Page 1 HAWNR3 Hi-Gain™ Wireless 300N Router with Range Amplifier website www.hawkingtech.com USER’S MANUAL e-mail techsupport@hawkingtech.com © COPYRIGHT 2012 HAWKING TECHNOLOGIES,INC. ALL RIGHTS RESERVED.
Page 2 COPYRIGHT Copyright ©2012 by Hawking Technologies, Inc. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means,...
Page 3 Federal Communication Commission Interference Statement FCC Part 15 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 4 Any changes or modifications not expressly approved by the party responsible for compliance could void the authority to operate equipment. Federal Communication Commission (FCC) Radiation Exposure Statement This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20cm (8 inches) during normal operation.
Page 5 EU Countries Intended for Use The ETSI version of this device is intended for home and office use in Austria, Belgium, Denmark, Finland, France, Germany, Greece, Ireland, Italy, Luxembourg, the Netherlands, Portugal, Spain, Sweden, and the United Kingdom. The ETSI version of this device is also authorized for use in EFTA member states: Iceland, Liechtenstein, Norway, and Switzerland.
Page 6: Table Of Contents
Chapter II: System and Network Setup ................15 2-1 Build Network Connection ..................15 2-2 Connecting to the HAWNR3 via Web Browser ............. 16 2-2-1 Windows 95/98/Me IP Address setup: ............18 2-2-2 Windows 2000 IP Address Setup: ..............20 ...
Page 7 3-4-5 Setup procedure for ‘L2TP’: ................65 3-4-6 Setup procedure for ‘DNS’: ................68 3-4-7 Setup procedure for ‘DDNS’: ................. 70 3-5 Wired LAN Configuration ..................72 3-5-1 Local Network ....................73 3-5-2 DHCP Server: ....................74 ...
Page 8 4-4-6 Active DHCP client list ................. 142 4-4-7 Statistics ......................143 4-5 Tools ........................144 4-6 Firmware Upgrade ....................146 4-7 System Reset......................148 Chapter V: Appendix ....................... 149 5-1 Hardware Specification ..................149 ...
Page 9: Chapter I: Product Information
Chapter I: Product Information 1-1 Introduction and Safety Information Thank you for purchasing the HAWNR3 Hi-Gain™ Wireless 300N Router with Range Amplifier. This highly efficient router is the best choice for Small office / Home office users. It allows computers and network devices to share a single xDSL / cable modem internet connection at high speed.
Page 10  Easy to use Web-based GUI for network configuration and management purposes  Remote management function allows configuration and upgrades from a remote computer (over the Internet)  Auto MDI / MDI-X function for all wired Ethernet ports.
Page 11: Safety Information
1-2 Safety Information In order to keep the safety of users and property, please follow these safety instructions: 1. This router is designed for indoor use only; DO NOT place this router outdoors. 2. DO NOT put this router at or near hot or humid places, like kitchens or bathrooms. Also, do not leave this router in the car in summer.
Page 12: System Requirements
1-3 System Requirements  One computer (Mac or PC).  Internet Web Browser (Internet Explorer, Safari, etc.)  A Wired or Wireless network adapter (e.g. Airport card, built-in Ethernet adapter, etc.)  Broadband Modem (e.g. Cable or DSL)
Page 13: Package Contents
1-4 Package Contents Before you start to use this router, please check if there’s anything missing in the package, and contact your place of purchase or contact Hawking Technologies.  Broadband Router (main body, 1 pcs)  Quick Installation Guide (1 pcs) ...
Page 14: Product Overview
1-5 Product Overview Front Panel LED Name Light Status Description Power Router is switched on and correctly powered Wireless network is switched on or WPS mode is on. Wireless Wireless network is switched off Flashing Wireless LAN activity (transferring or receiving data). WAN port (Internet) is connected Internet WAN port is not connected...
Page 15: Back Panel
Back Panel Item Name Description Antenna 3dBi dipole antennas. Power Power connector, connects to A/C power adapter 12V/1A. Reset/W{S Reset the router to factory default settings (clear all settings). Press this button and hold for 30 seconds to restore all settings to factory defaults.
