Fine Jog sensitivity factor [ ]
Sets the fraction of the regular Jog Sensitivity Setting that will be invoked when Fine Jog is selected in the
Machines > Controllers menu

Mouse Scrubbing Settings

There are two possible scrub modes, Analog Tape Mode and Repeat Loop Mode check the appropriate box for
the required mode. The length of the loop in Repeat Loop Mode is related to the base sampling frequency so the
loop will be 116mS long at
Analog Tape Mode gives a similar response to 'reel-rocking' on an analogue tape machine.
Jog anyway
Shuttle when more than 10 [s] is shown in the Timeline
Repeat Loop Mode continuously repeats a short loop starting at the cursor position.

Vari Speed Audio Quality

High when playing less than of equal to [6] track(s)
Best when playing less than or equal to [2] track(s)
MassCore : the varispeed quality is set automatically according to the current core load.
Native and Mykerinos : the playback quality is defined by the playback streams numbers set above.

Scrub Settings

Audio Quality
Offers a choice of Standard or Improved. The higher the quality chosen the greater the CPU load. Default is Stan-
dard.
Improved mode is more demanding in terms of system resources. This setting will be automatically overridden to
Standard mode if more tracks than the number specified in the Max simultaneous tracks field are scrubbed at
the same time.

Fast Speed Settings

F.FWD and REW nominal speed ratio [20]
Type in the box to set the nominal F.FWD and REW speed. (I.e. a value of 20 means 20 times sync play speed)

Transport Controls

The Play Head Cursor or the Timeline will also move in response to the transport control buttons on the strip at
the bottom of the main Pyramix Virtual Studio by Merging Technologies window, or by using the separate
Transport window controls (providing control over the Internal machine is selected). Note that the Transport
Strip disappears when the Transport window is open, and reappears when the window is closed.
From left to right along the Transport strip, the most common controls are as follows:
• The Rewind button moves the Play Head at an accelerated speed backward through the Composition
while it is being pressed.
• The Play Selection button plays the currently selected clip, clips or region.
• The Play button plays the Composition at normal speed forward from the current position of the Play
Head. Play in reverse by holding the Ctrl key while pressing Play.
• The Record button puts Pyramix into Record mode, and creates a new recording to the disk on the Tracks
previously armed for recording. The Play Head moves forward at normal Play speed during the recording.
44.1, 88.2 and 176.4 kHz or 106ms at 48, 96 and 192 kHz.
When lit, Jog Mode is used regardless of how much audio is visi-
ble in the Timeline
When lit, if there is more than 10 seconds of audio visible in the
Timeline scrub will be in Shuttle Mode
Quickstart Guide : Navigation Page 48
