- Page 1 LCD TELEVISION OWNER`S MANUAL MODELS: LR42T1 LR47T1 Please READ this manual carefully before operating your TV, and retain it for future reference.
- Page 2 " " Dear Haier product owner: Thank you for your confidence in Haier. You`ve selected one of the best-built, best-backed products available today. We`ll do everything in our power to keep you happy with your purchase for many years to come.
-
Page 3: Table Of Contents
BEFORE OPERATING Warning...1 Important Safety Instructions...2 Buttons and interface location... 4 Remote controller ...6 keys of Remote control ...7 External equipment connections...8 BASIC OPERATING Switching on/off the TV set...13 Choose the Menu language... 13 Choose the Input Source ... 13 Searching Channel...14 Watching TV Program...17 Picture Control Functions... -
Page 4: Warning
Explanation for signs Dear Users: Above all, please accept our sincere appreciation for your choice of Haier TV; and for the sake of making you easier to read instructions and use TV, the company will explain in detail the signs appeared in the instructions as follows:... - Page 5 Important Safety Instructions Attentions Phenomena Dark spots on The TV is manufactured with technology of extra high precision, the screen however there possibly is pixel loss or light spot on the screen sometimes. This is not a problem. Do not make the still pictures display too long because it probably bring permanent burn-in on the TV screen (still pictures include signs, video games, computer figures, electronic texts and the pictures displaying in the mode of 4: 3).
- Page 6 Important The product should be tightly fixed to avoid drop damages and even fire. Do not locate the product close to water or oil, which may cause fire hazards. Do not use damaged or worn electric plugs and keep electric cord away from heat sources to avoid electric shocks or fire hazards.
- Page 7 Important Don't use or store inflammable materials near the product to avoid explosion or fire hazards. The antenna of the product should be away from electric cable to avoid electric shocks. Always make sure that the televisionis well plugged as poor electric connection might cause fire.
-
Page 8: Buttons And Interface Location
Buttons and interface location - This is a simplified representation of front panel. - Here shown may be somewhat different from your TV. Front panel Control HDMI jack Right audio Left audio Video USB jack 1. TV/AV button 2. MENU button 3. - Page 9 Buttons and interface location Rear panel Control HDMI Input Connnect a signal to HDMI/DVI PC Input Connect the monitor output connector from a PC to the jack Component Input Connect a component video/audiodevice to these jacks. Input Connect audio/video out from an audio/video device to these jacks. S-Video Input Connect S-Video out from a S-Video device to these jacks.
-
Page 10: Remote Controller
Remote controller Battery loading 1.Slide open the cover of the battery compartment on the back of the remote controller. 2.Load two 7# (AAA)alkaline batteries in the compartment. (plus and minus poles to respective mark) 3.Replace the cover of the battery compartment. Precautions As strong light may interfere the signals, change your position to... -
Page 11: Keys Of Remote Control
Keys of remote control - The remote controller cannot be operated unless the batteries are properly loaded. - When using the remote control, aim it at the remote control sensor on the TV. Function introduction Power Off/Standby any other programmed equipment off. -
Page 12: External Equipment Connections
External Equipment Connections - Antenna or Cable Service without a Cable Box Connections - For optimum picture quality, adjust antenna direction if needed. outdoor antenna (not supply) Antenna input 75 standard coaxial type twin-lead cable Antenna adapter (not supply) Note * It is recommended that you'd better use 75 disturbance caused by airwave. -
Page 13: Choose Your Connection
External Equipment Connections NOTE: All cables shown are not included with the TV. Choose Your Connection There are several ways to connect your television, depending on the components you want to connect and the quality of the signal you want to achieve. The following are examples of some ways to connect your TV. -
Page 14: Dvd Setup
External Equipment Connections DVD Setup How to connect . Connect the DVD video outputs (Y, Pb/Cb, Pr/Cr) to the COMPONENT (Y, Pb/Cb, Pr/Cr) input jacks on the TV and connect the DVD audio outputs to the AUDIO jacks on the TV, as shown in the figure. -
Page 15: Pc Setup
External Equipment Connections PC Setup How to connect Use the TV`s PC IN port for video connections. Then, make the corresponding audio connection. If using a sound card, adjust the PC sound as required. How to use 1. Turn on the PC and the TV. 2. -
Page 16: Connecting Headphones
