Summary of Contents for Haier LY22K3CWW2
-
Page 2: Table Of Contents
Contents Contents COMMON INTERFACE ........13 Safety Warnings Software Update function ..........13 WELCOME ............. 2 Operation................14 IMPORTANT INFORMATION ........ 2 USING YOUR TV..........14 How to select the TV program........14 About your LCD TV HOW to adjust volume............14 CH.LIST function ..............15 GET TO KNOW YOUR TV........ -
Page 3: Safety Warnings
Safety Warnings Safety Warnings WELCOME Thanks for buying this 19"/22"/40" HD Ready Digital LCD/LED LCD TV. This guide will help you set up and begin using your TV. First, check the contents of your box with the parts checklist below: 19"/22"... - Page 4 Safety Warningss The product should be tightly fixed to avoid To avoid fire hazards, do not use this drop damages and even fire. product under direct sunlight or closely to heat sources. Unplug the power supply and antenna of Do not locate the product close to water the product when there is a rainstorm, or oil, which may cause fire hazards.
- Page 5 Safety Warnings Don‘t use or store inflammable materials Don’t place the product in a humid area to near the product to avoid explosion or fire avoid fire hazards. hazards. Never touch the plug when your hand is wet The antenna of the product should be away as this might cause electric shocks.
-
Page 6: About Your Lcd Tv
About your LCD TV Installing the stand Only for LED19/22T3 1. Put the small piece out of the base stand. 2. Position the column with the base stand. 3. Push the LCD TV onto the base. Rotate the machine about 15 degrees according to the arrow on the base stand . - Page 7 About your LCD TV Installing the Stand Only for LED40T3 1.Carefully place the TV screen side down on a table. We suggest that you place the wrapping material from the TV package on the table top to protect the screen from damage.
-
Page 8: Get To Know Your Tv
About your LCD TV About your LCD/LED LCD TV GET TO KNOW YOUR TV Only 19"/22" LCD Model Front control panel 1 Standby switch 5 CH- 2 SOURCE 3 MENU 6 Power indicator 7 Remote Sensor 4 VOL- VOL+ EN-7 Digital LCD Television Instruction Manual... -
Page 9: Rear Terminals Control
About your LCD TV Rear Terminals Control Digital LCD Television Instruction Manual EN-8... - Page 10 About your LCD TV Only 19"/22" LED LCD Model 4 CH- Call the input Source menu/Confirm button TV channel down/to select the item in the menu. 1 SOURCE when operating menu. TV channel up/to select the item in the menu. 2 MENU Press to select the main menu.
- Page 11 About your LCD TV Only 40" LED LCD Model 4 CH+/- Toggles between all the available input Press to change channels. 1 SOURCE sources 5 POWER Press to turn the TV on and off. Press to see an on-screen menu of your TV’s 2 MENU features.
- Page 12 About your LCD TV GET TO KNOW YOUR REMOTE CONTROL When using the remote control, aim it towards the remote sensor on the TV. 1 Stand By 2 DVD Menu / REC 3 DVD open / close 4 Picture Mode 5 Sound Mode 6 Call Screen Display 7 Sleep button...
- Page 13 About your LCD TV CONNECTING YOUR Turn on the DVD player and insert a DVD. Press the button to select . Refer to the DVD player user guide for operating instructions. ANTENNA CONNECTION Connect your aerial to the back of the TV into the ANTENNA IN socket.
- Page 14 About your LCD TV About your LCD TV / Getting Started Press the button to select SCART mode. SOURCE Close the cover of the battery compartment. Press the PLAY button on the external device. HDMI INPUT Connect the cable from the HDMI device to the TV HDMI socket.
- Page 15 Getting Started Insert the batteries into the remote control. Make sure they are inserted the right way around, matching the polarity as indicated inside the battery compartment. SWITCHING YOUR TV ON Press the STANDBY button on the right side/top of the TV once.
- Page 16 Getting Started Press button to select Tuning menu, press button to enter. Press button to select Digital Manual Search item, press button to enter. Press button to select Search item, press button is used to select the higher frequency channel. Press button is used to select the lower frequency channel.
- Page 17 Getting Started Press button to select the number position you want to remove to, press yellow button to confirm. You can press the EXIT button to cancel the changes at anytime. Setting favourite channel Press button to select the channel, press red button to set your favourite channel.
- Page 18 Getting Started Press button to select the guide item. CI Slot Press OK button to enter the submenu, the electronic program guide is displayed. You can quickly call up Guide menu by GUIDE Smart Card button on the remote control. Note Only DTV mode.
- Page 19 Getting Started Press button to select the System Update option and use OK button to enter. Then the TV will restart and search the upgrade information. Note If the upgrade information is received, the TV will begin to upgrade. Or else, the TV will be back the DTV source.
- Page 20 Getting Started Colour CH.LIST function This will adjust the saturation level of the colours to suit your personal preference. Press CH.LIST button on the remote control will display Channel List menu, and then press button to enter. Sharpness Press button to select the channel, and then press This will adjust the sharpness of fine details in the OK button to enter.
- Page 21 Getting Started Audio Languages Press button to select Sound menu, press Press button to select Primary/Secondary item, button to enter. and then press button to select the languages you needed. Press button to select the item requires Press button to select Close item, press OK button adjusting.
- Page 22 Getting Started Note The Blue Screen function is only available for ATV mode. Recorder To recorder the DTV program. Details of Recorder are described in the page of 25, 26. SCART Input When you use the SCART2 input ,make sure the input Press button to select the item requires adjusting.
- Page 23 Getting Started Press button to select Clock item, press Press button to select Off Time item, press button to enter setting. button to enter setting. Press button to select hour or minute, press Press button to select Repeat option, and button to adjust the value.
