# Parameter Name
Auto-Record Hold Off
7
8 Jam Received TC
Jam time Of Day
9
Set Generator TC
10
11 Set Generator UBits
12 File Start TC Offset

LCD Monitor

# Parameter Name
1 Exposure Assist
2 Focus Assist
Zebra 1 Level
3
4 Zebra 2 Threshold
Peaking Color
5
6 Peaking Sensitivity
Peaking Background Con-
7
trast
Vertical Flip Display
8
9 Horizontal Flip Display
Description
Sets the duration that a valid timecode sig-
nal has to be recognized by the PIX 260i
before generating a new take when using ex-
ternal timecode to trigger recording (When
[Remote Control - Rec Start/Stop] is set to
Timecode .
Opens a dialog that displays incoming timecode
value in realtime (RxTC), incoming userbits (UB),
transmitting/internal (Ambient® Lockit) timecode value
(GENTC), and transmitting/internal userbits (UB) .
Sets the internal timecode clock to the current time
of day .
Sets the Ambient® Lockit timecode generator value in
HH:MM:SS .FF format .
Sets userbits of the Ambient® Lockit timecode
generator .
Sets the offset of the beginning timecode stamp of
recorded files . Useful when there is a constant offset
between camera and PIX 260i recorded files . The
applied offset does not affect timecode output of the
PIX 260i .
Description
Sets the type of Exposure assist tool .
Sets the type of Focus Assist tool .
Sets IRE level of Zebra 1 .
Sets the IRE threshold valued for Zebra 2 .
Sets the displayed peaking color .
Sets the general peaking sensitivity .
Sets the amount of background contrast when Focus
Assist Peaking is active .
Flips the LCD and OSD vertically .
Flips the LCD video image horizontally .
PIX 260i User Guide and Technical Information
» 0 sec
(numeric 0-8)
• Push Control Knob to jam inter-
nal timecode to incoming (RxTC)
timecode .
• Push Menu button to back out .
» 00:00:00 .00
(Timecode value)
» 00 00 00 00
(Hex: 00-FF for each slot)
» 0
(numeric -10 to +10)
» False Color, 12-step
• False Color, 4-step
• Zebras 1
• Zebras 2
• Zebras 1+2
» Peaking
• Edge Enhance
» 70 IRE +/-5%
(numeric 50-108)
» 85 IRE
(numeric 70-108)
• White
» Red
• Blue
• Green
• Yellow
• High
» Mid
• Low
» 1x
• 0 .5x
• 0 .25x
• No Background
» Off
• On
» Off
• On
Options
Options
67