Page 16: Chapter Ii: System And Network Setup
2-1 Build Network Connection Please follow the following instructions to build the network connection between your new HAWNR3 router and your computers and other network devices: 1. Connect your xDSL /cable modem to the WAN port of this router by Ethernet cable.
Page 17: Connecting To The Hawnr3 Via Web Browser
2-2 Connecting to the HAWNR3 via Web Browser After the network connection is built, the next step you should do is setup the router with proper network parameters, so it can work properly in your network environment. Before you can connect to the router and start configuration procedures, your computer must be able to get an IP address automatically (use dynamic IP address).
Page 19: Windows 95/98/Me Ip Address Setup
2-2-1 Windows 95/98/Me IP Address setup: 1. Click ‘Start’ button (it should be located at lower-left corner of your computer), then click control panel. Double-click Network icon, and Network window will appear. Select ‘TCP/IP’, then click ‘Properties’. 2. Select ‘Obtain an IP address from a DHCP server’ and then click ‘OK’.
Page 21: Windows 2000 Ip Address Setup
2-2-2 Windows 2000 IP Address Setup: 1. Click ‘Start’ button (it should be located at lower-left corner of your computer), then click control panel. Double-click Network and Dial-up Connections icon; click Local Area Connection, and Local Area Connection Properties window will appear. Select ‘Internet Protocol (TCP/IP)’...
Page 22 2. Select ‘Obtain an IP address automatically’ and ‘Obtain DNS server address automatically’, then click ‘OK’.
Page 24: Windows Xp Ip Address Setup
2-2-3 Windows XP IP Address Setup: 1. Click ‘Start’ button (it should be located at lower-left corner of your computer), then click control panel. Double-click Network and Internet Connections icon, click Network Connections, and then double-click Local Area Connection, Local Area Connection Status window will appear, and then click ‘Properties’...
Page 25 2. Select ‘Obtain an IP address automatically’ and ‘Obtain DNS server address automatically’, then click ‘OK’.
Page 27: Windows Vista/7 Ip Address Setup
2-2-4 Windows Vista/7 IP Address Setup: 1. Click ‘Start’ button (it should be located at lower-left corner of your computer), then click control panel. Click View Network Status and Tasks, and then click Manage Network Connections. Right-click Local Area Network, then select ‘Properties’. Local Area Connection Properties window will appear, select ‘Internet Protocol Version 4 (TCP / IPv4), and then click ‘Properties’...
Page 28 2. Select ‘Obtain an IP address automatically’ and ‘Obtain DNS server address automatically’, then click ‘OK’.
Page 29: Mac Os X Ip Address Setup
Mac OS X IP Address Setup 2-2-5 Go to your system preferences, go to network. Select your network connection. Make sure ‘Configure’ is set to ‘Using DHCP’.
Page 30: Tablet/Smartphone Setup
2-2-6 Tablet/Smartphone Setup iOS (iPhone or iPad) Go to your settings on your tablet or smart phone First, make sure JavaScript is On: Go to Settings icon Select (a) Safari > make sure (b) JavaScript is ON. back to Home Screen > Select Settings > In Wi-Fi Networks, select (c) “Hawking_300N”...
Page 31 Android (Android 2.1 +) Go to Settings Go to Wireless & Networks Check “Turn on Wi-Fi” and then click on Wi-Fi settings Look for Hawking_300N, then select to connect...
Page 33: Accessing The Web Based Setup Page
2-2-7 Accessing the Web Based Setup Page Open your web browser, In the address field, please type: 192.168.1.254 Press enter. The following message should be shown: Please input user name and password in the field respectively, Default Username: admin Default Password: 1234 Press ‘OK’...
Page 34 NOTE: If you can’t see the web management interface, and you are being prompted to input user name and password again, it means you didn’t input username and password correctly. Please retype user name and password again. If you are certain that user name and password you typed are correct, please go to ‘5-2 Troubleshooting’...
