- Page 1 User Guide...
- Page 2 Cigarette Lighter Adapter 103-0614-00 ___________________________________________________________________________ Copilot Xmit Cable * 103-0027-00 For iNova use only ___________________________________________________________________________ Aux. Input Cable 103-0613-00 Stereo Patch Cord ___________________________________________________________________________ 103-0604-00 PTT Gold ___________________________________________________________________________ 9 volt Battery *Warning: This cable is NOT compatible with other Flightcom products!
- Page 3 Most people choose to operate the iNova using battery power. * To install the 9 volt battery open the door on the bottom of the iNova and drop the battery in following the positioning diagram inside the door. * The iNova has an auto on/off feature. Plug in the pilot or copilot headset and the intercom is on.
- Page 4 Insert the 5.2 mm plug from the intercom into the aircraft microphone jack. Note: There is no “off/on” control on your iNova intercom. The intercom is on as soon as aircraft power is on. The intercom is off when aircraft power is off.
- Page 5 Expansion Module. Plug the SR-4 cable into the expansion port on the end of the intercom and route the cable to the rear seat area. Note that the iNova requires a specific SR-4 cable. The 6-pin connector from a Model III SR-4 cable will not plug into the iNova correctly, and will not activate the headphone drivers for the two rear positions.
- Page 6 Connect the stereo patch cord (included) between the 3.5 mm input jack on the iNova and the headphone jack on the source. (See installation diagram on page 13 of this manual). Music will not be transmitted over the radio.
- Page 7 If both the pilot and copilot have their PTT’s depressed at the same time, both voices will be transmitted. For optimum results from your iNova intercom, use high quality, stereo headsets such as the Flightcom Denali.
- Page 8 Setting this switch to the “Pilot” position will connect the pilot’s headset directly to the aircraft radio while allowing the three other positions to use the intercom. Setting this switch to the “Crew” position connects the pilot and copilot headsets to a common intercom/radio bus and the two expansion module positions to a separate intercom bus.
- Page 9 In CREW mode, music audio will not be present for the pilot and copilot. The crew will not hear passenger conversation. Passenger music audio is present and will mute only when the passenger ICS is active. Passengers will not hear crew ICS, aircraft radio, or crew transmissions.
- Page 10 In PILOT ISO mode, the pilot will not hear the music. The pilot will not hear conversation between the copilot and passengers. Copilot and passenger music audio will be present and will only mute during copilot and passenger ICS conversation. Copilot and passengers will not hear any transmissions or aircraft radio.
- Page 11 If the intercom does not work correctly when plugged in, you may have inserted the Push-to-Talk switch between the headset and the intercom. Reconnect the PTT between the intercom and the aircraft radio. Check the DC power cable to confirm that voltage is available at the intercom connector.
- Page 12 If you have difficulty transmitting on the radio Is the pilot’s headset plugged into the pilot’s jacks on the intercom? Distorted sidetone is related to improper shielding of the aircraft antenna cable. Usually your transmissions are received clearly despite the distorted sidetone. If the copilot’s transmission is not clear, check that the copilot transmit cable is plugged in correctly and that the plugs are clean.
- Page 13 RMA number. Warranty claims require that a dated sales receipt or proof of purchase be provided when requested and that your warranty card has been filled out and returned to Flightcom. Repair charges for non-warranty service will be estimated when you call for an RMA.
- Page 15 Flightcom Corporation warrants to the original purchaser of this product that it will be free from defects in materials and workmanship, under normal and proper use, for the period of two years from date of purchase. Flightcom Corporation will repair or replace, at its sole option, any parts showing factory defects during this warranty period, subject to the following provisions.
- Page 16 7340 SW Durham Road | Portland | Oregon 97224 | USA Copyright © 2001. Denali is a registered trademark and iNova is a trademark of Flightcom Corporation. Flightcom is a registered trademark of Flightcom Corporation. All rights reserved. Printed in U.S.A. Specifications subject to change without notice.
