Broan 113023 Instructions Manual

BHOAN
MODEL 113023
WARNING Z_
INTENDEDFOR DOMESTICCOOKINGONLY.
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS,
OBSERVETHE FOLLOWING:
1. Use this unit only in the manner intended by the manufacturer. If you have
questions, contact the manufacturer at the address or telephone number listed
in the warranty.
2. Before servicing or cleaning unit, switch power off at service panel and lock the
service disconnecting means to prevent power from being switched on
accidentally. When the service disconnecting means cannot be locked, securely
fasten a prominent warning device, such as a tag, to the service panel.
3. lnstal[ationworkandelectricelwiringmustbedonebyaqualifiedperson(s) in
accordanqe with all applicable codes and standards, including fire-rated
construction codes and standards.
4. Sufficient air is needed for orocer combustion and _xhsustina nf oases thrmsnh
the flue (chimney) of fuel btJrni'ngequipment to prevent backc/'raft_ng. Foiiowthe
heating equipment manufacturer's guideline and safety standards such as
those published by the National Fire Protection Association (NFPA), and the
American Society for Heating, Refrigeration and Air Conditioning Engineers
(ASHRAE), and the local code authorities.
5. When cutting or drilling into wall or ceiling, do not damage electrical wiring and
other hidden utilities.
6. Ducted fans must always be vented to the outdoors.
7. Do not use this unit with an additional speed control device.
8. To reduce the risk of fire, use only metal ductwork.
9. Use with approved cord-connection kit only.
10. This unit must be grounded.
TO REDUCE THE RISK OF A RANGE TOP GREASE RRE:
1. Neverleavesurfaceunitsunattendedathighsattings. Boiloverscausesmoking
and greasy spillovers that may ignite.
2. Always turn hood ON when cooking at high heat or when cooking flaming foods.
3. Clean ventilating fans frequently, Grease should not be allowed to accumulate
on fan or filler.
4. Use proper pan size. Always use cookware appropriate for the size of the
surface element,
This hood requires installation of a
rough-in plate, ductwork and elec-
trical wiring before installing hood.
Refer to the instruction sheet packed
with the rough-in plate.
WARNING Z_ Z_k
TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A RANGE TOP
GREASE FIRE, OBSERVE THE FOLLOWING:
1. SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal tray, turn off
the burner. BE CAREFUL TO PREVENT BURNS. If the flames do not go out
immediately, EVACUATEAND CALLTHE FIRE DEPARTMENT
2. NEVER PICK UP A FLAMING PAN - You may be burned.
3. DO NOT USE WATER, including wet dishcloths or towels - a Violent stream
explosion will result,
4. Use an extinguisher ONLY if:
A, You know you a Class ABC extinguisher and you already know how to
operate it.
B. The lire is small and contained in the area where it started.
C. The fire department isbeing ca!!ed.
D. You can fightthe fire withyour back to an exit.
*Based on "Kitchen Firesalety Tips" published by NFPA.
CAUTION
1. Forgeneralventilating useonly. Donot use to exhaust hazardous or explosive
materials and vapors.
2. To avoid motor bearing damage and noisy/and or unbalanced impellers, keep
drywall spray, construction dust, etc. off power unit.
3. For best capture of cooking impurities, your range hood should be mounted
18-24" above the cocking surface.
4. This product is equipped with a thermostat which may start fan automatically.
To reduce the risk of injury, switch power off at service panel and lock service
panel to prevent power from being switch on accidentally.
5. Your hood motor has thermal overload which will automatically shut off the
motor if it becomes overheated. The motor will restart when it cools down. If
the motor continues to shut and restart, have the hood serviced.
6, Please read specification label on product for further information and
requirements.
IRK
This hood is shipped set up for cabinets
which are 30" high. It can be adjusted in 1"
increments from 30" down to 24" high.
SHIPPED
FACE FRAME & DOORS
(provided by installer)
J
(ADJUSTABLE)
INSTALLER: Leave this manual with the homeowner.
HOMEOWNER: Use and care information on page 5,
