18 GAUGE STAPLER KIT
MODEL G6042/3
INSTRUCTION MANUAL
Model G6042
Model G6043
COPYRIGHT © OCTOBER, 2001 BY GRIZZLY INDUSTRIAL, INC.
1821 VALENCIA ST., BELLINGHAM, WA 98227
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
PRINTED IN TAIWAN
Advertisement
Table of Contents
Related Manuals for Grizzly G6042/3
Summary of Contents for Grizzly G6042/3
- Page 1 Model G6043 COPYRIGHT © OCTOBER, 2001 BY GRIZZLY INDUSTRIAL, INC. 1821 VALENCIA ST., BELLINGHAM, WA 98227 WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. PRINTED IN TAIWAN...
-
Page 2: Safety Instructions For Power Tools
For Your Own Safety Read Instruction Manual Before Operating This Equipment The purpose of safety symbols is to attract your attention to possible hazardous conditions. This manual uses a series of symbols and signal words which are intended to convey the level of importance of the safety messages. The progres- sion of symbols is described below. - Page 3 Safety Instructions For Power Tools 10. USE PROPER EXTENSION CORD for the tool. Make sure your extension cord is in good condition. Conductor size should be in accordance with the chart below. The amperage rating should be listed on the motor or tool nameplate.
- Page 4 Basic Stapler Safety In addition to the rules stated in the previ- ous section, and those in the warning boxes throughout this manual, please observe the following safety tips for your new stapler: READ THIS ENTIRE MANUAL BEFORE OPERATING THE STA- PLER.
- Page 5 Commentary We are proud to offer the Grizzly Model G6042/G6043 18 Gauge Stapler. This model is part of a growing Grizzly family of fine power tools. When used according to the guidelines set forth in this manual, you can expect years of trouble-free, enjoy- able operation and proof of Grizzly’s com-...
-
Page 6: Compressed Air System
Check the cur- rent Grizzly catalog for availability of this unit. If you plan on installing a filter/lubrica- tor/regulator unit in your compressed air system, always follow the connection instructions that come with the unit. -
Page 7: Operation
Loading Stapler To load your stapler: Disconnect the air supply from the stapler! Push the magazine latch in the direc- tion shown in Figure 1. Figure 1. Releasing magazine latch. Pull back the magazine cover until it stops. OPERATION Point the stapler up and insert a stick of staples into the magazine as shown in Figure 2. - Page 8 Operating Stapler If you have not read the safety instruc- tions in this manual, do not operate the stapler. Before you operate your stapler, place one drop of the included oil into the quick con- nect fitting where the stapler connects to the air supply.
-
Page 9: Clearing Jammed Staples
Clearing Jammed Staples The most frequent situation with any type of stapler is a staple jam. A jammed staple must be cleared before using the stapler again. The two places where a staple can get jammed are the magazine and the dis- charge area. - Page 10 As mentioned before, the best option is to install a filter/lubricator/regulator unit such as the Grizzly Model H2333 in your air line. Figure 4. Lubricating stapler via air inlet. G6042/G6043 18 Gauge Stapler Kit...
- Page 11 Replacing Pistons/O-Rings If you use your stapler day in and day out, Grizzly offers repair pistons as cheap insurance against wasted down time and lost profits in the event that a piston or pis- ton shaft becomes worn out. To replace a...
-
Page 12: Maintenance Notes
MAINTENANCE NOTES G6042/G6043 18 Gauge Stapler Kit... - Page 13 G6042 PART BREAKDOWN G6042/G6043 18 Gauge Stapler Kit...
- Page 14 PART # DESCRIPTION P6042001 CAP SCREW P6042002 LOCK WASHER P6042003 P6042004 SEAL P6042005 SPRING P6042006 O-RING P6042007 CAP SEAL P6042008 PISTON HEAD VALVE 08A P604200A PISTON HEAD ASSY P6042009 O-RING P6042010 STOPPER P6042011 O-RING P6042012 COLLAR P6042013 O-RING 14A P6042014A DRIVER ASSEMBLY P6042018 O-RING P6042019...
- Page 15 G6043 PART BREAKDOWN G6042/G6043 18 Gauge Stapler Kit...
- Page 16 PART # DESCRIPTION P6043001 CAP SCREW P6043002 LOCK WASHER P6043003 P6043004 SEAL P6043005 SPRING P6043006 O-RING P6043007 CAP SEAL P6043008 PISTON HEAD VALVE 08A P604300A PISTON HEAD ASSY P6043009 O-RING P6043010 STOPPER P6043011 O-RING P6043012 COLLAR P6043013 O-RING 14A P6043014A DRIVER ASSEMBLY P6043018 O-RING P6043019...
-
Page 17: Troubleshooting
1. Use correct staples. 2. Use undamaged staples 3. Tighten magazine and nose screws. 4. Replace worn or dam- aged parts. 1. Clear stapler magazine or discharge area. 2. Replace piston shaft. 3. Check/increase air pres- sure. G6042/3 18 Gauge Stapler Kit... -
Page 18: Warranty And Returns
WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of main- tenance. -