- Page 24 Getting Started button to enter the sub-menu, and you will be required Press the MENU button and then use button to enter the password. The initial password of the to select the Time menu. television is 0000. If you forget your password, you can always input 9443 to regain control.
- Page 25 Getting Started Channel NO. SHORTCUT MENU Channel NO. is opted for setting up preset channel. Press button to select preset Channel. Press DISPLAY button to select channel number. Source set Subtitle Function Channel set is opted for setting up start source. Press button to select Off, DTV, TV, SCART, , Press...
- Page 26 Getting Started You can press the EXIT button to cancel the changes Note at anytime. Press AUDIO button on the remote, it will display Audio Languages menu only in the DTV mode. Eliminate Sound When you need to pay attention to surrounded sounds, or there is a telephone calling you or there are some guests visiting you, the sound elimination (mute) function is very convenient.
- Page 27 Using the features Mix mode Using the features To view the TV picture while in Text mode press the button, this will superimpose the Teletext data on top of the TV picture. Press this button again to return to Full text. Teletext functions Teletext is an information system, broadcast by certain channels, which can be read like a newspaper.
- Page 28 Using the features Supported equipment: Time Support the equipment that supports Mass Storage While in normal TV mode only, pressing the button Protocol and whose file system is FAT32, such will display the teletext time in the top right hand as some USB disks, mobile harddisks, and MP3 corner for a few seconds.
- Page 29 Using the features Please do not unplug the USB device when the If you want to pause the picture which is being connected USB storage device is working. When such palyed, press the PALY/PAUSE button again. device is suddenly separated or unplugged, the stored Press ”ZOOM“...
- Page 30 Using the features To exit the “Text” mode, just press “BACK” repeatedly. Playing a Movie Note “ / “ to Atter entering USB main interface, press You can enjoy the music and the text at the same select “Movie”. time. Press “...
- Page 31 Using the features IMPORTANT Note USB device should be format as FAT32 format by The system will format the whole device and if your your PC before insert to the USB connector. device size is bigger than 1GB, you can set the size which is used for time shift.
- Page 32 Using the features Place the DVD in the disc slot with the DVD label Press button to select the content you recorded. facing away from you and the screen. The disc slot Press the button to display the program will only take standard-sized DVD. information.
- Page 33 Using the features SEARCH USING THE ZOOM FUNCTION Press SEARCH and use the numerical keys to enter Press the ZOOM button to zoom into the image the chapter number you wish to go to and press on screen. You can press it repeatedly to further PLAY/PAUSE.
- Page 34 Using the features PLAYING AN AUDIO CD Verify if correct channel is No picture in Insert a CD in the same way as you would a DVD, selected. some channel with the label facing away from you. Adjust the antenna. The CD will load and a menu of the disc’s contents Verify if the same problem exists will appear on screen.
- Page 35 Reference Sections 40” Remote control , AAA battery ×2 , Instruction Manual , Warranty , TV Stand 5XScrews for TV stand(only for 40" model) Component adapter,Component audio adapter ,SCART adapter (only for 40" model) Cover button (only for 40" model) Digital LCD Television Instruction Manual EN-34...
-
Page 38: Get To Know Your Tv With Dvd
Contents Contents COMMON INTERFACE ........13 Safety Warnings Software Update function ..........13 WELCOME ............. 2 Operation................14 IMPORTANT INFORMATION ........ 2 USING YOUR TV..........14 How to select the TV program........14 About your LCD TV HOW to adjust volume............14 CH.LIST function ..............15 GET TO KNOW YOUR TV........ - Page 39 Safety Warnings Safety Warnings WELCOME Thanks for buying this 19"/22"/40" HD Ready Digital LCD/LED LCD TV. This guide will help you set up and begin using your TV. First, check the contents of your box with the parts checklist below: 19"/22"...
- Page 40 Safety Warningss The product should be tightly fixed to avoid To avoid fire hazards, do not use this drop damages and even fire. product under direct sunlight or closely to heat sources. Unplug the power supply and antenna of Do not locate the product close to water the product when there is a rainstorm, or oil, which may cause fire hazards.
- Page 41 Safety Warnings Don‘t use or store inflammable materials Don’t place the product in a humid area to near the product to avoid explosion or fire avoid fire hazards. hazards. Never touch the plug when your hand is wet The antenna of the product should be away as this might cause electric shocks.
- Page 42 About your LCD TV Installing the stand Only for LED19/22T3 1. Put the small piece out of the base stand. 2. Position the column with the base stand. 3. Push the LCD TV onto the base. Rotate the machine about 15 degrees according to the arrow on the base stand .
- Page 43 About your LCD TV Installing the Stand Only for LED40T3 1.Carefully place the TV screen side down on a table. We suggest that you place the wrapping material from the TV package on the table top to protect the screen from damage.
-
Page 44: Front Control Panel
About your LCD TV About your LCD/LED LCD TV GET TO KNOW YOUR TV Only 19"/22" LCD Model Front control panel 1 Standby switch 5 CH- 2 SOURCE 3 MENU 6 Power indicator 7 Remote Sensor 4 VOL- VOL+ EN-7 Digital LCD Television Instruction Manual... -
Page 45: Rear Terminals Control
About your LCD TV Rear Terminals Control Digital LCD Television Instruction Manual EN-8... -
Page 46: Usb Input
About your LCD TV Only 19"/22" LED LCD Model 4 CH- Call the input Source menu/Confirm button TV channel down/to select the item in the menu. 1 SOURCE when operating menu. TV channel up/to select the item in the menu. 2 MENU Press to select the main menu. - Page 47 About your LCD TV Only 40" LED LCD Model 4 CH+/- Toggles between all the available input Press to change channels. 1 SOURCE sources 5 POWER Press to turn the TV on and off. Press to see an on-screen menu of your TV’s 2 MENU features.
