EAGTAC TX25C2 User Manual

User Manual
TX25C2
EAGTAC
High Performance Tactical Flashlight
http://www.eagletac.com
EAGTAC TX25C2 offers maximum output
performance, versatile user interface,
tough build quality and rich accessories
like no other flashlight offers. This series
is designed for police, professionals, and
hobbyists.

Quick Specifications

LED XM-L U2
LED Lumen 1030
ANSI Lumen 852
Runtime* 1 to 90+ hrs
Output 3 / 7
/AUX level
Circuit C3300 ST
Batteries 1x18650 / 2xCR123A
w/ extension tube 2x18650/3-4xCR123a
Voltage 2.7V-12V
* Tested with 2xCR123A with energy saving feature enabled
Tailcap
On/Off
Switch
Brightness
Adjustment
WARNING - Lithium and Li-ion batteries
can explode or cause burns if disas-
sembled, shorted, or exposed to high
temperature. Do not mix with used or
other battery types or install backwards.

Battery Safety Precaution

All EAGTAC flashlights are designed to
use "button-top" battery (battery with
protruding positive terminal). For
rechargeable li-ion battery, use only
EagleTac li-ion battery, or other
protected li-ion battery with compat-
ible length and diameter. Before using
the battery, check and ensure the
battery outer wrapping (the isolating
plastic film that wraps around the
metal housing of the battery) is com-
plete. Broken battery wrapping may
lead to short circuit and damage to the
flashlight.
Lithium and Li-ion battery can explode
or cause burns if disassembled,
shorted, or exposed to high tempera-
ture. Do not mix new and used batter-
ies. Do not mix batteries with different
brand, capacity, voltage, or install
batteries backwards. When the output
starts to dim (this implies battery is
almost drained), replace the batteries.
Do not drain the batteries completely
especially when you're using two (or
more) batteries in series.

Quick Start Guide

1) Unscrew the tailcap and insert new
batteries (w/ protrude top) to use.
Ensure positive terminals is facing the
LED and the ring that holds the pocket
clip is tighten. Replace tailcap and
tighten snugly.
pocket clip ring
LED (Front) Tail-cap
CR123A battery magazine
Use it to prevent battery rattling.

Basic ON and OFF

Turn on the light by press and release
the on/off button switch (<0.4s). To turn
off the light, press and release the
switch again.
For momentary on,
press and hold
the button switch
for immediate
output.
