PREMIERE WHIRLPOOL
THANK YOU...
for selecting an Eljer bathing product. Your new bath is shipped to you after careful inspection. The whirlpool
version is completely assembled with pump and circulatory system piping. All you need to finish the installation
are your selected fittings, electrical connections and support bedding material.
To ensure maximum performance and pleasure from this product, please follow the instructions and cautions.
For questions or service issues, please call Technical Support 1-(800)-442-1902.
Please do not contact or return product to the store.
© Eljer 2011
All product names listed herein are trademarks of Eljer unless otherwise noted.
INSTALLATION AND
OPERATION MANUAL
MODEL NUMBERS
015-0005, 015-0015, 015-0026,
015-0066, 015-0076, 015-0077 ,
015-0305, 015-0309
1
754764-100
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Eljer 015-0005
Summary of Contents for Eljer 015-0005
-
Page 1: Cover
015-0305, 015-0309 THANK YOU... for selecting an Eljer bathing product. Your new bath is shipped to you after careful inspection. The whirlpool version is completely assembled with pump and circulatory system piping. All you need to finish the installation are your selected fittings, electrical connections and support bedding material. -
Page 2: Table Of Contents
TABLE OF CONTENTS: Cover....................Page 1 Table of Contents................Page 2 Safety Instructions Notice..............Page 3 Installation, Framing and Post Installation Clean-Up Instructions...............Page 4 Typical Flange & Under Deck Mounting Instructions......Page 6 General Specifications for Whirlpools..........Page 7 Roughing-in References for All Model Series........Pages 8 - 10 Electrical Installation Instructions.............Page 11 Total Massage Whirlpools..............Page 12 Operating Instructions...............Page 13... -
Page 3: Safety Instructions Notice
IMPORTANT SAFETY INSTRUCTIONS INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK OR INJURY TO PERSONS READ AND FOLLOW ALL INSTRUCTIONS! WARNING: Risk of personal injury. Do not permit children to use this unit without adult supervision. WARNING: Risk of personal injury. Do not operate this unit without the guard over the suction fitting. -
Page 4: Installation, Framing And Post Installation Clean-Up Instructions
Installation and Framing Instructions Each bath arrives ready for installation, completely equipped with the pump and plumbing necessary for operation. However, a drain/overflow kit is required for each bath and it is not included. The variety of installations for this bath may require framing procedures other than those shown. Locate studs as required. - Page 5 SEALANT (610 mm) BE SUPPORTED BY STUD WALL OR ACCESS PANEL MUST BE LOCATED ELJER APRON KIT ON THE SAME SIDE AS THE MOTOR. ACCESS PANEL MUST BE LOCATED BATH ON THE SAME SIDE AS THE MOTOR. ALLOW OPEN FRAMING ON PUMP/MOTOR END FOR SERVICE.
-
Page 6: Typical Flange & Under Deck Mounting Instructions
TYPICAL FLANGE MOUNTING DETAIL SUGGESTED WHIRLPOOL / BATH TYPICAL INSTALLATION - INSTALLATION METHOD CORNER WOOD STUD STUDS WATERPROOF DRYWALL OR CEMENT BOARD TILE ROOFING NAIL 58-1/2" 58-1/2" SEALANT (1486mm) (1486mm) LEVELING 12" STRINGER (305mm) 1 x 3 (25 x 76mm) WOOD STRINGER FULL LENGTH STEEL STEEL... -
Page 7: General Specifications For Whirlpools
Water / Floor Weight Overflow of Deck: C G x F E x D Overflow: J Loading L 60" (1524mm) 015-0005 C 17" 58-1/2" 60" 2-1/4" 418 lb. (190 kg)/ 98 lb. A 15-1/4" W 32" (813mm) 5' x 32"... -
Page 8: Roughing-In References For All Model Series
ROUGH-IN REFERENCES CYPRESS MODEL 015-0005 60" (1524mm) 16" (406mm) 40-1/2" (1029mm) 32" 19-1/2" (813mm) (495mm) 9" x 14" (229 x 356mm) FLOOR CUTOUT PROVIDE ACCESS TO PUMP SERVING ON ALL INSTALLATIONS 10-1/4" (260mm) MADISON MODEL 015-0015 60" (1524mm) 16" (406mm) 40-1/2"... - Page 9 ROUGH-IN REFERENCES CANTERBURY MODEL 015-0026 60" (1524mm) 18" (457mm) 44-1/2" 36" (1130mm) (914mm) 24-1/2" (622mm) 9" x 14" (229 x 356mm) FLOOR CUTOUT PROVIDE ACCESS 10-1/4" TO PUMP (260mm) SERVING ON ALL INSTALLATIONS TRIANGLE MODEL 015-0066 35-1/2" (902mm) 60" (1524mm) PROVIDE ACCESS TO PUMP SERVING ON...
- Page 10 ROUGH-IN REFERENCES EMBLEM MODEL 015-0076 EMBLEM TOTAL MASSAGE MODEL 015-0077 72" (1829mm) 18" (457mm) 51-1/2" (1308mm) 36" 21-1/2" (914mm) (546mm) 9" x 14" (229 x 356mm) FLOOR CUTOUT PROVIDE ACCESS TO PUMP SERVING ON ALL INSTALLATIONS 10-1/2" (267mm) PATRIOT MODEL 015-0309/0305 (Right hand version shown) 60"...
-
Page 11: Electrical Installation Instructions
ELECTRICAL INSTALLATION INSTRUCTIONS All wiring must be performed by a licensed electrician in accordance with the national electrical code and all other applicable codes. WARNING: When using electrical products, basic precautions should always be observed, including the following: 1. DANGER: RISK OF ELECTRIC SHOCK Connect only to a circuit protected by a ground-fault circuit interrupter. -
Page 12: Total Massage Whirlpools
ELECTRICAL INSTALLATION INSTRUCTIONS (continued) TOTAL MASSAGE WHIRLPOOLS The whirlpool pump and blower should be installed on a 120 vac, 20 amp dedicated circuit. The circuit should be hard-wired from the electrical power supply panel. The circuit must be a three (3) wire circuit from the electrical supply panel. -
Page 13: Automatic Cleaning And Purge Cycle
OPERATING INSTRUCTIONS 1. Fill the bath to at least 3 inches above the jets before activating the pump. 2. The pump is activated by an on/off switch. Each depression of the button switches the power either on or off. Do not repeatedly depress the switch in rapid order if you do not see the whirlpool function right away, as it may take a few seconds before you can see it fully operating. -
Page 14: Cleaning And Maintenance
Your new acrylic bathtub is tough, durable and easy to care for. The colors have been formulated to match other Eljer fixtures and enhance your choice of bathroom decorations. The high gloss surface will retain its lasting luster with proper care and maintenance. -
Page 15: Warranty
AS AMERICA, INC. LIMITED LIFETIME WARRANTY FOR ELJER PREMIERE SERIES ACRYLIC TUBS AS America, Inc. (“American Standard”) warrants to the original consumer purchaser that it will, at its option, repair or replace this tub or any of its parts that are found by American Standard, in its sole judgment, to be defective under normal residential use and maintenance so long as it is owned by the original consumer purchaser.