-
Page 48: Get To Know Your Remote Control
About your LCD TV GET TO KNOW YOUR REMOTE CONTROL When using the remote control, aim it towards the remote sensor on the TV. 1 Stand By 2 DVD Menu / REC 3 DVD open / close 4 Picture Mode 5 Sound Mode 6 Call Screen Display 7 Sleep button... -
Page 49: Connecting Your Tv
About your LCD TV CONNECTING YOUR Turn on the DVD player and insert a DVD. Press the button to select . Refer to the DVD player user guide for operating instructions. ANTENNA CONNECTION Connect your aerial to the back of the TV into the ANTENNA IN socket. -
Page 50: Hdmi Input
About your LCD TV About your LCD TV / Getting Started Press the button to select SCART mode. SOURCE Close the cover of the battery compartment. Press the PLAY button on the external device. HDMI INPUT Connect the cable from the HDMI device to the TV HDMI socket. -
Page 51: Switching Your Tv On
Getting Started Insert the batteries into the remote control. Make sure they are inserted the right way around, matching the polarity as indicated inside the battery compartment. SWITCHING YOUR TV ON Press the STANDBY button on the right side/top of the TV once. -
Page 52: Analog Manual Search
Getting Started Press button to select Tuning menu, press button to enter. Press button to select Digital Manual Search item, press button to enter. Press button to select Search item, press button is used to select the higher frequency channel. Press button is used to select the lower frequency channel. -
Page 53: Rename
Getting Started Press button to select the number position you want to remove to, press yellow button to confirm. You can press the EXIT button to cancel the changes at anytime. Setting favourite channel Press button to select the channel, press red button to set your favourite channel. -
Page 54: Common Interface
Getting Started Press button to select the guide item. CI Slot Press OK button to enter the submenu, the electronic program guide is displayed. You can quickly call up Guide menu by GUIDE Smart Card button on the remote control. Note Only DTV mode. -
Page 55: Operation
Getting Started Press button to select the System Update option and use OK button to enter. Then the TV will restart and search the upgrade information. Note If the upgrade information is received, the TV will begin to upgrade. Or else, the TV will be back the DTV source. -
Page 56: Ch.list Function
Getting Started Colour CH.LIST function This will adjust the saturation level of the colours to suit your personal preference. Press CH.LIST button on the remote control will display Channel List menu, and then press button to enter. Sharpness Press button to select the channel, and then press This will adjust the sharpness of fine details in the OK button to enter. -
Page 57: Function Settings
Getting Started Audio Languages Press button to select Sound menu, press Press button to select Primary/Secondary item, button to enter. and then press button to select the languages you needed. Press button to select the item requires Press button to select Close item, press OK button adjusting. -
Page 58: Time Settings
Getting Started Note The Blue Screen function is only available for ATV mode. Recorder To recorder the DTV program. Details of Recorder are described in the page of 25, 26. SCART Input When you use the SCART2 input ,make sure the input Press button to select the item requires adjusting. - Page 59 Getting Started Press button to select Clock item, press Press button to select Off Time item, press button to enter setting. button to enter setting. Press button to select hour or minute, press Press button to select Repeat option, and button to adjust the value.
-
Page 60: Lock Menu Setting
Getting Started button to enter the sub-menu, and you will be required Press the MENU button and then use button to enter the password. The initial password of the to select the Time menu. television is 0000. If you forget your password, you can always input 9443 to regain control. -
Page 61: Shortcut Menu Display
Getting Started Channel NO. SHORTCUT MENU Channel NO. is opted for setting up preset channel. Press button to select preset Channel. Press DISPLAY button to select channel number. Source set Subtitle Function Channel set is opted for setting up start source. Press button to select Off, DTV, TV, SCART, , Press... - Page 62 Getting Started You can press the EXIT button to cancel the changes Note at anytime. Press AUDIO button on the remote, it will display Audio Languages menu only in the DTV mode. Eliminate Sound When you need to pay attention to surrounded sounds, or there is a telephone calling you or there are some guests visiting you, the sound elimination (mute) function is very convenient.
-
Page 63: Using The Features
Using the features Mix mode Using the features To view the TV picture while in Text mode press the button, this will superimpose the Teletext data on top of the TV picture. Press this button again to return to Full text. Teletext functions Teletext is an information system, broadcast by certain channels, which can be read like a newspaper. -
Page 64: Usb Mode
Using the features Supported equipment: Time Support the equipment that supports Mass Storage While in normal TV mode only, pressing the button Protocol and whose file system is FAT32, such will display the teletext time in the top right hand as some USB disks, mobile harddisks, and MP3 corner for a few seconds. -
Page 65: Operating The Usb Device
Using the features Please do not unplug the USB device when the If you want to pause the picture which is being connected USB storage device is working. When such palyed, press the PALY/PAUSE button again. device is suddenly separated or unplugged, the stored Press ”ZOOM“... -
Page 66: Playing A Movie
Using the features To exit the “Text” mode, just press “BACK” repeatedly. Playing a Movie Note “ / “ to Atter entering USB main interface, press You can enjoy the music and the text at the same select “Movie”. time. Press “... -
Page 67: Time Shift
Using the features IMPORTANT Note USB device should be format as FAT32 format by The system will format the whole device and if your your PC before insert to the USB connector. device size is bigger than 1GB, you can set the size which is used for time shift. -
Page 68: Using Your Dvd Player
Using the features Place the DVD in the disc slot with the DVD label Press button to select the content you recorded. facing away from you and the screen. The disc slot Press the button to display the program will only take standard-sized DVD. information. -
Page 69: Additional Dvd Functions
Using the features SEARCH USING THE ZOOM FUNCTION Press SEARCH and use the numerical keys to enter Press the ZOOM button to zoom into the image the chapter number you wish to go to and press on screen. You can press it repeatedly to further PLAY/PAUSE. -
Page 70: Reference Sections
Using the features PLAYING AN AUDIO CD Verify if correct channel is No picture in Insert a CD in the same way as you would a DVD, selected. some channel with the label facing away from you. Adjust the antenna. The CD will load and a menu of the disc’s contents Verify if the same problem exists will appear on screen. - Page 71 Reference Sections 40” Remote control , AAA battery ×2 , Instruction Manual , Warranty , TV Stand 5XScrews for TV stand(only for 40" model) Component adapter,Component audio adapter ,SCART adapter (only for 40" model) Cover button (only for 40" model) Digital LCD Television Instruction Manual EN-34...
