USER MANUAL

Thank you very much for choosing the iiyama
LCD monitor.
We recommend that you take a few minutes to
read carefully through this brief but
comprehensive manual before installing and
switching on the monitor. Please keep this
manual in a safe place for your future
reference.
PLX436S_486S-e.p65
1
ENGLISH
ENGLISH
DEUTSCH
FRANCAIS
NEDERLANDS
ITALIANO
ESPAÑOL
2005/06/20, 16:13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProLite X436S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Iiyama ProLite X436S

Summary of Contents for Iiyama ProLite X436S

  • Page 1: User Manual

    ENGLISH ENGLISH DEUTSCH FRANCAIS NEDERLANDS ITALIANO Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to ESPAÑOL read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this manual in a safe place for your future reference.

  • Page 2: Why Do We Have Environmentally Labelled Computers

    Congratulations! You have just purchased a TCO’99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.

  • Page 3: Environmental Requirements

    Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances.

  • Page 4: Fcc Declaration Of Conformity

    To meet the FCC requirements, you should use a signal cable with ferrite core at both ends. CAUTION Changes or modifications not expressly approved by iiyama could void the users authority to operate the device under FCC compliance regulations. CANADIAN DEPARTMENT OF COMMUNICATIONS COMPLIANCE...

  • Page 5: Table Of Contents

    SCREEN ADJUSTMENTS ..............19 POWER MANAGEMENT FEATURE ..........22 TROUBLE SHOOTING ................23 APPENDIX ....................25 SPECIFICATIONS: ProLite X436S ............ 25 SPECIFICATIONS: ProLite X486S ............ 26 DIMENSIONS: ProLite X436S ............27 DIMENSIONS: ProLite X486S ............27 COMPLIANT TIMING ................. 27 CONNECTOR PIN ASSIGNMENT ............

  • Page 6: For Your Safety

    STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor and contact your dealer or iiyama service center immediately. Further use may be dangerous and can cause fire or electric shock.
  • Page 7 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located.

  • Page 8: Special Notes On Lcd Monitors

    Power Switch for hours. Contact your dealer or iiyama service center for the backlight replacement when the screen is dark, flickering or not lighting up. Never attempt to replace it by yourself.

  • Page 9: Before You Operate The Monitor

    BEFORE YOU OPERATE THE MONITOR FEATURES ProLite X436S: 43cm (17.0") TFT Color LCD Monitor ProLite X486S: 48cm (19.0") TFT Color LCD Monitor Supports Resolutions up to 1280 × 1024 High Contrast 700:1 / High Brightness 300cd/m / Quick Response Time 8ms...

  • Page 10: Checking The Contents Of The Package

    CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama office.

  • Page 11: Controls And Connectors

    CONTROLS AND CONNECTORS USB IN AUDIO IN DVI-D D-SUB AC IN <Front> <Back> A Light Sensor B Power-Saving Sensor C Speakers D Power Indicator Blue: Normal operation NOTE Orange: Power Management The monitor enters into power management mode which reduces the power consumption to less than 2W when receiving no horizontal and/or vertical sync signal.

  • Page 12: Connecting Your Monitor

    The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office. For connection to Macintosh computers, contact your local iiyama dealer or regional iiyama office for a suitable adaptor.

  • Page 13: Computer Setting

    Change to the desired signal timing listed on page 27: COMPLIANT TIMING. Windows 95/98/2000/Me/XP Plug & Play The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs on Windows 95/98/2000/Me/XP by connecting the monitor to DDC2B compliant computer with the Signal Cable supplied.

  • Page 14: Operating The Monitor

    OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 27. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 19 for SCREEN ADJUSTMENTS.

  • Page 15: Adjustment Menu Contents

    ADJUSTMENT MENU CONTENTS Analog Input Menu : 1 (Analog) Menu:1 1280 × 1024 H : 8 0 . 0 K H z V : 7 5 . 0 H z Adjustment Item Problem / Option Button to Press Too dark Brightness * Direct Too bright...

  • Page 16: Screen Adjustments

    Menu : 2 M e n u : 2 (Analog) 1280 × 1024 H : 8 0 K H z V : 7 5 . 0 H z Adjustment Item Problem / Option Button to Press Return to Menu. Auto Set-up * Adjust Clock, Phase, V-Position and H-Position automatically.
  • Page 17 Menu : 2 (Analog) Adjustment Item Problem / Option Normal Gamma Mode1 High contrast Dark Mode2 Normal Economy Mode Mode1 Brightness of back-light is reduced. Mode2 Brightness of back-light is reduced more than Mode1. NOTE is displayed while Economy Mode is active. Exit Close OSD Window.
  • Page 18 Menu : 3 M e n u : 3 (Analog) 1280 × 1024 H : 8 0 . 0 K H z V : 7 5 . 0 H z Adjustment Item Problem / Option Button to Press 1 2 3 4 5 OSD Position You can move the OSD display area to any one of the following 5 positions...
  • Page 19 Menu : 4 Menu:4 (Analog) 1280 × 1024 H : 8 0 . 0 K H z V : 7 5 . 0 H z Adjustment Item Problem / Option Button to Press Too soft Volume Direct Too loud NOTE is displayed while Mute* is active.

