User's manual ：WY50QT-55
PREFACE
Thank you for buying WangYe's Model WY50QT-55 motorcycle,
meanwhile, welcome you to join the ranks that WangYe motorcycle
drives sincerely. Unless it enjoy it is the safer for driving result happy,
before driving should first contained every content in manual familiar
completely. Your personal security, does not only depend on your
alertness and is familiar with every operating technology, whether
familiar with mechanical performance of the motorcycle relevantly with
you too. Before driving each time, do a inspection first, maintain
regularly at the same time, are all the most basic condition. If while
needing to carry on time based maintenance or repair, remember to be
only the special maintenances of our company of all parts, most clear
how to deal with, can also guarantee to reach the best performance. If you
possesses the technological knowledge of every machinery and maintains
Advertisement
Table of Contents
Related Manuals for WangYe WY50QT-55
Summary of Contents for WangYe WY50QT-55
- Page 1 PREFACE Thank you for buying WangYe’s Model WY50QT-55 motorcycle, meanwhile, welcome you to join the ranks that WangYe motorcycle drives sincerely. Unless it enjoy it is the safer for driving result happy, before driving should first contained every content in manual familiar completely.
- Page 2 Operation instructions this adjust Model WY50QT-55 correct working technique with simple maintenance of motorcycle method, main point,etc. explain, expect durable to use in detail. Technical specification if there is the modification, manual this some picture or content might have some differences with the actual situation of vehicle, please forgive.
-
Page 3: Table Of Contents
LIST I. Motorcycle safe drive Brake operation……………………………15 Rules for safe drive………………………1 Engine power off operation…………………16 The payload………………………………2 Stopping motorcycle………………………16 The parts &subassemblies and use instruction IV Service and maintenance Parts & subassemblies………………………3 Periodical maintenance form………………19 Speedometer and indicator…………………5 Obviation of the simple trouble……………19 Ignition switch………………………………6 Cleaning of air cleaner……………………20 Fuel meter…………………………………7... -
Page 4: The Payload
The payload ※ Admonition: Only put light goods in sundry box or other deposited place. The goods weight conforms to the following blank 1: Blank.1 Deposited Weight(kg) Rack Luggage Box ※ The motorcycle max payload is 75kg,including the weight with the driver and the goods. - Page 5 Fig.1 - 4 - Fig.2 Broken Line（……）indicate the invisible parts. - 5 -...
-
Page 6: Ignition Switch
Instrument and turn signal light (Fig3) （1）Left turning signal light ⑵Odometer ⑶ Fuel meter ⑷ Speedometer ⑸ Right turning signal light FIG.3 ⑹ High-beam indicator Ignition switch（Fig4） ⑴On ( )-when the switch turn to this position, Start engine and do not pull out the key. ⑵Off ( ) When the switch turn to this position, Start engine power off and take out the key. -
Page 7: Horn Switch
Horn switch 3: （Fig 7） Press (3) button, the horn makes sound. Steering lock (Fig8, Fig 9): Turn handle left to end, presses down ignition key1 to ( ), the steering device are locked Do the above opposite it opened. Fig.9 Fig.8 Seat Lock（Fig 10）... - Page 8 Inspection engine oil level（Fig 12、Fig 13） 1.Keep the motor steady in the plane screw up the oil dip rod and clean it, then reinsert and inspect oil. 2.If the oil level reach to down limit sign (2), replenish the standard oil to upper limit sign (3) Fig.1 Suggestion the engine oil type: SAE-15W/40...
- Page 9 Brake Machinery’s burst indicate mark (Fig 16) (1). Reference marks. (2). Indicate marks. Notice :If totally brake. Change the brake block when reference marks and Indicate marks must be situated a straight line. - 12 - Tire Check the tire pressure regularly and adjust. Check before the tire cooled Check if there any metal trash or gravel in the groove of tires WARNING:...
-
Page 10: Brake Operation
Riding motor: WARNING: Wear the trousers to avoid touching with exhaust pipe and was burnt. The entire device must be installed according to requirement of the traffic rule. Take the license to riding. NOTICE: Control the speed and load during 1000km of running in period. Load should be within 100kg(including driver) If take more weight and speed will reduce life of engine, Speed according to (Blank 2) - Page 11 Engine Powered off（Fig18, Fig19） Close oil: revolve to the lowest place according to picture. (Normal situation is loose the throttle grip, and the engine is idling speed) Put the key to “（ ）” Fig18 Fig19 Stop operation: When the motorcycle stops, turn the key to “ ” position .put down the side stand and lock handle.
-
Page 12: Spark Plug
page Every month ﹡ Fuel pipe line ﹡ Operation of throttle ﹡ Core of the air Note1 C/1000km, if need: R ﹡ Spark plug C/2000km,If need: R ﹡ Idle, carburetor ﹡ Belt, drive Per1000km I If need: R ﹡ （300km）R Oil, gear box Note3 System,... - Page 13 Trouble Trouble reason Solution phenomenon The octane value of the fuel is too low Change flue Clean oil path Oil path stop up Check wire and change CDI Ignition time is too early or too late The vehicle Check ignition and clear out Spark too weak or flameout is unable to Clean adjust carburetor...
- Page 14 Warm up few minutes after the engine starts Idle to adjust screw (1) is it is it improve idle speed slightly to enter to fasten, is it is it withdraw it than screw slowly after stocking to fasten to mix and then rapidly, to stabilizing the position at most, then withdraw slowly, get and stabilize the position the most low.
-
Page 15: Fuse Replacement
（Fig.25） Changing of gear oil The recommended engine oil: SAE 80W/90 Oil capacity Resolving capacity: 0. 11L Changing capacity: 0. 1L Park in Main Stand。 Take apart the limiting bolt (2), and the spilling bolt (1). Fig25 NOTICE: The engine must be warmed up when spilling and the vehicle must be support by main stand! Reinstall the spilling bolt after clean. - Page 16 Warning: Gasoline is inflammable and may cause fire and even explosion under certain conditions. Therefore, do not smoke, make fire or have any fire left behind on draining off fuel. 3. Take out the spark plug, pour about 15~20ml clean engine oil into the cylinder, step down the kick lever repetitively for several times so as to have machine oil distributed all over the engine and finally fit the spark back on.
-
Page 17: Ⅵ. Main Technique Parameter
Main technique parameter Blank.5 MODEL MODEL DATA DATA Exterior size Front wheel 3.00-10 1755×670×1170 Wheelbase 1240 Rear wheel 3.00-10 Ground clearance Air pressure of F wheel kPa Dry weight kg Air pressure of R wheel kPa Transmission Type Max payload kg 150kg Speed Ratio of Transmission Genocidal of operation bar... -
Page 18: Statement
Emission Control System Warranty Statement VIII. Wangye USA Co., LLC is pleased to explain the emission control system warranty on Highway Motorcycle. New Highway Motorcycle must be designed, built and equipped to regulations and standards of the United States Environmental Protection Agency and the California Air Resource Board and free from defects in material and workmanship that may keep it from these requirements in the all applicable regulations. - Page 19 Wangye USA, and the above warranty constitutes your sole remedy and the full liability of Wangye USA. In no event shall Wangye USA be liable for special, incidental or consequential damages howsoever caused, whether by negligence or otherwise resulting directly or indirectly from the use of the Motorcycle, or the Motorcycle’s...
