HISTREAM HD IP Speed Dome Camera User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

HD IP Speed
Dome Camera
IE Browser User's Manual
(for WindowsXP/2003/Win7/Vista)
Document edition:V4.3
The manual for: V2（5）.3.1.2 and above editions
Editions suit for IPC: HD IP Speed Dome Camera

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD IP Speed Dome Camera and is the answer not in the manual?

Questions and answers

Related Manuals for HISTREAM HD IP Speed Dome Camera

Summary of Contents for HISTREAM HD IP Speed Dome Camera

  • Page 1 HD IP Speed Dome Camera IE Browser User's Manual (for WindowsXP/2003/Win7/Vista) Document edition:V4.3 The manual for: V2（5）.3.1.2 and above editions Editions suit for IPC: HD IP Speed Dome Camera...
  • Page 2 IP Camera IE Browser User’s Manual Preface Thank you for using our HD IP Speed Dome Camera. The product is developed by using Megapixel Progressive Scan CCD or CMOS sensors and high performance multimedia processor, choosing the embedded Linux Operating System, supporting several kinds of video coding protocols, such as H.264 Main Profile、...
  • Page 3 IP Camera IE Browser User’s Manual Statement: Contents in this manual may be different from the edition that you are using. Should any unsolved problem occur given that the product is used according to this manual, please contact our technical support department or your product suppliers. The content of this manual may be updated at irregular intervals without prior notice.
  • Page 4 IP Camera IE Browser User’s Manual Modify record： ： ： ： Recording the corresponding update, the latest document include all of the content in previous editions. Modify date Edition Explanation According to the write standards 2010-12-1 V4.0 of our company, typesetting the document again.

  • Page 5: Table Of Contents

    IP Camera IE Browser User’s Manual Table of Contents Set the IE browser .............................. 6 1 Download and install ActiveX......................... 7 2 Login .................................. 8 3 Live Preview ..............................8 4 Record Playback............................11 5 Set System Parameters ..........................14 5.1 Local config ..........................

  • Page 6: Set The Ie Browser

    IP Camera User’s Manual Set the IE browser If you visit IP camera for the first time, Please set the IE browser frist. Setting method:Open the IE browser, click Ineternet Option into the "Security" page, click the "Custom Level",then follow steps to set the IE browser.(See Figure a b c) 6/66...

  • Page 7: Download And Install Activex

    IP Camera User’s Manual Download and install ActiveX You need to install ActiveX Control when you visit IP camera for the first time through IE browser. ActiveX installing method: Download installation Input the IP address of IP camera in Internet Explore to enter into login page(see Figure Click [File] to download the ActiveX:...

  • Page 8: Login

    IP Camera User’s Manual Login Reopen Internet Explorer after ActiveX installation completes, input IP address of the IP camera to turn to login page, enter username (default setting is admin) and password (default setting is admin), click login to enter into main interface(see Figure 4): Figure 4 Live Preview See Figure 5 for the interface of “Live Preview”...
  • Page 9 IP Camera User’s Manual Lens Control. [Snap]: click “Snap”, snap the current image and save it in .JPG format automatically to the storage directory of snapped images. [Record]: Manual image recording, automatically record current images and save them in .264 format to the storage directory of recorded images after the recording function turned on.
  • Page 10 IP Camera User’s Manual Figure Scan: Support two groups of figure scan. If you enable this function, it can record the operations of PTZ, but the operations don’t include PTZ rotate automatically, preset tour, P&Z scan, PTZ reset, mostly special presets or call by menu. PAN Flip: Rotate horizontally 180 Zero Detection: If you set azimuth zero, the device will be rotated to there after power on and tests by itself when click this button.

  • Page 11: Record Playback

    IP Camera User’s Manual Record Playback Click enter into video playback page (see Figure 9). Figure 9 Users can search for recorded image files or snapped pictures in local PC or storage device according to date. [Date]: Users can select certain date to perform recorded image file or snapped picture searching, click “date”...
  • Page 12 IP Camera User’s Manual The way to search for recorded image files or snapped pictures of a specific period(see Figure 11): Select to search for record files or snapped pictures in PC or device SD card The record file list searched is displayed on the left The picture list searched is displayed on the right The left side stands for hour, each grid means one hour The right side stands for minute, each grid means 2 minutes...
  • Page 13 IP Camera User’s Manual file list, click “download” button to download the files to PC. [Download information]: Users can view the information downloaded after clicking “Download”(see Figure 13): Figure 13 Click [Pause] to pause download manually，click [Start] to continue to download the unfinished files，click [Delete] to delete the downloaded files，click...

