Eljer Marco 3660IS Specification Sheet

LUXURY SERIES
Marco 3660IS Whirlpool (015-0448) Shown with
Optional Metallic Trim. Bath waste not included.
All components are UL listed and approved.
Electrical Specifications: 115V, 20 AMP, GFCI Protected
Circuit. Additional identical circuit required with
installed heater. If optional electronic on/off is
installed, a 120VAC, 20 AMP, GFCI dedicated circuit is
required.
Water Capacity to Overflow: 58 gal.
36"
19"
(914)
(483)
18"
(457)
10"
(254)
NOTE: Eljer assumes no responsibility or liability for local or state
regulations which deviate from national standards. It shall
be the responsibility of the installer to comply with local
codes and standards prior to installation of any Eljer product.
Whirlpools/Tubs 1.67
Marco 3660IS Whirlpool
59-3/4"
(1518)
37"
(940)
21-1/2"
HIGH GLOSS ACRYLIC
59-3/4" (1518 mm) Length, 36" (914 mm) Width,
21-1/2" (546 mm) Height - 200 lbs., Cubes 37
Six Jetted Multi-Directional Whirlpool System
Rectangular Unit with Integral Arm Rests
Integral Apron/Skirt with Removable Access Panel
Integral Tiling Flange
14" Pillow included for Bathing Comfort
2HP Pump Motor 1 phase, 115V, 60HZ, 3450 RPM
Pre-Leveled FRP Base for Ease of Installation
Dual Air Volume Controls
Safety Suction Fitting
Trim and Jets Removable and Top Rack Dishwasher Safe
Optional Inline Heater Available
Water Capacity at Operating Level - 44 Gallons
Weight - Empty 135 lbs., with Water 502 lbs.
_______________________________________________________
015-0448
015-0444
015-0446
015-0447
Optional Metallic Whirlpool Trim Kits:
494-3000
494-3005
494-3025
494-3035
Other Options (Factory Installed Only):
494-1550
494-1400
494-1700
494-1800
494-1900
5-1/2"
1-1-4" (32) Flange
(140)
Three Sides
+ Skirt
(546)
FAUCETS ARE NOT INCLUDED. ALL FIXTURE DIMENSIONS ARE NOMINAL AND
MAY VARY WITHIN THE RANGE OF TOLERANCES ESTABLISHED BY ASME/ANSI
STANDARDS, Z124.1. ALL MEASUREMENTS SHOWN ARE SUBJECT TO CHANGE
OR CANCELLATION.
Eljer, Inc. 9/06
Six Jet Whirlpool Bath Complete with
Color-Matched* Whirlpool Trim, 2 HP
Motor, Less Bath Waste
Six Jet Whirlpool Bath and Soft Air
Bubbler System Complete with Color-
Matched* Whirlpool Trim, One 2 HP
Motor, One 2 HP Blower, Less Bath Waste
Six Jet Whirlpool Bath with Aqua-Therapy
Back Massage Jets Complete with Color-
Matched* Whirlpool Trim, One 2 HP
Motor, One 3/4 HP Motor, Less Bath Waste
Six Jet Whirlpool Bath with Both
Aqua-Therapy Back Massage and
Soft-Air TM Bubbler System Complete
with Color-Matched* Whirlpool Trim, One
2 HP Motor, One 2 HP Blower, Less Bath
Waste
Polished Chrome
Polished Brass
Brushed Nickel
Oil Rubbed Bronze
Factory Installed In-Line Heater,
Maintains Bathing Water Temperature
Neck Massage Pillow
Electronic Control Panel
Ozonator Whirlpool Sanitation System
Underwater Light Package
*
Trim for Whirlpool, Soft Air
Aqua-Therapy Back Massage will be
Color-Matched on White, Natural/Bone,
Biscuit, Platinum, and Onyx Units.
Chrome Trim Standard on Units of all
other Colors.
Whirlpool Trim includes: whirlpool jets,
air controls (2), on/off button, and suc-
tion return cover.
TM
and
TM
