J40UCM
Stand-by Power @ 60Hz
Prime Power @ 60Hz
Standard Features
General features :
Engine (JOHN DEERE , 3029TF270 )
Engine EPA Carb Charge alternator 12 V ,
Governor:Meca
Alternator (LEROY SOMER , LSA432M45 )
Single bearing alternator IP 23 , insulation class H /H
Radiator 50°C [122°F]°C max. T° air inlet with coolant
cap
Skid and vibration isolators
Dry type air filter
Main line circuit breaker
Microprocessor control panel
12 V battery, rack and cable
Industrial silencer (loose)
User manual ^pCSA Certified (consult us)
Generator Ratings
Voltage
240MONO
PRP : Prime Power is available for an unlimited number of annual operating hours in variable load applications, in accordance with ISO 8528-1. A
10% overload capability is available for a period of 1 hour within 12-hour period of operation, in accordance with ISO 3046-1
ESP : The standby power rating is applicable for supplying emergency power in variable load applications in accordance with ISO 8528-1. Overload is
not allowed.
Conditions of sale
SDMO provides a full line of products with high quality
recognized engines and alternators.
Service and parts are available from SDMO distributors as a
single source of responsibility.
J40UCM
MODEL
HZ
Phase
60
1
P.F
Standby Amps
1
Each and every units is factory tested. All generator sets are
also prototype tested.
Warranty according to our standard conditions. Five years
extended also available
specifications and design liable to modifications without prior notice
DIESEL GENSET
J40UCM
40kW / 40 kVA
36 kW / 36 kVA
Standby Ratings
kW/kVA
167
40 / 40
Prime Ratings
kW/kVA
36 / 36
1/5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SDMO J40UCM
Summary of Contents for SDMO J40UCM
- Page 1 ESP : The standby power rating is applicable for supplying emergency power in variable load applications in accordance with ISO 8528-1. Overload is not allowed. Conditions of sale SDMO provides a full line of products with high quality Each and every units is factory tested. All generator sets are recognized engines and alternators.
-
Page 2: Engine Data
Fan air flow 2.34m3/s [4959cfm] Available restriction on air flow 20mm CE [0.8in. WG] Type of coolant Gencool Thermostat 82-94 °C Emissions 49.98 gr/bhp/h 11.19 gr/bhp/h 49.98 gr/bhp/h 11.94 gr/bhp/h J40UCM specifications and design liable to modifications without prior notice... -
Page 3: Alternator Specifications
225 kVA Motor start (Delta = 20% perm. Or 50% trans.) 15.3 % Transient dip (4/4 charge) – PF : 1.8 AR 1.64 kW No load losses 6.42 kW Heat rejection J40UCM specifications and design liable to modifications without prior notice... -
Page 4: Control Panels
Alarms and faults Oil pressure, water temperature, No start-up, Overspeed, Min/max alternator, Min/max battery voltage, Low fuel level, Emergency stop Engine parameters Hours counter, Oil pressure, Water temperature, Engine speed, Battery voltage, Fuel level J40UCM specifications and design liable to modifications without prior notice... -
Page 5: Weight And Dimensions
860kg [1895lbs] Net 970kg [2138lbs] Brut With Optional Enclosure Overall size l x w x h : 2080mm [82in] x 904mm [36in] x 1415mm [56in] Weight : 1090kg [2402lbs] Net 1200kg [2645lbs] Brut J40UCM specifications and design liable to modifications without prior notice... - Page 6 SDMO industries - Head Office – 12bis, rue de la Villeneuve – CS 92848 - 29228 BREST cedex 2 - FRANCE - www.sdmo.com J40UCM specifications and design liable to modifications without prior notice...
