Table of Contents

Important Safety Information
Service Information
Introduction
M4 Series Key Features
M4 Series Technical Specifications
Unpacking and Installing
Front Panel Controls and Indicators
M4 Series Operating Description
Sample VFD Displays
Performance Loss Monitor
M4.2R Ethernet Port Setup
Three Year Warranty
M4 Firmware v4.0.9 and v4.2.9 - New Features
• Added M4.2R with Performance Loss Monitor (PLM, including 6 dry-contact alarm relay
closures), full-time digital audio output, Ethernet remote port and RBDS decoding
• Eliminated "Standby at Turn-on" feature and improved brown-out performance
• Number of AM and FM Presets doubled from 10 to 20 for each band
•
Capability to store Multicast stations as FM Presets
• Multicast Set feature to keep tuner continuously monitoring selected HD-2 through HD-8
channel
•
iBiquity multicast PSD patch addresses importer cross-porting
• New "Scrolling Data" mode sequentially displays selected HD Radio
fields
•
Displays HD-1 for MPS channel modem lock in VFD
• New DATA-DISPLAY menu with firmware version, scrolling data and muting options
• Redesigned user interface for MPS, Multicast and Forced Analog modes
•
Support for optional M4.0X Performance Loss Monitor (PLM) with 6 alarms
All rights reserved ATI Group Inc. Copyright 2007.
All logos and trademark used herein are the property of their respective owners.
Specifications subject to change.
M4.0 Revision K.
