Hardware Requirement - HISTREAM Mega Pixel IP Camera User Manual

Image Sensor
Video Compression
Two Streaming
Video Resolution
Video Parameters
Streaming Type
Video Frame rate
Video Compression
bit rate
Audio Input
Audio Compression
Audio Output
Two-way talk input
Local Recording
System Interface
Alarm Input
Alarm Output
PoE
Power Supply
Power Consumption
Work Temperature
Work Humidity
Storage
Temperature
1.3 Hardware Hardware

Hardware requirement

Hardware requirement requirement requirement
1.3 1.3
1.3
The lowest configuration for hardware
CMOS：1/3 inch deinterlace CMOS sensor. Min 1.5Lux
H.264 Main Profile
Primary and Secondary streaming H.264 & MJPEG
CMOS: 1600*1200, 1280*960, 1280*720.
CMOS: Brightness, Chroma, Saturation, gamma, Contrast, Acutance, Red,
Blue and Image quality.
Pure Video Streaming or Audio and Video streaming.
CMOS: 1-30 fps，can be set under different resolution.
30Kbit/S～8MKbit/S
1 channel linear input, input impedance 1 K Ohms
G.726, G.711, ADPCM
1 channel Linear output
Support Audio two-way talk
Support SD card to record the image and snapshot. SD2.0 standard.
Support IP-San storage.
10Base-T/100Base-TX Ethernet Port
WiFi（802.11b/g）
1 RS485
USB port
SD Slot
1 channel on/off input, Support NO(open),or NC(closed)
1 channel on/off output, 120VAC 1A/24VDC 1A
POE standard 802.3AF-class 0
DC 12V 1A
Less than 6W
-10℃ ~ 55℃
10% ~ 85%
-20℃ ~ 70℃
