Room Air Conditioners
Portable Heat Pump Range
ECO15P
Register your air conditioner
Model information can be found on the
CE label.
Please register your product online at
www.ecoair.org. For your future
convenience, record the model
information below.
____________________________________
MODEL NUMBER
____________________________________
SERIAL NUMBER
____________________________________
PURCHASE DATE
Advertisement
Table of Contents
Related Manuals for Eco Air ECO15P
Summary of Contents for Eco Air ECO15P
- Page 1 Room Air Conditioners Portable Heat Pump Range ECO15P Register your air conditioner Model information can be found on the CE label. Please register your product online at www.ecoair.org. For your future convenience, record the model information below. ____________________________________ MODEL NUMBER...
-
Page 2: Table Of Contents
Congratulations! You have purchased the very latest in room air conditioner technology. Your new EcoAir high efficiency room air conditioner will give you many years of dependable service. Many features have been built into your EcoAir air conditioner to assure quiet operation, the best circulation of cool, dry air, functional controls, and the most economical operation. -
Page 3: Bs Plug Wiring
BS Plug Wiring Wiring Instructions: Should it be necessary to change the plug please note the wires in the mains lead are coloured in accordance with the following code : BLUE - NEUTRAL BROWN – LIVE GREEN AND YELLOW - EARTH As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:... -
Page 4: Specification
SPECIFICATION Model no. ECO15P 15000 BTU/hr Cooling capacity 4395watts 15000 BTU/hr Heating capacity 4395watts Power/Ampere 1655 W/ 7.5A consumption for cooling Power/Ampere 1280 W/ 5.9A consumption for heating Air volume (max. speed) 550m Humidity removal capacity 1.6L/hour Power supply 220-240V~. 50Hz... -
Page 5: Before Use
BEFORE USE BEFORE USE BEFORE USE BEFORE USE GENERAL SAFETY • • • FIG. 1 • ELECTRICAL SAFETY • FIG. 2 • • • • FIG.3 - 3 -... - Page 6 FOR MAXIMUM EFFICENCY • • • • • FIG.4 • • • - 4 -...
-
Page 7: Product Description
PRODUCT DESCRIPTION PRODUCT DESCRIPTION PRODUCT DESCRIPTION PRODUCT DESCRIPTION Front Back FIG.5 FIG.6 Control Panel Air filter Air vent Air inlet Handle Cord storage Caster Outlet of exhaust air Water stopper / outlet of condensed water Accessories 10. Exhaust hose. 11. PVC strip - for filling the open window space 12. -
Page 8: Installation
INSTALLATION INSTALLATION INSTALLATION INSTALLATION Installation of the exhaust pipe The unit is a portable air conditioner that may be moved from room to room. 1. Using the PVC strip PVC strip FIG.8 Offer PVC strips to the window gap and adjust to size if necessary. •... -
Page 9: Mounting Of The Exhaust Pipe
MOUNTING OF THE EXHAUST PIPE Use only the hose provided and • clip exhaust hose and unit adaptor to the back of the air conditioner. FIG.11 Avoid kinks and bends in the • exhaust hose as this will cause expelled moist air to build up causing the unit to overheat and shut down. -
Page 10: Installation Of Carbon Filter
INSTALLATION OF CARBON FILTER Remove the filter frame from the FIG.15 unit. Separate the filter fixer from the filter frame. Remove the active carbon filter from its plastic bag. Insert the active carbon filter into the filter frame. Fix the filter by reassembling the fixer onto the filter frame. -
Page 11: Operation Of Control Panel
OPERATION OF THE CONTROL PANEL Control panel FIG.16 1. Speed (ventilation) button 13. “Water Full” indicator 2. Timer button 14. ON/OFF (power) button 3. Display window 15. Sleep function button 4. Receiver for remote control 16. TiO2(UV light)/Ionizer button (optional) 5. - Page 12 Indicators of the functions in progress come on at the same time. *NOTE! The display window shows the ambient room temperature from 0 C to 50 To turn the unit off, press ON/OFF button again, then close the air louvers. Setting mode/function Press MODE button to select required working mode: automatic, cooling, fan or heat...
- Page 13 In SLEEP mode, the ventilation will be kept at low speed. Re-press the SLEEP button, the setting temperature and ventilation speed will return to the pre-selected one. In SLEEP mode, the unit will shut down automatically after running for 12 hours. Please note, the sleep function is not available while the machine is working in ventilation.
-
Page 14: Self Diagnosis
SELF DIAGNOSIS SELF DIAGNOSIS SELF DIAGNOSIS SELF DIAGNOSIS This machine is equipped with self-diagnosis function. Please contact us if your machine displays “E1” or “E2” codes. All the above functions can also be performed with the supplied remote control. This remote control requires 2 pcs. AAA size batteries to operate. -
Page 15: Drainage
DRAINAGE DRAINAGE DRAINAGE DRAINAGE During the process of cooling, some water will be extracted from the air into the unit. Most of the water will be evaporated by the coil for maximum efficiency. However in very warm temperature or humid condition, excessive condensation may occur and will require water drainage when tank is full. - Page 16 The drain tube may be extended • by adding an extension tube and using a suitable connector. FIG.21 Please note The drain must be at or below the outlet level. 2. Flashing comp / ‘full water’ indicator will not function in this mode of drainage.
-
Page 17: Maintenance
MAINTENANCE MAINTENANCE MAINTENANCE MAINTENANCE Always unplug the air conditioner from the mains before cleaning. To maximize the efficiency of the air conditioner, clean regularly. Cleaning the housing Use a soft, damp cloth to wipe the body clean. Never use aggressive chemicals, gasoline, detergents, chemically treated cloths, or other cleansing solutions. -
Page 18: Fault Checklist
FAULT CHECK LIST FAULT CHECK LIST FAULT CHECK LIST FAULT CHECK LIST Is the air conditioner plugged in? Is there a power failure? Is the comp / ‘full water’ indicator flashing? Is the room temperature below the set temperature? Is there direct sunshine? (Please put down the curtain.) Are too many windows or doors open? Are there too many people in the room? -
Page 19: Easy To Order Form For Accessories
EASY TO ORDER FORM FOR ACCESSORIES (Please complete in BLOCK CAPITALS in black ink) Full Name: Previous Invoice No.: (If available) Model No. Delivery Address: Telephone No.: Email Address: Signature UNIT DESCRIPTION PRODUCT CODE TOTAL PRICE Filters Rear Filter & Fixer 15P-108&109 £14.99 Side Filter... - Page 20 ONE (1) YEAR LIMITED WARRANTY SAVE THIS WARRANTY INFORMATION EcoAir guarantees this product free from defects in materials and workmanship for a period of one (1) year from the date of purchase, limited to parts only. Faults arising from a faulty installation is specifically excluded. This unit must be operated under conditions as recommended, at voltages indicated on the unit.