External Equipment Connections Connecting Headphones You can connect a set of headphones to your set if you wish to watch a TV programme without disturbing the other people in the room. Power source AC Outlet Wider Hole and Blade Polarized AC Cord Plug Plug a set of headphones into the 3.5mm mini-jack socket on the rear panel of the set. -
Page 17: Switching On/Off The Tv Set
Switching ON/OFF the TV set In the manual, the OSD (on screen display) may be different from your TV`s because it is just an example to help you with the TV operation. Switching ON/OFF the TV set first, connect power cord correctly ress POWER button on the remote control again. -
Page 18: Searching Channel
Searching Channel This TV set has three methods to set channels, which are respectively full automatic, manual search fine tune. In this section, how to use the remote control to set channel is explained. You can also use buttons on the TV set to set channel. Automatic search Press MENU button and then use VOL+/- button to select "... -
Page 19: Channel Edit
Searching Channel Channel Edit Press MENU button and then use VOL+/- button to select Tuner menu. " " Press CH+/- button to select "Channel Edit" item. Press VOL+ to enter the submenu. Press CH+/- button to select the item to press VOL+/- button to adjust the item to select. -
Page 20: Watching Tv Program
Watching TV Program You can watch TV program in a presetting channel. To select the TV mode Before watching TV program, you may ensure your TV in TV mode. Press TV/AV button to select TV mode. How to select the desired program Using "Program number"... -
Page 21: Picture Control Functions
Picture Control Functions The TV menu gives you can an overviews of the menus you can select. Note: Depending on the input signal, one or more menu items may not be selectable. How to select picture modes You can quickly select the desired picture mode from three preset modes and one customized mode. -
Page 22: Picture Control Functions
Picture Control Functions Palette(Color Adjustment Panel for Eye-pleasing) Press CH +/- button to select Palette for Eye-pleasing, press VOL +/- button to enter the submenu, and press CH +/- button to select "User", "Standard", "6500K", "7500K", "8500K" and "9300K" six color adjustment modes according to your personal preference for color. -
Page 23: Sound Control Functions
Sound Control Functions How to choose sound mode You can quickly select the desired sound mode from four preset modes and one customized mode. Press the SSM button to select the desired sound quality. Five kinds of sound modes (i.e., "Standard","User", "Theater" and "Music") can be selected in turn. User A spare setting that can be adjusted to personal tastes;... - Page 24 Sound Control Functions Eliminate Sound When you need to pay attention to surrounded sounds, or there is a telephone calling you or there are some guests visiting you, the sound elimination (mute) function is very convenient. Press the MUTE button on the remote control and "Mute" type face will display on the lower part of the screen.
-
Page 25: Timer Functions
Timer Functions Current time setting First, should examine that this current time and your location is consistent or not, If inconformity , you may carry out time in REC setup On/Off Time Using on/off Time function, the TV set can automatically turn on to a preset program or shut down in a preset time. -
Page 26: Function Menu
Function Menu The PIP function is only available to LR47T1 product; Function Menu Setting Press MENU button and then use VOL+/- button to select Function menu. Press CH+/- button to select the item to be adjusted, then press VOL+/- button to adjust the desired value. -
Page 27: Function Menu
Function Menu AAA Picture Optimize Press MENU button and then use VOL+/- button to select Function menu . Press CH+/- button to select AAA Picture Optimize, and then press the VOL+ button to enter the submenu. Press CH+/- button to select the item to be adjusted, then press VOL+/- button to adjust the desired value. -
Page 28: Adjust Menu
Adjust Menu In PC input mode , H-Position and V-Position can be used to adjust the picture position. When PC input mode is set Press MENU button and then use VOL+/- button to select Adjust menu . Press the VOL+ button and then use CH+/- button to select the item to be adjusted, then press the VOL+/- button to adjust the desired value. - Page 29 Program Recording Pre-arrangement of Program Recording 1.The function is designed to record the video TV program. 2.When using the function of program recording, please first connect the external mobile device to the USB port and set the recording function; and if you do not set the function, the system would use the default setting.
- Page 30 Program Recording Start Time: the time to start program recording. Stop Time: the time to stop program recording. Source: the program source of program recording. Channel Number: the Channel Number for TV program recording. On/Off Program Recording: if the option is set On , the TV would be in black screen state (no sound and no picture) in the process of program recording.