- Page 74 Contents Contents COMMON INTERFACE ........13 Safety Warnings Software Update function ..........13 WELCOME ............. 2 Operation................14 IMPORTANT INFORMATION ........ 2 USING YOUR TV..........14 How to select the TV program........14 About your LCD TV HOW to adjust volume............14 CH.LIST function ..............15 GET TO KNOW YOUR TV........
-
Page 75: Safety Warnings
Safety Warnings Safety Warnings WELCOME Thanks for buying this 19"/22"/40" HD Ready Digital LCD/LED LCD TV. This guide will help you set up and begin using your TV. First, check the contents of your box with the parts checklist below: 19"/22"... - Page 76 Safety Warningss The product should be tightly fixed to avoid To avoid fire hazards, do not use this drop damages and even fire. product under direct sunlight or closely to heat sources. Unplug the power supply and antenna of Do not locate the product close to water the product when there is a rainstorm, or oil, which may cause fire hazards.
- Page 77 Safety Warnings Don‘t use or store inflammable materials Don’t place the product in a humid area to near the product to avoid explosion or fire avoid fire hazards. hazards. Never touch the plug when your hand is wet The antenna of the product should be away as this might cause electric shocks.
-
Page 78: About Your Lcd Tv
About your LCD TV Installing the stand Only for LED19/22T3 1. Put the small piece out of the base stand. 2. Position the column with the base stand. 3. Push the LCD TV onto the base. Rotate the machine about 15 degrees according to the arrow on the base stand . - Page 79 About your LCD TV Installing the Stand Only for LED40T3 1.Carefully place the TV screen side down on a table. We suggest that you place the wrapping material from the TV package on the table top to protect the screen from damage.
-
Page 80: Get To Know Your Tv
About your LCD TV About your LCD/LED LCD TV GET TO KNOW YOUR TV Only 19"/22" LCD Model Front control panel 1 Standby switch 5 CH- 2 SOURCE 3 MENU 6 Power indicator 7 Remote Sensor 4 VOL- VOL+ EN-7 Digital LCD Television Instruction Manual... -
Page 81: Rear Terminals Control
About your LCD TV Rear Terminals Control Digital LCD Television Instruction Manual EN-8... - Page 82 About your LCD TV Only 19"/22" LED LCD Model 4 CH- Call the input Source menu/Confirm button TV channel down/to select the item in the menu. 1 SOURCE when operating menu. TV channel up/to select the item in the menu. 2 MENU Press to select the main menu.
- Page 83 About your LCD TV Only 40" LED LCD Model 4 CH+/- Toggles between all the available input Press to change channels. 1 SOURCE sources 5 POWER Press to turn the TV on and off. Press to see an on-screen menu of your TV’s 2 MENU features.
-
Page 84: Get To Know Your Remote Control
About your LCD TV GET TO KNOW YOUR REMOTE CONTROL When using the remote control, aim it towards the remote sensor on the TV. 1 Stand By 2 DVD Menu / REC 3 DVD open / close 4 Picture Mode 5 Sound Mode 6 Call Screen Display 7 Sleep button... -
Page 85: Connecting Your Tv
About your LCD TV CONNECTING YOUR Turn on the DVD player and insert a DVD. Press the button to select . Refer to the DVD player user guide for operating instructions. ANTENNA CONNECTION Connect your aerial to the back of the TV into the ANTENNA IN socket. -
Page 86: Hdmi Input
About your LCD TV About your LCD TV / Getting Started Press the button to select SCART mode. SOURCE Close the cover of the battery compartment. Press the PLAY button on the external device. HDMI INPUT Connect the cable from the HDMI device to the TV HDMI socket. -
Page 87: Switching Your Tv On
Getting Started Insert the batteries into the remote control. Make sure they are inserted the right way around, matching the polarity as indicated inside the battery compartment. SWITCHING YOUR TV ON Press the STANDBY button on the right side/top of the TV once. -
Page 88: Analog Manual Search
Getting Started Press button to select Tuning menu, press button to enter. Press button to select Digital Manual Search item, press button to enter. Press button to select Search item, press button is used to select the higher frequency channel. Press button is used to select the lower frequency channel. -
Page 89: Rename
Getting Started Press button to select the number position you want to remove to, press yellow button to confirm. You can press the EXIT button to cancel the changes at anytime. Setting favourite channel Press button to select the channel, press red button to set your favourite channel. -
Page 90: Common Interface
Getting Started Press button to select the guide item. CI Slot Press OK button to enter the submenu, the electronic program guide is displayed. You can quickly call up Guide menu by GUIDE Smart Card button on the remote control. Note Only DTV mode. -
Page 91: Operation
Getting Started Press button to select the System Update option and use OK button to enter. Then the TV will restart and search the upgrade information. Note If the upgrade information is received, the TV will begin to upgrade. Or else, the TV will be back the DTV source. -
Page 92: Ch.list Function
Getting Started Colour CH.LIST function This will adjust the saturation level of the colours to suit your personal preference. Press CH.LIST button on the remote control will display Channel List menu, and then press button to enter. Sharpness Press button to select the channel, and then press This will adjust the sharpness of fine details in the OK button to enter. -
Page 93: Function Settings
Getting Started Audio Languages Press button to select Sound menu, press Press button to select Primary/Secondary item, button to enter. and then press button to select the languages you needed. Press button to select the item requires Press button to select Close item, press OK button adjusting. -
Page 94: Time Settings
Getting Started Note The Blue Screen function is only available for ATV mode. Recorder To recorder the DTV program. Details of Recorder are described in the page of 25, 26. SCART Input When you use the SCART2 input ,make sure the input Press button to select the item requires adjusting. - Page 95 Getting Started Press button to select Clock item, press Press button to select Off Time item, press button to enter setting. button to enter setting. Press button to select hour or minute, press Press button to select Repeat option, and button to adjust the value.
