User Manual for your
BYHG604.5SS / BYHG610.5SS
NOTE
:
This
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
60 cm 4 Burner gas hob
BYHG710.5SS
70 cm 5 Burner gas hob
User
Instruction
JW 18/05/12
Manual
contains
important
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HomeKing BYHG604.5SS
Summary of Contents for HomeKing BYHG604.5SS
- Page 1 User Manual for your BYHG604.5SS / BYHG610.5SS 60 cm 4 Burner gas hob BYHG710.5SS 70 cm 5 Burner gas hob NOTE This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...
-
Page 2: Table Of Contents
Contents Environmental note Important safety information Specifications BYHG604.5SS BYHG610.5SS BYHG710.5SS Electrical details Gas details Using the gas hob 11-13 Before first use The gas hob Automatic ignition with flame failure safety device Energy saving tips Cleaning 14-15 Cleaning the hob top... -
Page 3: Environmental Note
Environmental note o The packaging materials that the manufacturer uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. -
Page 4: Important Safety Information
Important safety information Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Customer Care Department. - Page 5 hild Safety o We strongly recommend that babies and young children are prevented from being near to the appliance and not allowed to touch the appliance at any time. During and after use, all surfaces will be hot. o If it is necessary for younger family members to be in the kitchen, plea se ensure that they are kept under close supervision at all times.
- Page 6 o Great care should be taken whilst using this appliance and when following the cleaning procedure. o You should not use a steam jet or any other high pressure cleaning equipment to clean the appliance. Installation This appliance must be correctly installed by a GASSAFE registered installer,...
-
Page 7: Specifications
– BYHG604.5SS/W Product dimens ons: Aperture dimensions: Depth: 510 mm epth: 480 mm Width: 620 mm idth: 560 mm Height: 50 mm Product specifications: o 1 x 3.00 kW rapid burner o 2 x 1.75 kW semi-rapid burne o 1 x 1.00 kW auxiliary bu... -
Page 8: Byhg610.5Ss
pecifications – BYHG610.5SS Product dimensions: Aperture dimensions: Depth: 510 mm Depth: 480 mm Width: 620 mm idth: 560 mm Height: 50 mm Product specifications: o 2 x 1.75 kW semi-rapid burner 1 x 1.00 kW auxiliary burner o 1 x 3.50 kW triple crown (wok) b urner Front control operation o Heavy duty cast iron pan stands... -
Page 9: Byhg710.5Ss
Specifications – BYHG710.5SS Product dimensions: Aperture dimensions: Depth: 510 mm Depth: 480 mm Width: 720 mm Width: 560 mm Height: 50 mm Product specifications: o 1 x 3.00 kW rapid burner o 2 x 1.75 kW semi-rapid burners o 1 x 1.00 kW auxiliary burner o 1 x 3.50 kW triple crown (wok) burner o Front control operation o Heavy duty cast iron pan stands... -
Page 10: Electrical Details
Electrical details Rated Voltage: 230 Vac 50 Hz Supply Connection: 3A (double pole switched fused outlet with 3mm contact gap) Mains Supply Lead: 3 core x 1.5 mm² Gas details Connection: Rp ½ (ISO R7) Type: Natural Gas (20 mbar) Alternative LPG G30 (28-30/37 mbar) For future reference please record the following information which can be found on the rating plate and the date of purchase which can be... -
Page 11: Using The Gas Hob
Using the gas hob Before first use IMPORTANT: You should clean the hob surface (see “Cleaning and maintenance” section). The gas hob The following symbols will appear on the control panel, next to each control knob: Circle: gas off Large flame: maximum setting / ignition position Small flame: minimum setting o The minimum setting is at the end of the anti-clockwise rotation of the control knob. -
Page 12: Automatic Ignition With Flame Failure Safety Device
Automatic ignition with flame failure safety device The appliance is fitted with a flame failure safety device on each burner, which is designed to stop the flow of gas to the burner head in the event of the flame going out. To ignite a burner: o Press in the control knob of the burner that you wish to light and turn it anti-clockwise to the maximum position. -
Page 13: Energy Saving Tips
Energy saving tips Burners Pan size Ø min Ø max 200 mm 320 mm Rapid 200 mm 260 mm Semi-rapid 140 mm 200 mm Auxiliary 100 mm 140 mm o The diameter of the bottom of the pan should correspond to that of the burner. -
Page 14: Cleaning
Cleaning Cleaning operations must only be carried out when the hob is cool. The appliance should be disconnected from your mains supply before commencing any cleaning process. Cleaning the hob top Any residues that are left on the hob top surface from cleaning agents will damage it. -
Page 15: Maintaining The Pan Stands
IMPORTANT: Make sure that you reassemble the burners in the original way. Maintaining the enamelled pan stands (BYHG604.5SS) o IMPORTANT: Make sure that the hob surface and pan stands have cooled before you attempt to touch them. o Wipe the pan stands over with a soft, damp cloth that has been put into warm soapy water. -
