- Page 1 WINDOW TYPE ROOM AIR CONDITIONER HW-09LM03 HW-12LM03 HW-09LMA03 HW-12LMA03 No.0010515698...
-
Page 2: Table Of Contents
C/26 Outdoor Minimum: 2. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similar qualified person. 3. After installation, the power plug should be easily reached. 4. The wiring method should be in line with the local wiring standard. -
Page 3: Parts Name
Parts Name Machine body Front panel Air inlet (indoor side) Machine body Air outlet (indoor side) Air inlet (outdoor side) Display panel Power plug Air filter (inside) Operation panel HIGH HIGH COOL COOL WAIT THREE MINUTES BEFORE RESTARTING... -
Page 4: Operation Guide
Hint When the mode selection switch is turned to "HIGH FAN" or " LOW FAN" , the air conditioner will only blow out air without cooling. I f the mode selection switch is turned from cooling mode to fan mode, do not turn it back until at least 3 minutes have elapsed. - Page 5 ON position. Note: It is advisable not to keep horizontal flap at downward position for a long time in COOL or FAN mode, otherwise , condensate water might occur. Don't move the vertical blade with hand in order to avoid the vertical blade abnormal, using the remote controller to adjust the move of vertical blade.
-
Page 6: Maintenance
Air filter cleaning (before cleaning, turn off the power) When dirt accumulates on air filter, air circulation will be blocked, which causes poor cooling. It is advisable to clean air filter every two weeks for longer operation. Take out the air filter 1.Pull the raised parts on both sides at... - Page 7 (See Fig.1 ) In this method, the accumulated condensed water in the bottom plate is hit by the fan onto the heat exchanger, and evaporated and blown out from the machine.
- Page 8 Maintenance Don't be exposed to cold air for Avoid opening doors and windows a long time. unless necessary. Use curtain or blind Keep heat source away from Direct sunlight may reduce cooling air conditioner. effect, always use window curtain. After unit stops, don't restart it Set temp .
-
Page 9: Troubleshooting
Are there any obstacles blocking air inlet and outlet? Is air filter clogged? Remove the heat source Is there too much heat source in the room? If problems can not be solved please pull out power plug and contact your dealer. -
Page 10: Installation Instructions
Avoid places where flammable gas leaks. Problems may occur if unit is installed in the following places: Place where oil exists in the air including engine oil or seaside with salt breeze blows and hot spring area with sulphurous gas in the air. -
Page 11: Installation Guide
(As illustrated in Fig. 1). 2. For the convenience of operation, it is recommended that air-conditioner be installed at least at the height of 760-1300 mm above the floor and no obstacles before it for a free airflow. - Page 12 Installation Guide MODEL HW-09LM03 366mm 481mm HW-09LMA03 HW-12LM03 392mm 610mm HW-12LMA03 outlet pipe fitting outlet pipe fitting outlet pipe fitting...
-
Page 13: Wiring Diagram
4.4/6.9 531X471X356 29.5 980/1500 9000 4.8/6.9 HW-09LMA03 531X471X356 29.5 12000 HW-12LM03 1250/1600 6.5/8.5 560X600X382 HW-12LMA03 12000 1300/1600 6.5/8.5 560X600X382 Note: All capacities are gross. Haier THERMOCOOL reserves the right to change specifications as part of its policy of continuous improvement. - Page 14 With 3 years warranty on all air- conditioner compressors, you have peace of mind from the date of purchase NATIONWIDE SALES AND SERVICES MINNA,ILORIN,OSHOGBO,LOKOJA, sales office 2719790...