-
Page 96: Lock Menu Setting
Getting Started button to enter the sub-menu, and you will be required Press the MENU button and then use button to enter the password. The initial password of the to select the Time menu. television is 0000. If you forget your password, you can always input 9443 to regain control. -
Page 97: Shortcut Menu Display
Getting Started Channel NO. SHORTCUT MENU Channel NO. is opted for setting up preset channel. Press button to select preset Channel. Press DISPLAY button to select channel number. Source set Subtitle Function Channel set is opted for setting up start source. Press button to select Off, DTV, TV, SCART, , Press... - Page 98 Getting Started You can press the EXIT button to cancel the changes Note at anytime. Press AUDIO button on the remote, it will display Audio Languages menu only in the DTV mode. Eliminate Sound When you need to pay attention to surrounded sounds, or there is a telephone calling you or there are some guests visiting you, the sound elimination (mute) function is very convenient.
-
Page 99: Using The Features
Using the features Mix mode Using the features To view the TV picture while in Text mode press the button, this will superimpose the Teletext data on top of the TV picture. Press this button again to return to Full text. Teletext functions Teletext is an information system, broadcast by certain channels, which can be read like a newspaper. -
Page 100: Usb Mode
Using the features Supported equipment: Time Support the equipment that supports Mass Storage While in normal TV mode only, pressing the button Protocol and whose file system is FAT32, such will display the teletext time in the top right hand as some USB disks, mobile harddisks, and MP3 corner for a few seconds. -
Page 101: Operating The Usb Device
Using the features Please do not unplug the USB device when the If you want to pause the picture which is being connected USB storage device is working. When such palyed, press the PALY/PAUSE button again. device is suddenly separated or unplugged, the stored Press ”ZOOM“... -
Page 102: Playing A Movie
Using the features To exit the “Text” mode, just press “BACK” repeatedly. Playing a Movie Note “ / “ to Atter entering USB main interface, press You can enjoy the music and the text at the same select “Movie”. time. Press “... -
Page 103: Time Shift
Using the features IMPORTANT Note USB device should be format as FAT32 format by The system will format the whole device and if your your PC before insert to the USB connector. device size is bigger than 1GB, you can set the size which is used for time shift. -
Page 104: Using Your Dvd Player
Using the features Place the DVD in the disc slot with the DVD label Press button to select the content you recorded. facing away from you and the screen. The disc slot Press the button to display the program will only take standard-sized DVD. information. - Page 105 Using the features SEARCH USING THE ZOOM FUNCTION Press SEARCH and use the numerical keys to enter Press the ZOOM button to zoom into the image the chapter number you wish to go to and press on screen. You can press it repeatedly to further PLAY/PAUSE.
-
Page 106: Reference Sections
Using the features PLAYING AN AUDIO CD Verify if correct channel is No picture in Insert a CD in the same way as you would a DVD, selected. some channel with the label facing away from you. Adjust the antenna. The CD will load and a menu of the disc’s contents Verify if the same problem exists will appear on screen. - Page 107 Reference Sections 40” Remote control , AAA battery ×2 , Instruction Manual , Warranty , TV Stand 5XScrews for TV stand(only for 40" model) Component adapter,Component audio adapter ,SCART adapter (only for 40" model) Cover button (only for 40" model) Digital LCD Television Instruction Manual EN-34...
- Page 110 Contents Contents COMMON INTERFACE ........13 Safety Warnings Software Update function ..........13 WELCOME ............. 2 Operation................14 IMPORTANT INFORMATION ........ 2 USING YOUR TV..........14 How to select the TV program........14 About your LCD TV HOW to adjust volume............14 CH.LIST function ..............15 GET TO KNOW YOUR TV........
- Page 111 Safety Warnings Safety Warnings WELCOME Thanks for buying this 19"/22"/40" HD Ready Digital LCD/LED LCD TV. This guide will help you set up and begin using your TV. First, check the contents of your box with the parts checklist below: 19"/22"...
-
Page 112: Safety Warnings
Safety Warningss The product should be tightly fixed to avoid To avoid fire hazards, do not use this drop damages and even fire. product under direct sunlight or closely to heat sources. Unplug the power supply and antenna of Do not locate the product close to water the product when there is a rainstorm, or oil, which may cause fire hazards. - Page 113 Safety Warnings Don‘t use or store inflammable materials Don’t place the product in a humid area to near the product to avoid explosion or fire avoid fire hazards. hazards. Never touch the plug when your hand is wet The antenna of the product should be away as this might cause electric shocks.