Page 16: Installation
Installation The installation must be carried out by a GASSAFE registered installer, in accordance with the current version of the following. o Gas Safety Regulations (Installation & Use) o Building Regulations (issued by the Department of Environment) o Building Standards (Issued Scottish Development... -
Page 17: Positioning
Positioning The adjacent furniture must be able to withstand a minimum temperature rise of 85°C above the ambient temperature of the room it is located in, during periods of use. o This appliance can be located in a kitchen, a kitchen diner or a sitting room. -
Page 18: Unpacking The Appliance
Self-adhesive label for amending the gas category on the appliance’s rating plate (required if the LPG conversion jets are used). Installing the appliance o Cut a hole in the worktop that corresponds with the correct model drawing below: BYHG604.5SS BYHG610.5SS BYHG710.5SS... - Page 19 o Carefully turn the hob upside down and place it on a cushioned mat. o Apply the sealing strip provided around the edge of the appliance. o The protective covering must be removed from both sides. o Do not leave a gap in the sealing agent or overlap the thickness. o IMPORTANT: Do not use a silicon sealant to seal the appliance against the aperture.
-
Page 20: Gas Connection
o On the underneath of the hob, adjust the clamps into a position that is suitable for your worktop. Then fully tighten the screws (C) to secure the hob into position. Gas connection This appliance must be installed by a competent person in accordance with the current versions of the following UK (United Kingdom) or ROI (Republic of Ireland) Regulations and Safety Standards or... -
Page 21: Ventilation Requirements
Ventilation requirements o The room containing the hob should have an air supply in accordance with the current edition of BS 5440: Part 2: o The room must have opening windows or equivalent; some rooms may also require a permanent vent. o If the room has a volume between 5 and 10m³, it will require an air vent of 50cm²... -
Page 22: Gas Safety (Installation And Use) Regulations
Gas Safety (Installation and Use) Regulations IMPORTANT: The appliance MUST be connected to the gas supply by use of a ½ BSP Elbow, seal, copper pipe and an isolation tap fitted in an easily accessible position. o It is the law that all gas appliances are installed by competent persons in accordance with the current edition of the Gas Safety Installation and Use Regulations. -
Page 23: Gas Adjustment (Conversion To Lpg)
Gas adjustment (Conversion to LPG) work must carried GASSAFE registered engineer. IMPORTANT: Always isolate the hob from the electricity supply before changing the injectors and/or adjusting the minimum flow of the burners. o Remove pan-stands, burners flame spreaders (A). o Unscrew the injector (B) and replace it with the stipulated injector for the new gas supply (see the table on the next page). -
Page 24: Minimum Flow Adjustment For Hob Gas Taps
Minimum flow adjustment for hob gas taps. work must carried GASSAFE registered engineer. IMPORTANT: Always isolate the hob from the electricity supply before changing the injectors and/or adjusting the minimum flow of the burners. o Switch the burner on and set the knob at the minimum position. o Remove the knob from the tap and place a small bladed screwdriver in the centre of the tap shaft. - Page 25 IMPORTANT: Before carrying out any maintenance operations, disconnect the appliance from the gas and electricity supplies. If a gas tap becomes stiff to operate, then you should proceed as follows: o Remove the control knobs, pan supports, burners, hob fixing screws and clamps.
-
Page 26: Electrical Connection
Electrical connection This appliance must be installed by a qualified person in accordance with the latest edition of the I.E.E. Regulations compliance with manufacturer’s instructions. Before connecting the appliance, make sure that the supply voltage marked on the rating plate corresponds with your mains supply voltage. -
Page 27: My Appliance Isn't Working Correctly
My appliance isn’t working correctly IMPORTANT: If your appliance appears not to be operating correctly, then you should disconnect it from your mains supply and then contact the Customer Care Department on telephone number (0118) 933 6911. DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF. Please note that if an engineer is asked to attend whilst the product is under guarantee and finds that the problem is not the result of an appliance fault, then you may be liable for the cost of the call out... -
Page 28: Contact Details
United Kingdom 6 Bennet Road, Reading, Berkshire RG2 0QX United Kingdom Customer Care (0118) 933 6918...
