Gravity-discharge Toilet
EN
Operation manual
Mazerier-WC
DE
Bedienungsanleitung . . . . . . . . . . . . . 13
WC dilacérateur
FR
Mode d'emploi . . . . . . . . . . . . . . . . . 22
Inodoro triturador
ES
Manual de instrucciones . . . . . . . . . . 32
Toilet met versnijdingspomp
NL
Instructihandleiding . . . . . . . . . . . . . . 42
WC di macerazione
IT
Manuale di istruzioni . . . . . . . . . . . . . 51
Silppuripumppu-wc
FI
Ohjekirja . . . . . . . . . . . . . . . . . . . . . . 60
Macerator-toalett
SV
Bruksanvisning . . . . . . . . . . . . . . . . . 69
Findelingstoilet
DA
Instruktionsvejledning . . . . . . . . . . . . 78
Macerator-toalett
NO
Brukerhåndbok . . . . . . . . . . . . . . . . . 87
Dometic
4300/4400 Series
Toilets
4300 series
4400 series
®
1
Advertisement
Table of Contents
Related Manuals for Dometic 4300 Series
Summary of Contents for Dometic 4300 Series
- Page 1 Inodoro triturador Manual de instrucciones . . . . . . . . . . 32 4300 series Toilet met versnijdingspomp Instructihandleiding . . . . . . . . . . . . . . 42 WC di macerazione Manuale di istruzioni .
-
Page 2: Table Of Contents
Modification of this product may result in property damage. Dometic recommends that a qualified marine technician or electrician install or service this product. Equipment damage, injury to personnel or death could result from improper installation. DOMETIC ACCEPTS NO RESPONSIBILITY OR LIABILITY FOR DAMAGE TO EQUIPMENT, OR PERSONAL INJURY OR DEATH THAT MAY RESULT FROM IMPROPER INSTALLATION, SERVICE OR OPERATION OF THIS PRODUCT. -
Page 3: General Safety Instructions
Dometic 4300 and 4400 series gravity-discharge toilets provides an electric-flush toilet that flushes waste in to a holding tank or other effluent storage/disposal system. Operated by a wall-mounted flush switch or electronic flush handle, the toilet allows the user to add water to the bowl (before using or flushing) and to flush the toilet by pushing a button. Benefits Convenient electronic flush. Add water or flush with the touch of a button or electronic flush handle. Residential-style wood seat with elongated opening. Provides premium quality and comfort. Water-conserving flushes. User controls volume of water used per flush. Manual flush override. Allows manual flushing in event of electrical power failure. Specifications Materials Toilet: vitreous ceramic Dometic switch panel (4300 series): polycarbonate resin Flush handle (4400 series): plated brass... -
Page 4: Specifications
Specifications Dometic 4300/4400 Series Toilets Minimum System Requirements Circuit breaker 2 amps/12 V DC Electrical Wiring 14 gauge stranded copper Fitting 0.5 in. NPT Water Flow rate 4 gpm/15 lpm minimum at toilet Supply Maximum flow pressure 40 PSI / 276 kPa 4-bolt floor (closet) flange. 3-in. (76 mm) ID Discharge Fitting ABS or PVC connection to holding tank Specifications are subject to change without notice . -
Page 5: Operation
Dometic 4300/4400 Series Toilets Operation Operation Toilet system start-up 1 . Turn off electrical power to toilet . 2 . Open small round plastic cover on back ledge of toilet (fig . ), insert screwdriver or other thin blunt-end rod, and push down on Manual Override Lever. This opens flush ball in toilet bowl. 3 . Add holding tank deodorant or treatment through toilet directly into holding tank (follow deodorant directions) . -
Page 6: Maintenance/Winterizing/Service
Maintenance/winterizing/service Dometic 4300/4400 Series Toilets Caution Shut off the toilet system before servicing and do not leave the vehicle for extended periods of time with toilet system circuit breaker on . Maintenance/winterizing/service Cleaning the toilet To maintain the toilet’s original, lustrous appearance, use SeaLand Toilet Bowl Cleaner or other ®... -
Page 7: Troubleshooting Guide
Dometic 4300/4400 Series Toilets Maintenance/winterizing/service Troubleshooting guide Toilet base components (fig . Ref. Description Flush handle (4300 series) Flush switch (4400 series) Hand sprayer (optional – not on all models) Vacuum breaker Bowl and flush ball seals Seal plate Flush ball Cam switch (adjustable) O-ring Floor flange adapter Flange adapter seal Rotor shaft cam Flush switch cable (4400 series) -
Page 8: Wiring Diagram
Maintenance/winterizing/service Dometic 4300/4400 Series Toilets Wiring diagram Troubleshooting information Symptom Possible Cause Service Instruction 1. Toilet will not flush and water will Fuse blown or circuit breaker is • Check toilet fuse or circuit not enter toilet bowl . tripped . breaker at DC distribution panel. • Check for loose/defective wiring between power source and toilet terminal block pins 5 and 8 . - Page 9 Dometic 4300/4400 Series Toilets Maintenance/winterizing/service Symptom Possible Cause Service Instruction 3 . Water will not enter toilet bowl, Blocked water supply or electrical • Blockage in water line to toilet. but toilet flushes. failure . Remove line and clear. • Filter screen at water valve inlet is clogged with debris. Remove water line and clear debris . • Loose or defective wiring be- tween water valve and terminal block pins 1 and 8 .
- Page 10 Maintenance/winterizing/service Dometic 4300/4400 Series Toilets Symptom Possible Cause Service Instruction 10 . Flush ball will not close Component adjustment required or • Rotor shaft cam is loose or de- completely . defective component . fective . If defective, replace . Call Customer Servive for details . 11. Squeaky noise occurs when Lubrication of component(s) is • Drive arm/drive linkage joint flush ball is opening.
-
Page 11: Warranty
. This warranty gives you specific legal rights, and you may have other rights which vary from state to state . To obtain warranty service, first contact your local dealer from whom you purchased this product, or go to http://www .dometic .com for a dealer near you . -
Page 12: Customer Service
To obtain warranty service, first contact your local dealer from whom you purchased this product or go to http://www .dometic .com for a dealer near you . Customer service There is a strong, worldwide network to assist You may also contact or have your local...