  • Page 20: Digital Input

    Digital Input Menu : 1 Menu:1 (Digital) 1280 × 1024 H : 8 0 . 0 K H z V : 7 5 . 0 H z Adjustment Item Problem / Option Button to Press Too dark Brightness * Direct Too bright Too dull Contrast...
  • Page 21 Menu : 1 (Digital) Adjustment Item Problem / Option Normal Economy Mode Mode1 Brightness of back-light is reduced. Mode2 Brightness of back-light is reduced more than Mode1. NOTE is displayed while Economy Mode is active. Exit Close OSD Window. OPERATING THE MONITOR PLX436S_486S-e.p65 2005/06/20, 16:13...
  • Page 22 Menu : 2 M e n u : 2 (Digital) 1280 × 1024 H : 8 0 . 0 K H z V : 7 5 . 0 H z Adjustment Item Problem / Option Button to Press 1 2 3 4 5 OSD Position You can move the OSD display area to any one of the following 5 positions...
  • Page 23 Menu : 3 Menu:3 (Digital) 1280 × 1024 H : 8 0 . 0 K H z V : 7 5 . 0 H z Adjustment Item Problem / Option Button to Press Too soft Volume Direct Too loud NOTE is displayed while Mute* is active.

  • Page 24: Screen Adjustments

    If the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Set-up, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http:// www.iiyama.com).
  • Page 25 C C C C C Press the Auto Button. (Auto Set-up) D D D D D Adjust the image manually by following procedure below when the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Set-up.
  • Page 26 G G G G G Adjust the Phase to correct horizontal wavy noise, flicker or blur in the zebra pattern. – NOTE NOTE In case the strong flicker or blurs remain on a part of the screen, repeat steps F and G because the Clock may not be adjusted correctly.

  • Page 27: Power Management Feature

    POWER MANAGEMENT FEATURE The power management feature of this product complies with every power saving requirement of ® and VESA DPMS. When activated, it automatically reduces unnecessary power NERGY consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer.

  • Page 28: Trouble Shooting

    2. Consult the following items if you cannot find an appropriate adjustment item in OPERATING THE MONITOR or if the problem persists. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem...
  • Page 29 Problem Check No sound. The audio equipment (computer etc.) is ON. The Audio Cable is properly connected. The Volume is turned up. The Mute is OFF. The audio output level of the audio equipment is within the specification of the monitor. The sound is too The audio output level of the audio equipment is within the specification of loud or too quiet.

  • Page 30: Appendix

    APPENDIX SPECIFICATIONS: ProLite X436S LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 43cm / 17.0" Pixel pitch 0.264mm H × 0.264mm V Brightness 300cd/m (Typical) Contrast ratio 700 : 1 (Typical) Viewable angle Right / Left: 75 degrees each, Up: 75 degrees, Down: 60 degrees...

  • Page 31: Specifications: Prolite X486S

    SPECIFICATIONS: ProLite X486S LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 48cm / 19.0" Pixel pitch 0.294mm H × 0.294mm V Brightness 300cd/m (Typical) Contrast ratio 700 : 1 (Typical) Viewable angle Right / Left: 75 degrees each, Up: 75 degrees, Down: 60 degrees Response time 8ms (Black, white, black) Display Colors...

  • Page 32: Dimensions: Prolite X436S

    DIMENSIONS: ProLite X436S 381mm/15" 62mm/2.5" 338mm/13.3" 180mm/7.1" DIMENSIONS: ProLite X486S 421mm/16.6" 62mm/2.5" 378.5mm/14.9" 180mm/7.1" COMPLIANT TIMING Horizontal Vertical Video Mode Dot Clock Frequency Frequency 25.175MHz 31.469kHz 59.940Hz 37.500kHz 75.000Hz 31.500MHz 640 × 480 37.861kHz 72.809Hz 31.500MHz 36.000MHz 35.156kHz 56.250Hz 40.000MHz 37.879kHz...

  • Page 33: Connector Pin Assignment

    CONNECTOR PIN ASSIGNMENT D-Sub mini 15pin Input Signal Input Signal Connector Red video Reserved port Green video / Sync on green Blue video Reserved port Reserved port Data line (SDA)* Ground H-Sync/HV-Sync Red video ground V-Sync Green video ground Clock line (SCL)* Blue video ground * Compliant to VESA DDC.