-
Page 114: About Your Lcd Tv
About your LCD TV Installing the stand Only for LED19/22T3 1. Put the small piece out of the base stand. 2. Position the column with the base stand. 3. Push the LCD TV onto the base. Rotate the machine about 15 degrees according to the arrow on the base stand . - Page 115 About your LCD TV Installing the Stand Only for LED40T3 1.Carefully place the TV screen side down on a table. We suggest that you place the wrapping material from the TV package on the table top to protect the screen from damage.
-
Page 116: Get To Know Your Tv
About your LCD TV About your LCD/LED LCD TV GET TO KNOW YOUR TV Only 19"/22" LCD Model Front control panel 1 Standby switch 5 CH- 2 SOURCE 3 MENU 6 Power indicator 7 Remote Sensor 4 VOL- VOL+ EN-7 Digital LCD Television Instruction Manual... -
Page 117: Rear Terminals Control
About your LCD TV Rear Terminals Control Digital LCD Television Instruction Manual EN-8... - Page 118 About your LCD TV Only 19"/22" LED LCD Model 4 CH- Call the input Source menu/Confirm button TV channel down/to select the item in the menu. 1 SOURCE when operating menu. TV channel up/to select the item in the menu. 2 MENU Press to select the main menu.
- Page 119 About your LCD TV Only 40" LED LCD Model 4 CH+/- Toggles between all the available input Press to change channels. 1 SOURCE sources 5 POWER Press to turn the TV on and off. Press to see an on-screen menu of your TV’s 2 MENU features.
-
Page 120: Get To Know Your Remote Control
About your LCD TV GET TO KNOW YOUR REMOTE CONTROL When using the remote control, aim it towards the remote sensor on the TV. 1 Stand By 2 DVD Menu / REC 3 DVD open / close 4 Picture Mode 5 Sound Mode 6 Call Screen Display 7 Sleep button... -
Page 121: Connecting Your Tv
About your LCD TV CONNECTING YOUR Turn on the DVD player and insert a DVD. Press the button to select . Refer to the DVD player user guide for operating instructions. ANTENNA CONNECTION Connect your aerial to the back of the TV into the ANTENNA IN socket. -
Page 122: Hdmi Input
About your LCD TV About your LCD TV / Getting Started Press the button to select SCART mode. SOURCE Close the cover of the battery compartment. Press the PLAY button on the external device. HDMI INPUT Connect the cable from the HDMI device to the TV HDMI socket. -
Page 123: Switching Your Tv On
Getting Started Insert the batteries into the remote control. Make sure they are inserted the right way around, matching the polarity as indicated inside the battery compartment. SWITCHING YOUR TV ON Press the STANDBY button on the right side/top of the TV once. -
Page 124: Analog Manual Search
Getting Started Press button to select Tuning menu, press button to enter. Press button to select Digital Manual Search item, press button to enter. Press button to select Search item, press button is used to select the higher frequency channel. Press button is used to select the lower frequency channel. -
Page 125: Rename
Getting Started Press button to select the number position you want to remove to, press yellow button to confirm. You can press the EXIT button to cancel the changes at anytime. Setting favourite channel Press button to select the channel, press red button to set your favourite channel. -
Page 126: Common Interface
Getting Started Press button to select the guide item. CI Slot Press OK button to enter the submenu, the electronic program guide is displayed. You can quickly call up Guide menu by GUIDE Smart Card button on the remote control. Note Only DTV mode. -
Page 127: Operation
Getting Started Press button to select the System Update option and use OK button to enter. Then the TV will restart and search the upgrade information. Note If the upgrade information is received, the TV will begin to upgrade. Or else, the TV will be back the DTV source. -
Page 128: Ch.list Function
Getting Started Colour CH.LIST function This will adjust the saturation level of the colours to suit your personal preference. Press CH.LIST button on the remote control will display Channel List menu, and then press button to enter. Sharpness Press button to select the channel, and then press This will adjust the sharpness of fine details in the OK button to enter. -
Page 129: Function Settings
Getting Started Audio Languages Press button to select Sound menu, press Press button to select Primary/Secondary item, button to enter. and then press button to select the languages you needed. Press button to select the item requires Press button to select Close item, press OK button adjusting. -
Page 130: Time Settings
Getting Started Note The Blue Screen function is only available for ATV mode. Recorder To recorder the DTV program. Details of Recorder are described in the page of 25, 26. SCART Input When you use the SCART2 input ,make sure the input Press button to select the item requires adjusting. - Page 131 Getting Started Press button to select Clock item, press Press button to select Off Time item, press button to enter setting. button to enter setting. Press button to select hour or minute, press Press button to select Repeat option, and button to adjust the value.
-
Page 132: Lock Menu Setting
Getting Started button to enter the sub-menu, and you will be required Press the MENU button and then use button to enter the password. The initial password of the to select the Time menu. television is 0000. If you forget your password, you can always input 9443 to regain control. - Page 133 Getting Started Channel NO. SHORTCUT MENU Channel NO. is opted for setting up preset channel. Press button to select preset Channel. Press DISPLAY button to select channel number. Source set Subtitle Function Channel set is opted for setting up start source. Press button to select Off, DTV, TV, SCART, , Press...
- Page 134 Getting Started You can press the EXIT button to cancel the changes Note at anytime. Press AUDIO button on the remote, it will display Audio Languages menu only in the DTV mode. Eliminate Sound When you need to pay attention to surrounded sounds, or there is a telephone calling you or there are some guests visiting you, the sound elimination (mute) function is very convenient.
