Fujitsu AOU18RLXFW Submittal Specification

AOU18RLXFW Submittal
ASU18RLF
Inverter Driven Heat Pump
Job Name:_______________________________
Location: ________________________________
Engineer:________________________________
Submitted to: _____________________________
Submitted by:_____________________________
Reference:_______________________________
Outdoor Unit Power
Available Voltage Range
Fuse Size, Max.
MCA
Compressor Inverter Driven Variable Speed DC Rotary
No. used
Output
Lubrican Oil
Fan type
Motor Output
Airflow rate Cooling/Heating (High)
Refrigerant
Outdoor unit
Contrlol
O.D. Discharge
O.D Suction
Dimensions
Uncrated
Crated
Weight
Net
Gross Shipping
Cooling
Rated Capacity
Min-Max Capacity
Rated Power Input
Max. Power Input
SEER
EER
Outdoor Sound Rating
Heating
Rated Capacity
Min-Max Capacity
Rated Power Input
Max. Power Input
HSPF
EER
Outdoor Sound Rating
Piping Lengths
Max. Piping Length (Total)
Max. Pipe Height Difference
Connection method
Operating Range
Cooling
Heating
Fujitsu General America, Inc.
Fairfield, NJ 07004
Toll Free: 1-888-888-3424
Fax: (973) 836-0447
www.fujitsugeneral.com
Note: Specifications are based on the following conditions.
Power source of specifications : 230V
Cooling: Indoor temperature of 80°F(26.67°C)DB / 67°F(19.44°C)WB, and outdoor temperature of 95°F(35°C)DB/75°F(23.89°C)WB.
Heating: Indoor temperature of 70°F(21.11°C)DB / 60°F(15.56°C)WB, and outdoor temperature of 47°F(8.33°C)DB/43°F(6.11°C)WB.
Pipe length : 24ft. 7in.(7.5m),Height difference : 0 ft.(0m) [Outdoor unit - Indoor unit]
208-230/VAC-1Ph-60Hz
187-253VAC
POE (RB68)
1489 / 2530CFM
4lbs 10.1oz
Electronic Expansion Valve
(in)
(in)
(in) 32-3/4 x 35-3/8 x 13
(mm) (830 x 900 x 330)
(in) 38-1/4 x 41-1/2 x 17-1/2
(mm) (970 x 1050 x 445)
135lbs (61kg)
150lbs (68kg)
18,000BTU/h
7,000~23,000BTU/h
21,600BTU/h
7,500~36,200BTU/h
. .
14°F~115°F DB
5°F~75°F DB
Fujitsu products are subject to continu-
ous improvements. Fujitsu reserves
the right to modify product design,
specifications and information in this
data sheet without notice and without
incuring any obligations.
Approval:________________________________
Date:___________________________________
Construction: ____________________________
Unit #:__________________________________
Drawing #:_______________________________
30A
14.5A
1
2,100W
Propeller
100W
R410A
3/8"(Flare)
5/8"(Flare)
H x W x D
Outdoor
1.35kW
3.01kW
19.2
13.3
47dB
1.80kW
3.01kW
10.0
12.0
50dB
164ft
98ft
(Flared)