Page 35: Quick Setup
2-3 ‘Quick Setup’ This router provides a ‘Quick Setup’ procedure, which will help you to complete all required settings you need to access the Internet in very short time. Please follow the following instructions to complete the ‘Quick Setup’: Please go to Quick Setup Wizard menu by clicking ‘Quick Setup’ button.
Page 36 1. Set Time Zone Set Time Please press button, a drop-down list Zone (1): will be shown, and you can choose a time zone of the location you live. Time Server Input the IP address / host name of time server Address (2): here.
Page 37 2. Broadband Type Please choose the broadband (Internet connection) type you’re using and then click ‘Next’. There are six types of Internet connection, they are: Cable Modem Setup (Dynamic IP) - Please go to section 2-3-1 DSL and Cable Modem Setup (Static IP) - Please go to section 2-3-2 DSL (PPPoE) - Please go to section 2-3-3...
Page 38 If you want to go back to previous step, please press ‘Back’ button on the bottom of this page. NOTE: Some service providers use ‘DHCP’ (Dynamic Host Configuration Protocol) to assign IP address to you. In this case, you can choose ‘Cable Modem’ as Internet connection type, even if you’re using another connection type, like xDSL.
Page 39: Setup Procedure For 'Cable Modem Setup (Dynamic Ip)
2-3-1 Setup Procedure for ‘Cable Modem Setup (Dynamic IP)’: Host Name (1): Please input the host name of your computer, this is optional, and only required if your service provider asks you to do so. MAC address (2): Please input MAC address of your computer here, if your service provider only permits computer with certain MAC address to access internet.
Page 40: Setup Procedure For 'Dsl And Cable Modem Setup (Static Ip Address)
2-3-2 Setup Procedure for ‘DSL and Cable Modem Setup (Static IP Address)’: IP address assigned Please input IP address assigned by your service provider. Provider (1): Subnet Mask (2): Please input subnet mask assigned by your service provider DNS address (3): Please input the IP address of DNS server provided by your service provider.
Page 41: Setup Procedure For 'Dsl (Pppoe)
2-3-3 Setup procedure for ‘DSL (PPPoE)’: User Name (1): Please input user name assigned by your Internet service provider here. Password (2): Please input the password assigned by your Internet service provider here. Service Name (3): Please give a name to this Internet service, this is optional MTU (4): Please input the MTU value of your network connection here.
Page 42 When you finish with all settings, please click ‘Continue’ (7); if you want to go back to previous menu, click ‘Back’. MTU - Please use default value if you don’t know what it is, or ask your service provider for a proper value. Connection Type - There are 3 options: ‘Continuous’...
Page 43: Setup Procedure For 'Dsl (Pptp)
2-3-4 Setup procedure for ‘DSL (PPTP)’: DSL (PPTP) requires two kinds of setting: WAN interface setting (setup IP address) and PPTP setting (PPTP user name and password). Here we start from WAN interface setting: Select how you obtain IP address from your service provider here. You can choose ‘Obtain an IP Address Automatically’...
Page 44 User ID (1): Please input user ID (user name) assigned by your Internet service provider here. Password (2): Please input the password assigned by your Internet service provider here. PPTP Gateway (3): Please input the IP address of PPTP gateway assigned by your Internet service provider here.
Page 45 * Setting item ‘BEZEQ-ISRAEL’ is only required to check if you’re using the service provided by BEZEQ network in Israel. When you finish with all settings, please click ‘Continue’ (9); if you want to go back to previous menu, click ‘Back’.
Page 46: Setup Procedure For L2Tp
2-3-5 Setup Procedure for L2TP L2TP requires two kinds of setting: WAN interface setting (setup IP address) and L2TP setting (L2TP user name and password). Here we start from WAN interface setting: Select the type of how you obtain IP address from your service provider here. You can choose ‘Obtain an IP Address automatically’...
Page 47 User Name (1): Please input user ID (user name) assigned by your Internet service provider here. Password (2): Please input the password assigned by your Internet service provider here. L2TP Gateway (3): Please input the IP address of PPTP gateway assigned by your Internet service provider here.
