BUILDER SERIES
Midland Whirlpool (015-2245). Bath waste not included.
Soaker Tub model also available.
NOTE:
Eljer assumes no responsibility or liability for local or state
regulations which deviate from national standards. It shall
be the responsibility of the installer to comply with local
codes and standards prior to installation of any Eljer product.
Electrical Requirements:
115V, 20AMP, GFCI Protected Circuit
71-3/4"
(1822)
41-1/2"
(1054)
Water Capacity to Overflow: 87 gal.
Whirlpools/Tubs
Midland Whirlpool/Tub
46"
(1168)
25"
(635)
20-3/4"
(527)
9-3/4"
(248)
23"
(584)
58-1/2"
(1486)
HIGH GLOSS ACRYLIC
71 3/4" (1822 mm) Length, 41 1/2" (1054 mm) Width,
23" (584 mm) Height
Six Jetted Multi-Directional Whirlpool System
Oval Drop In Unit
2HP Pump Motor
Pre-Leveled Base for Ease of Installation
Safety Suction Fitting
Trim and Jets Removable and Top Rack Dishwasher Safe
Optional Inline Heater Available
Available in White, Platinum, Onyx, Natural, and Biscuit
Operating Water Capacity 45 Gallons
Weight - Empty 147 lbs., with Water 522 lbs., Cubes 49.62
015-2245
Six Jet Whirlpool Bath Complete with
Color-Matched Whirlpool Trim, 2 HP
Motor, Less Bath Waste
Whirlpool Trim Includes:
Color-Matched Whirlpool Jets
Color-Matched Air Controls (2)
Whirlpool-Mounted On/Off Air Switch
Color-Matched Suction Return Cover
Optional Metallic Trim Kits:
494-3000
Polished Chrome
494-3005
Polished Brass
Optional In-Line Heater: (Factory Installed Only)
494-1550
Factory Installed In-Line Heater,
Maintains Bathing Water Temperature
Note: Extended Lead Time Applies to Whirlpools Ordered
with In-Line Heater
Soaker Tub Model:
015-2250
Non-Jetted Acrylic Bath, Less Bath Waste
Empty Weight: 112 lbs.
2"
(51)
"
31
(787)
FAUCETS ARE NOT INCLUDED. ALL FIXTURE DIMENSIONS ARE NOMINAL AND
MAY VARY WITHIN THE RANGE OF TOLERANCES ESTABLISHED BY ASME/ANSI
STANDARDS, Z124.1. ALL MEASUREMENTS SHOWN ARE SUBJECT TO CHANGE
OR CANCELLATION.
Eljer, Inc. 5/06
2-1/4" (57)