  • Page 14: Set System Parameters

    IP Camera User’s Manual Set System Parameters 5.1 Local config See Figure 14 for the interface of “Local config”: Figure 14 [PC live view parameter setting] Code stream: set video stream for PC live preview, preferred stream and alternate stream are selectable. The parameters of preferred and alternate stream can be set up in [Video Settings].

  • Page 15: Remote Config

    IP Camera User’s Manual 5.2 Remote config 5.2.1 Audio Setting See Figure 15 for the interface of “Audio Setting”. Figure 15 [Enable audio]: turn on or turn off the audio of IP camera, When there is no need for audio, close audio input to save DSP resource and network resource.

  • Page 16: Video Coding

    IP Camera User’s Manual Figure 16 [Title]: the name of video channel, displayed at the bottom left of image(movable), maximum characters allowed: 32. [Color]:You can choose different colors for the text. [OSD]: Display or not to display Title, Connecting No.,Date, Time, Week, Date Format and Frame/Bitrate of channels.
  • Page 17 IP Camera User’s Manual Hitachi camera (130W CCD ) Preferred Stream:1280*960/1280*720; Alternate Stream:640*480/320*240/160*112 Hitachi camera (200W CMOS ) Preferred Stream:1920*1080/1280*720; Alternate Stream:640*480/320*240/160*112 720P camera (130W CMOS) Preferred Stream: 1280*720; Alternate Stream:640*480/320*240/160*112 Sony camera (200W CMOS) Preferred Stream:1920*1080/1280*720; Alternate Stream:640*480/320*240/160*112 CMOS support： Preferred Stream：640*480/320*240/160*112；...

  • Page 18: Video Mask

    IP Camera User’s Manual Under CBR setting, [Bitrate] is the constant bitrate of encoding. Under VBR setting, [Bitrate] is the variable bitrate of encoding. [Quality]: Under CBR setting: set the bitrate range via “Image Quality”, 1 means it is controlled by the software, 2~6 means corresponding bitrate range is ±10%～±50% Under VBR setting: set image quality via “Image Quality”, smaller value of image quality means better quality and higher bitrate, but the bitrate will not exceed its set value.

  • Page 19: Picture Parameter

    IP Camera User’s Manual Figure 18 [Enable Mask]: Enable or disable video masking. [Mask area set]: Click and move cursor to set image masking area, an image can be entirely or partially masked, maximum 4 areas supported. [All]: Mask the whole image. [Cls]: Clear masked areas.

  • Page 20: Network Settings

    IP Camera User’s Manual 5.2.3 Network Settings 5.2.3.1 Basic Setting See Figure 20 for the interface of “Basic setting”: Figure 20 [Data port]: Default value is 5000 (users are recommended not to change it). [Web port]: Default value is 80 (users are recommended not to change it). After you set these parameters, please click and the device will reboot to make the parameters valid.

  • Page 21: Pppoe Setting

    IP Camera User’s Manual [MAC]: The Physical address of IP camera (users are recommended not to change it). [DNS]: The default DNS address is the DNS address of Guangdong province, users outside the area please use DDNS function to set the DNS address as their local DNS address.

  • Page 22: Upnp Setting

    IP Camera User’s Manual 5.2.3.4 UPNP setting See Figure 23 for the interface of “UPNP setting”: Figure 23 Auto-mapping of port, when IP camera is connected to a router with UPNP function enabled, the router will automatically map the port in UPNP settings to public network, manual port mapping by users is not necessary.

  • Page 23: Email Setting

    IP Camera User’s Manual [Data mapping status]: When UPNP function runs successfully, the status bar will echo the data port mapped to the router by the device. [Web mapping status]: When UPNP function runs successfully, the status bar will echo the web port mapped to the router by the device.

  • Page 24: Ftp Setting

    IP Camera User’s Manual Commonly used mail server configuration: Gmail Yahoo SMTP server smtp.gmail.com smtp.mail.yahoo.com smtp.163.com username@yahoo.com OR SMTP user name username@gmail.com username username@yahoo.com.cn SMTP port: enabled enabled disabled 5.2.3.6 FTP setting See Figure 25 for the interface of “FTP setting”: Figure 25 FTP server sends the record files and snapped images generated after alarm is triggered in FTP mode to specified FTP server, supports 2 FTP servers, when the preferred one goes...

  • Page 25: Ddns Setting

    IP Camera User’s Manual Notice： ： ： ： If you want to upload the record files and snapped images,you must have the authority to write on the FTP server. 5.2.3.7 DDNS setting See Figure 26 for the interface of “DDNS setting”: Figure 26 Bind the device with a fixed domain name by DNNS setting so that visiting to the device can be realized no matter how the public IP...