Page 48: Wireless Setup
2-3-6 Wireless Setup Please enter your SSID you wish for your wireless network Default: Hawking_300N Enter a wireless security key. By default, this device uses WPA TKIP security. Please enter a key 8 characters or more or leave it blank if you do not wish to use any security.
Page 49: Finishing Up
2-3-7 Finishing Up Click ‘Finish’ to reset the router and have it reboot; if you want to go back to previous menu, click ‘Back’. Congratulations! You have setup your HAWNR3.
Page 50: Chapter Iii General Setup
Chapter III General Setup In this chapter, you’ll know how to change the time zone, password, and remote management settings. Please start your web browser and log onto router web management interface, then click ‘General Setup’ tab.
Page 51: Time Zone And Time Auto-Synchronization
3-1 Time zone and time auto-synchronization Please follow the following instructions to set time zone and time auto-synchronization parameters: Please click ‘General Setup’ at the top of web management interface, select ‘System’ on the left hand column, and select ‘Time Zone’. The time zone settings will be displayed in your web browser: Please select the correct time zone from the drop-down list, and input the IP address or host name of the time server.
Page 52 Please click ‘Go Back’ to go back to previous setup menu, or click ‘Apply’ to reboot the router so the settings will take effect. Please wait 30-60 seconds for the router to reboot. NOTE: You can refer to the instructions given in the last chapter ‘2-3-1’, for detailed descriptions on time zone settings.
Page 53: Change Management Password
3-2 Change management password Default password of this router is ‘1234’, and it’s displayed on the login prompt when accessed from the web browser. There’s a security risk if you don’t change the default password, since everyone can see it. This is very important when you have wireless function enabled.
Page 54 Please retype the new password again when you see above message. If you see the following message: It means the content in ‘Current Password’ field is wrong, please click ‘OK’ to go back to previous menu, and try to input current password again. If the current and new passwords are correctly entered, after you click ‘Apply’, you’ll be prompted to input your new password: Please use new password to enter web management interface again, and you...
Page 55: Remote Management
3-3 Remote Management This router does not allow management access from Internet, to prevent possible security risks (especially when you defined a weak password, or didn’t change default password). However, you can still manage this router from a specific IP address by enabling the ‘Remote Management’ Function. Please click ‘General Setup’...
Page 56 Please click ‘Go Back’ to go back to previous setup menu, or click ‘Apply’ to reboot the router so the settings will take effect. Please wait 30-60 seconds for the router to reboot. NOTE: When you want to manage this router from another computer over the internet, you have to input the IP address and port number of this router.
Page 57: Setup Internet Connection (Setup)
3-4 Setup Internet Connection (Setup) Internet connection setup can also be done by using ‘Quick Setup’ menu described in Chapter 2-3. To start configuration, please follow the instructions: Please click ‘General Setup’ tab at the top of the web management interface, and on the left hand column, click ‘Internet Connection’.
Page 58: Setup Procedure For 'Cable Modem Setup (Dynamic Ip)
3-4-1 Setup procedure for ‘Cable Modem Setup (Dynamic IP)’: Host Name (1): Please input host name of your computer, this is optional, and only required if your service provider asks you to do so. MAC Address (2): Please input MAC address of your computer, if your service provider only permits computer with certain MAC address to access internet.
Page 59: Setup Procedure For 'Dsl Modem (Static Ip)
3-4-2 Setup procedure for ‘DSL Modem (Static IP)’: IP address (1): Please input IP address assigned by your service provider. Subnet Mask (2): Please input subnet mask assigned by your service provider Default Gateway (3): Please input the Default Gateway provided by your service provider DNS Address (4): Please input the DNS server provided by your service...
Page 60 Please click ‘Go Back’ to go back to previous setup menu, or click ‘Apply’ to reboot the router so the settings will take effect. Please wait 30-60 seconds for the router to reboot.