-
Page 135: Using The Features
Using the features Mix mode Using the features To view the TV picture while in Text mode press the button, this will superimpose the Teletext data on top of the TV picture. Press this button again to return to Full text. Teletext functions Teletext is an information system, broadcast by certain channels, which can be read like a newspaper. -
Page 136: Usb Mode
Using the features Supported equipment: Time Support the equipment that supports Mass Storage While in normal TV mode only, pressing the button Protocol and whose file system is FAT32, such will display the teletext time in the top right hand as some USB disks, mobile harddisks, and MP3 corner for a few seconds. -
Page 137: Operating The Usb Device
Using the features Please do not unplug the USB device when the If you want to pause the picture which is being connected USB storage device is working. When such palyed, press the PALY/PAUSE button again. device is suddenly separated or unplugged, the stored Press ”ZOOM“... -
Page 138: Playing A Movie
Using the features To exit the “Text” mode, just press “BACK” repeatedly. Playing a Movie Note “ / “ to Atter entering USB main interface, press You can enjoy the music and the text at the same select “Movie”. time. Press “... -
Page 139: Time Shift
Using the features IMPORTANT Note USB device should be format as FAT32 format by The system will format the whole device and if your your PC before insert to the USB connector. device size is bigger than 1GB, you can set the size which is used for time shift. -
Page 140: Using Your Dvd Player
Using the features Place the DVD in the disc slot with the DVD label Press button to select the content you recorded. facing away from you and the screen. The disc slot Press the button to display the program will only take standard-sized DVD. information. - Page 141 Using the features SEARCH USING THE ZOOM FUNCTION Press SEARCH and use the numerical keys to enter Press the ZOOM button to zoom into the image the chapter number you wish to go to and press on screen. You can press it repeatedly to further PLAY/PAUSE.
-
Page 142: Reference Sections
Using the features PLAYING AN AUDIO CD Verify if correct channel is No picture in Insert a CD in the same way as you would a DVD, selected. some channel with the label facing away from you. Adjust the antenna. The CD will load and a menu of the disc’s contents Verify if the same problem exists will appear on screen. - Page 143 Reference Sections 40” Remote control , AAA battery ×2 , Instruction Manual , Warranty , TV Stand 5XScrews for TV stand(only for 40" model) Component adapter,Component audio adapter ,SCART adapter (only for 40" model) Cover button (only for 40" model) Digital LCD Television Instruction Manual EN-34...
- Page 146 Contents Contents COMMON INTERFACE ........13 Safety Warnings Software Update function ..........13 WELCOME ............. 2 Operation................14 IMPORTANT INFORMATION ........ 2 USING YOUR TV..........14 How to select the TV program........14 About your LCD TV HOW to adjust volume............14 CH.LIST function ..............15 GET TO KNOW YOUR TV........
-
Page 147: Safety Warnings
Safety Warnings Safety Warnings WELCOME Thanks for buying this 19"/22"/40" HD Ready Digital LCD/LED LCD TV. This guide will help you set up and begin using your TV. First, check the contents of your box with the parts checklist below: 19"/22"... - Page 148 Safety Warningss The product should be tightly fixed to avoid To avoid fire hazards, do not use this drop damages and even fire. product under direct sunlight or closely to heat sources. Unplug the power supply and antenna of Do not locate the product close to water the product when there is a rainstorm, or oil, which may cause fire hazards.
- Page 149 Safety Warnings Don‘t use or store inflammable materials Don’t place the product in a humid area to near the product to avoid explosion or fire avoid fire hazards. hazards. Never touch the plug when your hand is wet The antenna of the product should be away as this might cause electric shocks.
-
Page 150: About Your Lcd Tv
About your LCD TV Installing the stand Only for LED19/22T3 1. Put the small piece out of the base stand. 2. Position the column with the base stand. 3. Push the LCD TV onto the base. Rotate the machine about 15 degrees according to the arrow on the base stand . - Page 151 About your LCD TV Installing the Stand Only for LED40T3 1.Carefully place the TV screen side down on a table. We suggest that you place the wrapping material from the TV package on the table top to protect the screen from damage.
-
Page 152: Get To Know Your Tv
About your LCD TV About your LCD/LED LCD TV GET TO KNOW YOUR TV Only 19"/22" LCD Model Front control panel 1 Standby switch 5 CH- 2 SOURCE 3 MENU 6 Power indicator 7 Remote Sensor 4 VOL- VOL+ EN-7 Digital LCD Television Instruction Manual... -
Page 153: Rear Terminals Control
About your LCD TV Rear Terminals Control Digital LCD Television Instruction Manual EN-8... - Page 154 About your LCD TV Only 19"/22" LED LCD Model 4 CH- Call the input Source menu/Confirm button TV channel down/to select the item in the menu. 1 SOURCE when operating menu. TV channel up/to select the item in the menu. 2 MENU Press to select the main menu.
- Page 155 About your LCD TV Only 40" LED LCD Model 4 CH+/- Toggles between all the available input Press to change channels. 1 SOURCE sources 5 POWER Press to turn the TV on and off. Press to see an on-screen menu of your TV’s 2 MENU features.
