HomeKing BHC609 User Manual

60 cm front touch control 4 zone ceramic hob
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual for your Homeking
BHC609
60 cm Front touch control
4 zone ceramic hob
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
JW 26/02/13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BHC609 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HomeKing BHC609

Summary of Contents for HomeKing BHC609

  • Page 1 User Manual for your Homeking BHC609 60 cm Front touch control 4 zone ceramic hob NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...

  • Page 2: Table Of Contents

    Contents Environmental note Important safety information 5 – 8 Specifications 8 – 10 Product and aperture dimensions Product specifications Electrical details Ceramic hob surface layout Control panel layout Using the ceramic hob 10 - 13 Before first use Touch controls Switching the hob on Switching on a cooking zone and setting a power level Switching off a cooking zone gradually...

  • Page 3: Environmental Note

    Environmental note o The packaging materials that Homeking uses environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment.

  • Page 4: Important Safety Information

    Important safety information Your safety is of the utmost importance to Homeking. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this ooklet, please contact the Advice Line.
  • Page 5 Child Safety o Homeking strongly recommend that babies and young children are prevented from being near to the appliance and not allowed to touch the applianc e at any time. During and after use, all surfaces will become hot. o If it is necessary for younger family members to be in the kitchen,...
  • Page 6 o Great care should be taken whilst using this appliance and when following the cleaning procedure. o You should not use a steam jet or any other high pressure cleaning equipment to clean the appliance. Installation This appliance must be correctly installed by a suitably qualified person, strictly...

  • Page 7: Specifications

    Specifications Product dimensions Aperture dimensions Depth: 520 mm Depth: 485 mm Width: 590 mm Width: 560 mm Height: 46 mm Product specifications: o 1 x 2.30 kW zone (Ø 230 mm) o 1 x 1.80 kW zone (Ø 180 mm) o 2 x 1.20 kW zones (Ø...

  • Page 8: Electrical Details

    lectrical details Rated Voltage: 220-240 Vac 50-60 Hz Supply Connection: 30 A (double pole switched f used outlet w ith 3mm contact gap) Max Rated Inputs: 6.5 kW ains Supply Lead: 3 core x 6 mm² (not supplied) For future reference please record the following information which can be found on the rating plate and the date of purchase which can be found on your sales invoice.

  • Page 9: Control Panel Layout

    ontrol panel layout On/Off button Cooking zone selection button (x 4 Cooking zone minus button (x 1 Cooking zone plus button (x 4) Cooking zone temperature display (x 4) sing the ceramic hob Before first use IMPORTANT: You should clean the ce ramic hob surface (see “...

  • Page 10: Touch Controls

    ouch controls o All operations are performed by m eans of the touch controls that can be found on the control panel. Each touch control has a visual display that corresponds to it. Every time you press a touch control, an acoustic signal will sound. Switching the hob on Press the ON/OFF button (1) The LED above the On/Off button will illuminate.

  • Page 11: Switching The Hob Off

    witching the hob off Once you hav e switched off all of the cooking zones, you should switch off the hob. Press the ON/OFF button (1). o It is possible to swi tch the hob off at any time by pressing the ON/OFF button (1).

  • Page 12: Hob Guidelines

    Especially if pointed or hard objects are allowed to fall on it with some force. o DO NOT USE THE HOB IF THE SURFACE BECOMES BROKEN CRACKED. SHOULD CONTACT HOMEKING CUSTOMER CARE DEPARTMEN T IMMEDIATELY.

  • Page 13: Cleaning And Maintenance

    Cleaning and maintenance Cleaning operations must only be carried out when the hob is cool. The appliance should be disconnected from you r mains supply before commencing any cl eaning process. Cleaning the ceramic hob top Any residues that are left on the hob top surface from cleaning agents will damage it.

  • Page 14: Using A Ceramic Hob Scraper

    sing a ceramic hob scraper The following guidelines should be followed when using a ceramic hob craper (not supplied):- o The scraper should be placed on the ceramic surface at an angle. o Residues should be r emoved by sliding the blade carefully over the ceramic surface.

  • Page 15: Positioning

    ositioning The adjacent furniture must be able to withstand a minimum temperature rise of 85°C above the ambient temperature of the room it is located in, during periods of use. This appliance is classified as Class 3 and therefore is to be built into a kitchen unit (depending on size) or 600 mm worktop that is at least 30 mm thick.

  • Page 16: Installing The Appliance

    nstalling the appliance o Cut a hole in the work top that corresponds with the relevant drawing shown above. o IMPORTANT: You must obs erve the ventilation requirements shown in the drawing above.
  • Page 17 o IMPORTANT: There are ventilation holes around the outside of the hob. YOU MUST ensure that these holes are not blocked by the work top, when you put th e hob into position (see drawing opposite). o NOTE: Your appliance comes fitted with a sealing strip already attached to the underside of the hob.

  • Page 18: Electrical Connection

    Electrical connection This appliance must be installed by a qualified person in accordance with the latest edition of the I.E.E. Regulations compliance with omeking’s instructions. Before connecting the appliance, make sure that the supply voltage marked o n the rating plate corresponds with your mains supply oltage.
  • Page 19 o The cable connections must be in accordance with the diagram located on the bottom of the hob (see above). The links must also be positioned as indicated. o You should use a good quality screwdriver to carefully, fully tighten ALL of the terminal screws. o If when the hob is first switched on, only two of the zones work, you should recheck that the terminal screws are all fully tightened and the links are in position.

  • Page 20: Replacing The Mains Supply Cable

    Replacing the mains supply cable If the mains supply cable is damaged, then it must be replaced by an appropriate replacement. The mains supply cable should be replaced in accordance with the following instructions: o Switch the appliance off at the socket. o Open the terminal block on the underside of the hob.

  • Page 21: My Appliance Isn't Working Correctly

    My appliance isn’t working correctly o The cooking zones are not functioning or will not switch on. * It has been more than 1 minute since the appliance was switched You should switch the appliance back on again, using the ON/OFF button and then switch on a cooking zone.
  • Page 22 Homeking Advice Line. DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF. Please note that if an engineer is asked to attend whilst the product is under guarantee and finds that the problem is not the result of an appliance fault, then you may be liable for the cost of the call out charge.

  • Page 23: Contact Details

    Homeking Homeking 6 Bennet Road, Reading, Berkshire RG2 0QX, United Kingdom Sales Telephone 0118 933 6900 Sales Fax 0118 931 0035 Service Telephone 0118 933 6911 Service Fax 0118 986 9124 Spares Telephone 01235 437244 Advice Line Telephone 0118 933 6911...