Page 61: Setup Procedure For 'Dsl (Pppoe)
3-4-3 Setup procedure for ‘DSL (PPPoE)’: User Name (1): Please input user name assigned by your Internet service provider here. Password (2): Please input the password assigned by your Internet service provider here. Service Name (3): Please give a name to this Internet service, this is optional MTU (4): Please input the MTU value of your network connection here.
Page 62 Internet. “Idle Time Out” is set to stop the connection when the network traffic is not sending or receiving after an idle time. Manual – After you have selected this option, you will see the “Connect” button and “Disconnect” button, click “’Connect” and the router will connect to the ISP.
Page 63: Setup Procedure For 'Pptp
3-4-4 Setup procedure for ‘PPTP’: PPTP requires two kinds of setting: WAN interface setting (setup IP address) and PPTP setting (PPTP user name and password). Here we start from WAN interface setting: Select the type of how you obtain IP address from your service provider here. You can choose ‘Obtain an IP Address automatically’...
Page 64 User Name (1): Please input user ID (user name) assigned by your Internet service provider here. Password (2): Please input the password assigned by your Internet service provider here. PPTP Gateway (3): Please input the IP address of PPTP gateway assigned by your Internet service provider here.
Page 65 Idle Time Out (8): Please input the idle time out of Internet connection you wish to use, and refer to section 3-4-3 for detailed descriptions. Setting item ‘BEZEQ-ISRAEL’ is only required to check if you’re using the service provided by BEZEQ network in Israel. When you finish with all settings, please click ‘Apply’...
Page 66: Setup Procedure For 'L2Tp
3-4-5 Setup procedure for ‘L2TP’: L2TP requires two kinds of setting: WAN interface setting (setup IP address) and L2TP setting (L2TP user name and password). Here we start from WAN interface setting: Select the type of how you obtain IP address from your service provider here. You can choose ‘Obtain an IP Address automatically’...
Page 67 User Name (1): Please input user ID (user name) assigned by your Internet service provider here. Password (2): Please input the password assigned by your Internet service provider here. L2TP Gateway (3): Please input the IP address of PPTP gateway assigned by your Internet service provider here.
Page 68 Please click ‘Go Back’ to go back to previous setup menu; to continue on router setup, or click ‘Apply’ to reboot the router so the settings will take effect. Please wait 30-60 seconds for the router to reboot.
Page 69: Setup Procedure For 'Dns
3-4-6 Setup procedure for ‘DNS’: If you select ‘Dynamic IP’ or ‘PPPoE’ as Internet connection method, at least one DNS server’s IP address should be assigned automatically. However, if you have preferred DNS server, or your service provider didn’t assign the IP address of DNS server, you can input the IP address of DNS server here.
Page 70 Please click ‘Go Back’ to go back to previous setup menu, or click ‘Apply’ to reboot the router so the settings will take effect. Please wait 30-60 seconds for the router to reboot...
Page 71: Setup Procedure For 'Ddns
3-4-7 Setup procedure for ‘DDNS’: DDNS (Dynamic DNS) is an IP-to-Host name mapping service for those Internet users who don’t have a static (fixed) IP address. It will be a problem when such users want to provide services to other users on the Internet, because their IP address will vary every time when connected to the Internet, and other user will not be able to know the IP address they’re using at a certain time.
Page 72 Domain Name (3): Input the domain name you’ve obtained from DDNS service provider. Account / Input account or email of DDNS registration. E-Mail (4): Password / Key (5): Input DDNS service password or key. After you finish with all settings, please click ‘Apply’ (6) button and the following message will be displayed on your web browser: Please click ‘Go Back’...
Page 73: Wired Lan Configuration
3-5 Wired LAN Configuration Before all computers using wired Ethernet connection (i.e. those computers connected to this router’s LAN port 1 to 4 by Ethernet cable) can communicate with each other and access Internet, they must have a valid IP address.
Page 74: Local Network
Please click ‘General Setup’ at the top of web management interface and click ‘Local Network’ on the left hand column. There are three setup groups here: ‘LAN IP’, ‘DHCP Server’, and ‘Static DHCP Leases Table’. 3-5-1 Local Network IP address (1): Please input the IP address of this router.
