Inverse switch
Switches the between normal and inverse expander modes.
Expander normal mode
Output level
Threshold
Attack/Release/Hold controls
The Expander Section uses the settings of the Attack/Release/Hold controls in the Dynamics Section to control
it's timing.
Equalizer section
A fully parametric five band equalizer. Each band covers the entire frequency range from 20 Hz to 20 kHz (or
higher, depending on the sampling rate of the project) and can be switched between peaking, high or low shelv-
ing and low-pass or high-pass characteristics. Each of the five bands can be switched off. De-activated bands do
not consume DSP power.
EQ Section On/Off
Show/Hide EQ Section
Band Selector
Band Filter Type
Gain Control
Frequency Control
Show/ Hide EQ Section
EQ section on/off
Pre Dynamics Switch
This switch offers the option to the switch the EQ before the dynamics section. By default the EQ is after the
dynamics section.
Graphic Display Window
This small window displays the settings of the currently selected EQ band in blue color and the resulting curve of
the whole EQ section in gray color. You can click and drag directly onto the handles (the small blue or gray points)
of the EQ bands to change the settings within the graph window.
Double-click anywhere in the window to open a bigger version. Please see The Big Graph Window on page 65.
Output level
Input level
Quickstart Guide : Strip and Bus Tools - Plug-ins
Inverse mode
Input level
Threshold
Pre-Dynamics Switch
Graphic Display Window
Selected Band On/Off
Q (Bandwidth) Control