  • Page 26: Vpn Setting

    IP Camera User’s Manual [Data port map No.]:Fill in the external data port mapped by the IP camera on the router that is connected to public website. [Web port map No.]:Fill in the external web port mapped by the IP camera on the router that is connected to public website.

  • Page 27: Public Ip Noticed By Email

    IP Camera User’s Manual Figure 28 [Enable RTSP]: check RTSP switch to enable RTSP function. [Enable encryption]: check encryption switch,you need the password then using VLC player connect camera. Open: rtsp://ip/av0_0&user=admin&password=admin; Close：rtsp://ip/av0_0; “av0_0 ”,frist“0” shows channel:0,1,2,3， :1,2,3,4;HD IP speed dome represent the channel camera has only one channel,fill in“0”;...

  • Page 28: Connect Setting

    IP Camera User’s Manual Figure 29 [Enable Email]:Check this switch to enable public IP mail notification function. [Update Interval]: Select the interval of public IP mail notifications. After enable this function, when the device starts or detects public IP change, it will send notification mail to the mail address setted in [mail setting].
  • Page 29 IP Camera User’s Manual Figure 31-1（CS Mode） Figure 31-2（P2P Mode） [Mode]:CS Mose and P2P Mode [Servel URL]: IP address or domain of Mobile server. [Port]: Port of server, [Device ID]:ID of device [Real time]: Fine, Mormal and Basic [Channel]:Channel of video streaming 29/66...

  • Page 30: Storage Settings

    IP Camera User’s Manual 5.2.4 Storage Settings 5.2.4.1 Device Setting See Figure 32 for the interface of “Device Setting”: Figure 32 [Storage Device Info]: View information of SD card here, including No.,TotalSize,FreeSize and Status. Users can also click [Format] button to format SD card, during the formatting process, please click [Refresh] button to the display formatting completion percentage.

  • Page 31: Record Setting

    IP Camera User’s Manual delete the files of the earliest hour. But files of the current hour cannot be deleted, if the SD card gets full in one hour, the device will stop recording and snapping images. After the one-hour session ends, system will delete the files of the hour and continue to record and snap pictures.

  • Page 32: Snap Setting

    IP Camera User’s Manual [File save mode]:Set the save scheduled recorded files to FTP server via FTP uploading, FTP server can be set up in [FTP settings]. After setting all the parameters, click [save] to make them valid. Notice： ： ： ： Record files are saved via FTP uploading. SD card is needed for cache memory support, otherwise record files will be overwritten by new files due to insufficient cache memory space.

  • Page 33: Alarm Settings

    IP Camera User’s Manual uploading. E-Mail server can be set up in [Mail Settings], FTP server can be set up in [FTP Settings]. After setting all the parameters, click [save] to make the parameters valid. 5.2.5 Alarm Settings 5.2.5.1 Motion detection See Figure 35 for the interface of “Motion detection”: Figure 35 In this page, users can set features like motion detection on/off, sensitivity, detection time,...
  • Page 34 IP Camera User’s Manual seconds), the range of the duration is 0~86400s.0 means that there is no limit for alarm output. [E-mail]: Send motion detection alarm information to users via E-mail, details about E-mail setting please refer to [Network Settings]. [Linkage Snapping]: When alarm is triggered, the device SD card will be driven to snap pictures.

  • Page 35: Sensor Setting

    IP Camera User’s Manual 5.2.5.2 Sensor Setting See Figure 36 for the interface of “Sensor Setting”: Figure 36 Set sensor alarm parameters here: Enable detect,sensor type, deployment time, linkage alarm output, linkage output duration, E-mail sending when alarm has been triggered, linkage snapping/recording, etc.

  • Page 36: Failure Setting

    IP Camera User’s Manual each picture is 1 second. [Record]: When alarm is triggered, the device SD card will be driven to record images. The record files can be saved via E-mail sending or FTP uploading. After setting all the parameters, click [save] to make the parameters valid.

