DaySequerra M4 Series User Manual page 13

Alarm Output 3 – OFDM Lock Loss (HD Radio
•
Highlight desired "SET" or "OFF" option using UP and DN switches to toggle the
setting. Select "SET" to set this tuner alarm and continue with alarm configuration
menu; select "OFF" to set this tuner alarm function to off. Push "SELECT" to
continue.
O F D
> S E
•
If "SET" is selected, submenu for "Alarm Delay" with "30", "60", "120" and "240"
second options is displayed next. Use UP and DN switches to toggle the setting and
highlight the desired option.
A L
3 0 >
Push "SELECT" switch to save and increment the menu to the next alarm function.
Alarm Output 4 – RBDS Data Loss (alarm based on data appearing in Radio Text field; available
in M4.2R model only)
Alarm Output 5 – HD Radio
does not mean data is valid)
•
Highlight desired "SET" or "OFF" option using UP and DN switches to toggle the
setting. Select "SET" to set this tuner alarm and continue with alarm configuration
menu; select "OFF" to set this tuner alarm function to off. Push "SELECT" to
continue.
P A
> S E
•
If "SET" is selected, submenu for "Alarm Delay" with "30", "60", "120" and "240"
second options is displayed next. Use UP and DN switches to toggle the setting and
highlight the desired option.
A L
3 0 >
Push "SELECT" switch to save and increment the menu to the next alarm function.
M L O
T <
A R M
6 0 < 1
TM
PAD Loss (alarm based on data appearing song title field only,
D D A
T <
A R M
6 0 < 1
TM
modem lock)
C K L
O
D E L
2 0 2
T A L
O
D E L
2 0 2
O S S
F F
A Y
4 0 S
O S S
F F
A Y
4 0 S
M4 User Manual
13