- Page 31 Program Recording Time Retrieving Function: 1. Time retrieving function is designed to play back the program which has been played on the TV, to perform the operations of Fast Forward, Skip Backward and Pause for pictures of time retrieving. 2. Please set the time retrieving function before you do it; for more information, see the Set Option under the USB channel.
-
Page 32: Lock Setup
Lock Setup The television has the function of security default lock. Password needs to be entered when the program lock mode is to be set. How to use the password function Press H.LOCK button, Password will appear on the screen. The initial password of the television is 0000. -
Page 33: Child Lock
Lock Setup Preset program Preset program is opted for setting up preset channel. Press CH+/- button to select preset Channel. Press VOL+/- button, to select channel number.(The item is not available except TV signal.) Child Lock Press CH+/- button to select Child Lock. Press VOL+/- button to set On or Off mode. -
Page 34: Other Functions
Other functions Display function Press the DISPLAY button, then the channel number and system will be displayed on the screen. Press the DISPLAY button STILL Press the STILL button, the STILL will display on the screen, at this time, the picture of TV is still, and press the STILL button again, the picture will resume. -
Page 35: Streaming Media Playing System
Streaming Media Playing System Notices: the following graphics are only diagrammatic sketches for reference and shall be subject to the actual appearance of products. Installation of Streaming Media 1. Supported file formats: 1) Pictures: *.jpg file; 2) Music: *.mp3\*.wma file; 3) Movie: MPEG4: *.avi\*.divx files that comply with the protocols of Divx3. - Page 36 Streaming Media Playing System RETURN ENTER ZOOM HELP TV/AV TIME SHIFT ZOOM/MOVE SWAP PIC.SIZE MENU VOL+ VOL- To operate the menu 1. Press Q.VIEW 2. Press STILL left or right. 3. Press ENTER button to ensure the desired option to enter the submenu to resume the speed of standard.
- Page 37 Streaming Media Playing System RETURN ENTER ZOOM HELP TV/AV TIME SHIFT ZOOM/MOVE SWAP PIC.SIZE MENU VOL- VOL+ Q.VIEW STILL CH.EDIT -/-- Note: 1.the play file menu are different with your USB devices. 2. May carry on the programming playing: repeated step 2 to choose many documents, ( right key choice or cancellation picture choice), press ENTER to play, at this time,...
-
Page 38: To Play Music
Streaming Media Playing System RETURN ENTER ZOOM HELP TV/AV TIME SHIFT ZOOM/MOVE SWAP PIC.SIZE MENU VOL- VOL+ Q.VIEW STILL CH.EDIT -/-- To play Music Press USB button to enter USB interface, and Press button to select disk partition, and then press or button to select Music option Press ENTER button to enter... - Page 39 Streaming Media Playing System RETURN ENTER ZOOM HELP TIME SHIFT TV/AV SWAP ZOOM/MOVE PIC.SIZE MENU VOL+ VOL- Q.VIEW STILL CH.EDIT -/-- To Record and Play Press USB button to enter USB interface, and Press button to select disk partition, and then press or button to select PVR option Press ENTER button to enter...
-
Page 40: Maintenance
Maintenance - Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you will have your new TV. Be sure to turn the power off and unplug the power cord before you begin any cleaning. Cleaning the Screen . -
Page 41: Troubleshooting
Troubleshooting For the sake of time and cost, it is strongly recommended that you check out the problem by yourself according to the instructions listed hereunder before contacting the after-sales service for technical assistance. Problem No picture, no sound Good picture, no sound Failure of remote controller... -
Page 42: Specifications
Product main size (contain stand) Power Model Consumption LR42T1 250W±10% 300W±10% LR47T1 NOTE : Design and specifications are subject to change without notice. The dimension in this manual is a approximation. ~ 150- 4 PAL NTSC, SECAM D/K I B/G, M... -
Page 43: Format
Format Recommendatory HDTV/SDTV(YPbPr/YCbCr) format Sequence Format Number 480i/480p 576i/576p 720p 1080i/1080p Recommendation PC connection input format: sequence Format number 640*480@60Hz 800*600@60Hz 1024*768@60Hz Recommendatory) 1280*1024@60Hz 1600*1200@60Hz Recommendation DVI connection input format: Sequence Refresh Frequency Resolution Number 640*480 800*600 1024*768 1280*1024 Refresh Frequency 50/60 50/60 H-Frequency...
