Introduction
- Support BIOS adjustable CPU Core voltage, Chipset voltage and DIMM voltage
Support Thermo Stick temperature (Optional)
Support Ghost BIOS - Rescue, recover BIOS in an easy step and no more worry of BIOS
being corrupted.
Powerful utilities for Windows
Support Thunder Probe - A hardware diagnostic software to monitor voltage, temperature
and speed of a variety of hardware. It also includes an ingenious built in fan control feature
called Smart Fan.
Support Thunder Flash - A Windows based innovation tool to provide safe and easy BIOS
rescue function, BIOS flash function and personal start up screen.
Form Factor
305mm x 245 mm ATX size
Supported Operating System
Windows 2000, Windows XP
Depending on the model you purchased, some components are optional and may
not be available.

1-4 System Block Diagram