  • Page 37: Dome Camera

    IP Camera User’s Manual [Snap]: When alarm is triggered, the device SD card will be driven to snap pictures. The pictures can be saved via E-mail sending or FTP uploading. For snapping parameters, if the number of pictures snapped at one time is set as 10, and the snapping interval is 1 second, that means when there is an alarm, 10 pictures will be snapped and the interval between each picture is 1 second.
  • Page 38 IP Camera User’s Manual Figure 38（Hitachi 720P Camera） [Images Color]: Adjust the Brightness, Chromatism, Saturation, Acutance of video. [Zoom Control]: You can choose high speed(3.5s) or normal speed(5.1s). [AWB Control]: You can choose Manual AWB or Auto mode to adjust white balance. White balance: Depending on the lighting conditions, a pure white in a photograph may appear slightly yellow or blue.
  • Page 39 IP Camera User’s Manual enables the capture and display of both bright and dark areas in the same frame, in a way that there are details in both areas, i.e. bright areas are not saturated, and dark areas are not too dark.
  • Page 40 IP Camera User’s Manual appropriate level for a range of input signal levels. For example, without AGC the sound emitted from an AM radio receiver would vary to an extreme extent from a weak to a strong signal; the AGC effectively reduces the volume if the signal is strong and raises it when it is weaker.
  • Page 41 IP Camera User’s Manual Figure 39（720P Camera） [Images Color]: Adjust the Brightness, Chromatism, Saturation, Acutance, Contrast of video. [Zoom Control]: You can choose high speed(3.5s) or normal speed(5.1s). [AWB Control]: You can choose Manual AWB or Auto mode to adjust white balance. White balance: Depending on the lighting conditions, a pure white in a photograph may appear slightly yellow or blue.
  • Page 42 IP Camera User’s Manual flickering of images, please choose 50HZ or 60HZ according to the power frequency. [Under Point Low Lighting Sources Auto Zooming]: Enable or disable under point low lighting sources auto zooming. Note： ： ： ： You can only select one mode in [program AE mode] at the sametime.
  • Page 43 IP Camera User’s Manual White balance: Depending on the lighting conditions, a pure white in a photograph may appear slightly yellow or blue. The white balance control will help to eliminate unwanted colour bias. There are 3 modes: [BLC Control]: To get better image effect, you can select BLC.
  • Page 44 IP Camera User’s Manual AE mode+ D/N automatically+ middle sensitivity mode AE mode,slow shutter AE mode,slow shutter+ D/N automatically+ high sensitivity mode AE mode,slow shutter+ D/N automatically+ middle sensitivity mode AE mode,slow shutter+ D/N automatically+ low sensitivity mode Shutter Priority: You can obtain the value of aperture when shutter is defined manually control. It is used to shoot moving objects.
  • Page 45 IP Camera User’s Manual Figure 41（Sony 1080P） [Images Color]: Adjust the Brightness, Chromatism, Saturation, Acutance, Contrast of video. If you want to adjust the Brightness,you must select [Bright prionty] in Program AE mode. [Zoom Control]: You can choose high speed(3.5s) or normal speed(5.1s). [AWB Control]: You can choose Manual AWB or Auto mode to adjust white balance.
  • Page 46 IP Camera User’s Manual objects, illumination compensation will be provided in the required range to get better image quality. [WDR Control]: If you turn on WDR, you can’t set [BLC Control]. Wide dynamic range: WDR is intended to provide clear images even under back light circumstances where intensity of illumination can vary excessively, namely when there are both very bright and very dark areas simultaneously in the field of view of the camera.

  • Page 47: Ptz Setting

    IP Camera User’s Manual 【Environment Power Frequency】 In indoor environment, if the flashing of lamps results in the flickering of images, please choose 50HZ or 60HZ according to the power frequency. [Under Point Low Lighting Sources Auto Zooming]: Enable or disable under point low lighting sources auto zooming.
  • Page 48 IP Camera User’s Manual function, when the dome camera rotated vertically to the maximum angle, it will be rotated horizontally 180 ,after that, it will continue to rotated vertically. [Proportional Pan]: Enable or disable proportional pan. If the function is disabled, you can drag the speed change lever to change the PTZ speed;...

  • Page 49: System Setting

    IP Camera User’s Manual Note： ： ： ： The time can not overlap between the five tasks. The priority of operating manually is higher than tasks that set in [Time set].For example, the demo is doing the task that set in [Park] while the PTZ is operated manually, then it will stop and turn to the latter.

  • Page 50: User Manage

    IP Camera User’s Manual Figure 44 [System time Setting]:You can choose the proper time zone. Update via NTP Server: After starting the function, switch on NTP switch and select time zone, save it to turn to [Liveview], the system time that has been automatically corrected by NTP server can be displayed.

  • Page 51: Upgrade

    IP Camera User’s Manual Default user name of administrator: admin Password: admin Default user name of general user: user 1 \user 2 Password: user 1 \user 2 Note: user name and password are case sensitive Notice： ： ： ： User name and password must be 1-15-character-strings consisted by letters, numbers, underlines or dots.

