RECEPTION. STRETCH IT OUT.
  • Page 18 PLAYBACK...
  • Page 19 FM Radio TURN ON THE SET AND SELECT FM IN THE MODE MENU. FOR THE AUTOMATIC TUNING, PRESS AND HOLD FORWARD OR REWIND BUTTON FOR 2SECONDS. THE TUNNER AUTOMATICALLY SCAN AND STOP ON THE NEXT STATION WITH A STRONG SIGNAL. IN AREA WITH WEAK RECEPTION, PRESS THE FAST FORWARD OR REWIND BUTTON TO FIND A CLEAR STATION.
  • Page 20 IF YOU WOULD LIKE TO RECORD THE PRESENT LISTENING TO STATION, PRESS “REC” BUTTON. RECORDED FILE STORED “FM ENC” FOLDER WITH FILE NAME “FM001_048KBPS_040101_010101.MP3” AND THE FILE NAME IS SEQUENTLY NAMED IN ORDER. NOISE MAY OCCUR WHEN RECORDING FM IN WEAK COVERAGE OR INSIDE OF THE BUILDING.

  • Page 21: Mode Menu

    Mode Menu YOU CAN GO TO “MODE MENU” BY PRESSING “MENU” BUTTON FOR 1 SECOND. MODE MENU IS CONSIST OF BELOW MODE. TO MOVE TO ANOTHER MODE, USE “REW/FF” BUTTON. B-MARK VOICE MUSIC L-IN ENC FM ENC FOLDER PLAY BACK VOICE FILE RECORDED IN VA001_ 008KBPS_040101_010101.MP3 TYPE.
  • Page 22 PLAY THE FILE IN FM ENC FOLDER. FILE IS STAMPED IN FM001_128KBPS_040101_010101.MP3. IN SEQUENCE. 256FILES CAN BE RECORDED AS MUCH AS MEMORY IS AVAILABLE. RECEVING RADIO STATION. * B-MARK STORE FAVOITE SONGS.(2OFILES ARE AVAILABLE.) BOOKMARK IS SET BY PRESSING STOP BUTTON ON THE MUSIC, L-IN ENC, FM_ENC MODE.
  • Page 23 Main Menu...
  • Page 24 “REW/FF” FOR YES/NO AND “PLAY/PAUSE” FOR SELECTION.
  • Page 25 “REW/FF” FOR YES/NO AND “PLAY/PAUSE” FOR SELECTION.

  • Page 31: Record In Recording Mode

    Record in Recording Mode THE SET HAS 4 WAYS TO RECORD AS BELOW. 1) RECORDING THRU INTERNAL MIC: JUST PRESS “REC” BUTTON. 2) RECORDING THRU EXTERNAL MIC: PLUG EXTERNAL MIC INTO LINE IN JACK. SELECT EXTERNAL MIC ON SYSTEM/INPUT SELECTOR. PRESS “REC”...

  • Page 32: Connecting External Device

    Connecting External Device 1) RECORDING EXTERNAL DEVICE TO DDR-5000 CONNECT THE PROVIDED AUDIO CABLE TO LINE IN JACK ON THE SET. 2) RECORDING DDR-5000 TO EXTERNAL DEVICE CONNECT THE PROVIDED AUDIO CABLE TO EARPHONE JACK ON THE SET AND MICROPHONE OR LINE IN ON THE EXTERNAL DEVICE.

  • Page 34: Installation Of Windows 98Se Driver

    Installation Of Windows 98SE Driver IT SUPPORTS USB MASS STORAGE AND IT CAN BE USED AS HARD DRIVE. IT CAN BE CONNECTED TO PC DIRECTLY WITHOUT ANY APPLICATION BY PLUG & PLAY METHOD ON WINDOWS ME, 2000, XP EXCEPT FOR WINDOWS 98SE. HOW TO INSTALL DRIVER (1) In case of Windows ME, 2000, XP WHEN CONNECTING DEVICE TO PC BY USB PORT, “NEW HARDWARE DETECTED”...
  • Page 35 (2) In case of Windows 98 SE 1 INSERT THE PROVIDED CD & IT WILL INDICATE HOW TO INSTALL. DOUBLE CLICK “DVR-WIN98SE.EXE” 3 CLICK “INSTALL 98UMS DRIVER” AND AUTOMATICALLY INSTALL.
  • Page 36 4 WHEN IT IS COMPLETED, BELOW POP-UP WILL APPEAR. CLICK “YES” CLICK FOR REBOOTING THE COMPUTER. AFTER REBOOTING, CONNECT THE SET & PC THRU USB CABLE. BELOW WINDOW WILL APPEAR. 7 EVERYTHING IS SUCCEED, IT CAN BE APPEARED AT SYSTEM PROPERTIES.
  • Page 37 * REMOVING USB MASS STORAGE SAFELY. (1) Windows ME, 2000, XP WHEN THE SET REMOVE FROM CONNECTION, IT SHOULD DO IT THRU PROPER PROCEDURE AS BELOW. IF NOT, IT MIGHT CAUSE SERIOUS PROBLEM IN DATA. 1 CLOSE THE FILE TO OPEN. LEFT CLICK “...

  • Page 38: Uninstallation Of Windows 98Se Driver

    Uninstallation of Windows 98SE Driver THE PROVIDED CD CONTAINS UNINSTALLING PROGRAM AUTOMATICALLY. 1 INSERT THE PROVIDED CD. DOUBLE CLICK “DVR-WIN98SE.EXE” 3 CLICK “REMOVE DRIVER” 4 WHEN IT COMPLETE, BELOW WILL APPEAR AND CLICK “OK”.

  • Page 39: Managing Folders And Files

    Managing Folders and Files (2) ALL FILE FORMATS CAN BE STORED AND REMOVED.

  • Page 40: Line In Mode

    (3) AUDIO MODE IS NOT DEFAULTED LIKE VOICE, L-IN_ENC, FM_ENC. CREAT IT ON THE PC AND CAN CHECK IT AT FOLDER & MUSIC MODE. (4) LINE IN MODE...

  • Page 42: Deleting Files

    Deleting Files...

  • Page 43: Downloading Files

    Downloading Files • Don’t detach USB cable under the condition file delete or file transfer. It might cause data loss or could break down.

  • Page 44: Formatting Files

    Formatting Files...

  • Page 46: Firmware Upgrade

    Firmware Upgrade • Upgrade Completed...