Page 75: Dhcp Server
3-5-2 DHCP Server: These settings are only available when ‘DHCP Server’ in ‘LAN IP’ section is ‘Enabled’. Lease Time (1): Please choose a lease time (the duration that every computer can keep a specific IP address) of every IP address assigned by this router from dropdown menu.
Page 77: Static Dhcp Leases Table
3-5-3 Static DHCP Leases Table: This function allows you to assign a static IP address to a specific computer forever, so you don’t have to set the IP address for a computer, and still enjoy the benefit of using DHCP server. A maximum of 16 static IP addresses can be assigned here.
Page 78 If you want to delete a specific item, please check the ‘Select’ box of a MAC address and IP address mapping (1), then click ‘Delete Selected’ button (2); if you want to delete all mappings, click ‘Delete All’ (3). If you want to deselect all mappings, click ‘Reset (4).
Page 79: Wireless Network
3-6 Wireless Network If your computer, PDA, game console, or other network devices is equipped with a wireless network adapter, you can use the wireless function of this router to let them connect to the Internet and share resources with other computers. Please click ‘General Setup’...
Page 80: Basic Wireless Settings
3-6-1 Basic Wireless Settings Please click ‘General Setup’ menu at the top of web management interface, then click ‘Wireless Configuration’ on the left hand column. Choose ‘Basic Settings’. Band (1): Please select the radio band from one of following options: 2.4 GHz (B) 2.4GHz band, only allows 802.11b wireless network clients to connect to this router (maximum transfer rate 11Mbps).
Page 81 NOTE: For 802.11b and 802.11g mode, the signals can be transmitted only by antenna 1 (The antenna on the right side of the rear panel). For 802.11n mode: The router is operating in a 2T2R Spatial Multiplexing MIMO configuration. Two (2) antennas are for signal transmitting and two (2) antennas are for signal receiving.
Page 82 Please click ‘Go Back’ to go back to previous setup menu; to continue on router setup, or click ‘Apply’ to reboot the router so the settings will take effect. Please wait 30-60 seconds for the router to reboot. NOTE: If you don’t have special reason to limit the type of allowed wireless clients, it’s recommended to choose ‘2.4 GHz (B+G+N) to maximize wireless client compatibility.
Page 83: Advanced Wireless Settings
3‐6‐2 Advanced Wireless Settings This router provides some advanced control of wireless parameters, if you want to configure these settings, please click ‘General Setup’ at the top of web management interface and click ‘Wireless Configuration’ on the left hand column. Choose “Advanced Settings’. Fragment Threshold(1): Set the Fragment threshold of wireless radio.
Page 84 value is ‘100’. DTIM Period(4): Set the DTIM period of wireless radio. Do not modify the default value if you do not understand the function, default value is ‘3’. Data Rate(5): Set the wireless data transfer rate to a certain value. Since most of wireless devices will negotiate with each other and pick a proper data transfer rate automatically.
Page 85 reach your wireless router). WMM(12): Wi-Fi MultiMedia (WMM) will enhance the data transfer performance of multimedia contents when they are being transferred over a wireless network. If you do not understand the function, then it is safe to set this option to ‘Enable’, however, default value is ‘Disable’.
Page 86: Security Settings
3-6-3 Security Settings It is important to set your wireless security settings properly! If you do not configure a wireless security setting, unauthorized users can use your network and/or obtain valuable data without your consent. To set wireless security settings, please click ‘General Setup’ tab at the top of web management interface, then click ‘Wireless Configuration’...
Page 87 and the following setup menu will be shown on your web browser: Key Length (2): There are two types of WEP key length: 64-bit and 128-bit. Using ‘128-bit’ is safer than ’64-bit’, but will reduce some data transfer performance. Key Format (3): There are two types of key format: ASCII and Hex.