  • Page 52: Restore

    IP Camera User’s Manual 3. For the V2.3.1.2 versions ,Please upgrade “uwe.” file frist， ， ， ， then upgrade “uot.”file . 5.2.7.5 Restore See Figure 47 for the interface of “Restore”: Figure 47 All device parameters (including network parameters, excluding physical address) will be recovered as factory setting values.

  • Page 53: Appendix 1 Network Interface Of Ip Camera

    IP Camera User’s Manual Appendix 1 Network Interface of IP Camera The default network ports of IP camera are: Web port 5000 Communication port, audio/video data transmission port, talkback data transmission port 5000 Audio/video data transmission port Multi-cast Multicast original port + channel number port Appendix 2 Default Network Parameters Default network parameters...

  • Page 54: Appendix 3 Apply For Ddns Domain Name Service

    IP Camera User’s Manual Appendix 3 Apply for DDNS domain name service 1 IP camera DDNS introduction DDNS function of IP camera DDNS (Dynamic Domain Name Service) refers to the real-time analysis of a fixed domain name and the dynamic public IP address of the IP camera. With this function, all Internet users can visit the IP camera via a fixed domain name.
  • Page 55 IP Camera User’s Manual Step 2: User login Enter registered user name and password, click “login” to enter into domain name management interface as follow: Step 3: Domain name registration A domain name must be registered first, then put into use. Click “Domain name management”, a page appears as follow: Register and submit the domain name to be used.

  • Page 56: Appendix 4 Visit Ip Camera Under Different Network Environments

    IP Camera User’s Manual Appendix 4 Visit IP camera under different network environments You can visit IP camera with your PC via LAN or WAN, the following contents will tell you how to use IP camera under different network environments. 1 LAN There are two ways to connect IP camera to LAN: static IP and dynamic IP Static IP...
  • Page 57 IP Camera User’s Manual If a wireless IP camera needs to be visited via WiFi mode, users need to set IP address, subnet mask, gateway, SSID number and password in “WiFi settings” Setup steps: Step 1: Log in IP camera via the IE browser (the default IP is 192.168.55.160). Step 2: Switch to the page [network settings], fill in the device IP address assigned by...
  • Page 58 IP Camera User’s Manual Log in IP camera via IE, turn to [Network Settings] and check [Enable DHCP]. After setting all the parameters, click [save] and restart to make the parameters valid. 2 Internet You have three ways to connect IP camera to Internet: Fixed IP mode;...
  • Page 59 IP Camera User’s Manual Step 1: Log in IP camera via crossover cable direct connection.(For details, please refer [Hardware Installation]) Step 2: Switch to the page [network settings], fill in the device IP address requested from network service provider in to [Basic Parameters], e.g.
  • Page 60 IP Camera User’s Manual Step 2: Click to open DDNS; Step 3: Select DDNS service provider, e.g. mvddns.net; Step 4: Fill in the registration name to log into DDNS server; Step 5: Fill in the registration password to log into DDNS server; Step 6: fill in the domain name applied on DDNS server, e.g.
  • Page 61 IP Camera User’s Manual Step 3: Select “Add New Items”, enter the IP address of the IP camera (e.g.192.168.1.100 ), port (e.g. 85), status (valid) and other information, click save, see below picture: Step 4: After save successfully, below screen appears: 61/66...
  • Page 62 IP Camera User’s Manual Step 5: If DDNS is successfully set in “Network Settings” of IP camera, direct visit to the IP camera can be realized via entering http://test.mvddns.net:85 into IE browser. PPPoE dial-up access For IP camera dial-up access, see below picture for the network topology: Setup steps: Step 1: Log in IP camera via crossover cable direct connection.(For details, please refer to [Hardware...

  • Page 63: Appendix 5 Hd Ip Camera Special Preset Points Function

    IP Camera User’s Manual Appendix 5 HD IP camera Special Preset points Function Preset Description Flip Turn to zero Start figure scan 2 D/N automatically Manual D/N automatically on（Black） Manual D/N automatically off（Color） WDR on WDR off BLC on BLC off Video freeze on Video freeze off Up limit...

  • Page 64: Appendix 6 Faqs

    IP Camera User’s Manual Appendix 6 FAQs 1、 、 、 、 Forget Password Solution: There is a [RESET] button on the back panel of the IP camera, press it 3 times to restore all default parameters (Factory Settings), user name and password are both “admin”.
  • Page 65 IP Camera User’s Manual Solution: Block some clients or reduce the video frame rate. Possible reason 3: The bandwidth is low. Solution: Reduce video frame rate or video compression bitrate. 6 6 6 6 、 、 、 、 Fail to visit IP camera via IE browser Possible Reason 1: Network is disconnected.
  • Page 66 IP Camera User’s Manual 66/66...
