System Overview
Left Side
Right Side
All air intake and
ventilation open-
ings must be kept
free from obstruc-
tions at all times.
If not, the device
is liable to over-
heat.
Belinea o.book 2.1
(1)
Kensington Lock anti-theft device
Modem port
(2)
(3)
Optical disk drive with eject button
(4)
Emergency release for optical disk drive
(use only if notebook is switched off)
(5)
USB ports
8
(1)
ExpressCard slot
(2)
USB port
(3)
Ethernet/LAN port
(4)
S-Video TV output
(5)
VGA port
(6)
Power adapter socket
(7)
Ventilation slots
Memory card slot
(8)
Fig. 5
Fig. 6
25