-
Page 156: Get To Know Your Remote Control
About your LCD TV GET TO KNOW YOUR REMOTE CONTROL When using the remote control, aim it towards the remote sensor on the TV. 1 Stand By 2 DVD Menu / REC 3 DVD open / close 4 Picture Mode 5 Sound Mode 6 Call Screen Display 7 Sleep button... -
Page 157: Connecting Your Tv
About your LCD TV CONNECTING YOUR Turn on the DVD player and insert a DVD. Press the button to select . Refer to the DVD player user guide for operating instructions. ANTENNA CONNECTION Connect your aerial to the back of the TV into the ANTENNA IN socket. -
Page 158: Hdmi Input
About your LCD TV About your LCD TV / Getting Started Press the button to select SCART mode. SOURCE Close the cover of the battery compartment. Press the PLAY button on the external device. HDMI INPUT Connect the cable from the HDMI device to the TV HDMI socket. -
Page 159: Switching Your Tv On
Getting Started Insert the batteries into the remote control. Make sure they are inserted the right way around, matching the polarity as indicated inside the battery compartment. SWITCHING YOUR TV ON Press the STANDBY button on the right side/top of the TV once. -
Page 160: Analog Manual Search
Getting Started Press button to select Tuning menu, press button to enter. Press button to select Digital Manual Search item, press button to enter. Press button to select Search item, press button is used to select the higher frequency channel. Press button is used to select the lower frequency channel. -
Page 161: Rename
Getting Started Press button to select the number position you want to remove to, press yellow button to confirm. You can press the EXIT button to cancel the changes at anytime. Setting favourite channel Press button to select the channel, press red button to set your favourite channel. -
Page 162: Common Interface
Getting Started Press button to select the guide item. CI Slot Press OK button to enter the submenu, the electronic program guide is displayed. You can quickly call up Guide menu by GUIDE Smart Card button on the remote control. Note Only DTV mode. -
Page 163: Operation
Getting Started Press button to select the System Update option and use OK button to enter. Then the TV will restart and search the upgrade information. Note If the upgrade information is received, the TV will begin to upgrade. Or else, the TV will be back the DTV source. -
Page 164: Ch.list Function
Getting Started Colour CH.LIST function This will adjust the saturation level of the colours to suit your personal preference. Press CH.LIST button on the remote control will display Channel List menu, and then press button to enter. Sharpness Press button to select the channel, and then press This will adjust the sharpness of fine details in the OK button to enter. -
Page 165: Function Settings
Getting Started Audio Languages Press button to select Sound menu, press Press button to select Primary/Secondary item, button to enter. and then press button to select the languages you needed. Press button to select the item requires Press button to select Close item, press OK button adjusting. -
Page 166: Time Settings
Getting Started Note The Blue Screen function is only available for ATV mode. Recorder To recorder the DTV program. Details of Recorder are described in the page of 25, 26. SCART Input When you use the SCART2 input ,make sure the input Press button to select the item requires adjusting. - Page 167 Getting Started Press button to select Clock item, press Press button to select Off Time item, press button to enter setting. button to enter setting. Press button to select hour or minute, press Press button to select Repeat option, and button to adjust the value.
-
Page 168: Lock Menu Setting
Getting Started button to enter the sub-menu, and you will be required Press the MENU button and then use button to enter the password. The initial password of the to select the Time menu. television is 0000. If you forget your password, you can always input 9443 to regain control. -
Page 169: Shortcut Menu Display
Getting Started Channel NO. SHORTCUT MENU Channel NO. is opted for setting up preset channel. Press button to select preset Channel. Press DISPLAY button to select channel number. Source set Subtitle Function Channel set is opted for setting up start source. Press button to select Off, DTV, TV, SCART, , Press... - Page 170 Getting Started You can press the EXIT button to cancel the changes Note at anytime. Press AUDIO button on the remote, it will display Audio Languages menu only in the DTV mode. Eliminate Sound When you need to pay attention to surrounded sounds, or there is a telephone calling you or there are some guests visiting you, the sound elimination (mute) function is very convenient.
-
Page 171: Using The Features
Using the features Mix mode Using the features To view the TV picture while in Text mode press the button, this will superimpose the Teletext data on top of the TV picture. Press this button again to return to Full text. Teletext functions Teletext is an information system, broadcast by certain channels, which can be read like a newspaper. -
Page 172: Usb Mode
Using the features Supported equipment: Time Support the equipment that supports Mass Storage While in normal TV mode only, pressing the button Protocol and whose file system is FAT32, such will display the teletext time in the top right hand as some USB disks, mobile harddisks, and MP3 corner for a few seconds. -
Page 173: Operating The Usb Device
Using the features Please do not unplug the USB device when the If you want to pause the picture which is being connected USB storage device is working. When such palyed, press the PALY/PAUSE button again. device is suddenly separated or unplugged, the stored Press ”ZOOM“... -
Page 174: Playing A Movie
Using the features To exit the “Text” mode, just press “BACK” repeatedly. Playing a Movie Note “ / “ to Atter entering USB main interface, press You can enjoy the music and the text at the same select “Movie”. time. Press “... -
Page 175: Time Shift
Using the features IMPORTANT Note USB device should be format as FAT32 format by The system will format the whole device and if your your PC before insert to the USB connector. device size is bigger than 1GB, you can set the size which is used for time shift. -
Page 176: Using Your Dvd Player
Using the features Place the DVD in the disc slot with the DVD label Press button to select the content you recorded. facing away from you and the screen. The disc slot Press the button to display the program will only take standard-sized DVD. information. -
Page 177: Additional Dvd Functions
Using the features SEARCH USING THE ZOOM FUNCTION Press SEARCH and use the numerical keys to enter Press the ZOOM button to zoom into the image the chapter number you wish to go to and press on screen. You can press it repeatedly to further PLAY/PAUSE. -
Page 178: Reference Sections
Using the features PLAYING AN AUDIO CD Verify if correct channel is No picture in Insert a CD in the same way as you would a DVD, selected. some channel with the label facing away from you. Adjust the antenna. The CD will load and a menu of the disc’s contents Verify if the same problem exists will appear on screen. - Page 179 Reference Sections 40” Remote control , AAA battery ×2 , Instruction Manual , Warranty , TV Stand 5XScrews for TV stand(only for 40" model) Component adapter,Component audio adapter ,SCART adapter (only for 40" model) Cover button (only for 40" model) Digital LCD Television Instruction Manual EN-34...
Need help?
Do you have a question about the LY22K3CWW2 and is the answer not in the manual?
Questions and answers