Page 88 ‘Hex’ as key format, you can use characters 0-9, a-f, and A-F. You must enter at least one encryption key here, and if you entered multiple WEP keys, they should not be same with each other. Enable 802.1x IEEE 802.1x is an authentication protocol. Every Authentication (9): user must use a valid account to login to this wireless router before accessing the wireless LAN.
Page 89 following message will be displayed on your web browser: Please click ‘Go Back’ to go back to previous setup menu, or click ‘Apply’ to reboot the router so the settings will take effect. Please wait 30-60 seconds for the router to reboot. 3-6-3-3 Wi-Fi Protected Access (WPA): When you select this mode, the wireless router will use WPA encryption, and the following setup menu will be shown on your web browser:...
Page 90 dictionary due to security reason. After you finish WPA Pre-shared key setting, please click ‘Apply’ button (5) and the following message will be displayed on your web browser: Please click ‘Go Back’ to go back to previous setup menu, or click ‘Apply’ to reboot the router so the settings will take effect.
Page 91 Cipher Suite: Available options are: WPA (TKIP), WPA2 (AES), and WPA2 Mixed. You can select one of them, but you have to make sure your wireless client support the cipher you selected. RADIUS Server Please input the IP address of your IP address (3): Radius authentication server here.
Page 92: Wireless Access Control
3-6-4 Wireless Access Control This function will help you prevent unauthorized users from connecting to your wireless router; only those wireless devices who have a MAC address you assigned can gain access to your wireless router. Use this function with other security measures described in previous section, to create a safer wireless environment.
Page 93 Access Control (1): ‘Enable Wireless Access Control’. When this item is unchecked, wireless router will not enforce MAC address filtering of wireless clients. MAC Address (2): Input the MAC address of your wireless devices here, dash ( - ) or colon ( : ) are not required. (i.e. If the MAC address label of your wireless device indicates ‘aa-bb-cc-dd-ee-ff’...
Page 94 Please click ‘Go Back’ to go back to previous setup menu, or click ‘Apply’ to reboot the router so the settings will take effect. Please wait 30-60 seconds for the router to reboot.
Page 95: Wi-Fi Protected Setup (Wps)
3-6-5 Wi-Fi Protected Setup (WPS) Wi-Fi Protected Setup (WPS) is the simplest way to build connection between wireless network clients and this wireless router. You don’t have to select an encryption mode and input a long encryption passphrase every time when you need to set up a wireless client, you only have to press a button on the wireless client and this wireless router, and the WPS will automatically configure for you.
Page 96 Enable WPS (1) Check this box to enable WPS function, uncheck it to disable WPS. WPS Information (2) WPS Status: If the wireless security (encryption) function of this wireless router is properly set, you’ll see ‘Configured’ message here. If wireless security function has not been set, you’ll see ‘Not configured’.
Page 97 enable security function of the wireless router before WPS is activated, the router will auto set the security to WPA (AES) and generate a set passphrase key for WPS connection. Passphrase Key: The wireless security key of the router will be displayed here.
Page 98: Security Tips For Wireless Network
3-6-6 Security Tips for Wireless Network Here are some quick tips to help you improve the security level of your wireless network: 1. Never use simple words for your password, such as “password” or “1234567890”. 2. A complicated (combination of numbers, alphabets, and even symbols) WEP key and WPA passphrase is more secure than simple and short words.
Page 99: Chapter Iv Advanced Functions
Chapter IV Advanced Functions 4-1 Quality of Service (QoS) Quality of Service provides an efficient way for computers on the network to share Internet bandwidth with a promised quality of Internet service. Without QoS, all computers and devices on the network will compete with each other to receive Internet bandwidth, and some applications which require guaranteed bandwidth (ie.
Page 100: Basic Qos Settings
4-1-1 Basic QoS Settings Please follow the following instructions to set QoS parameters: Please click ‘General Setup’ at the top of web management interface and click ‘QoS’ on the left hand column. Enable QoS (1): Check this box to enable QoS function, unselect this box if you do not want to enforce QoS bandwidth limitations.
Page 101 bandwidth (3): To disable upload bandwidth limitation, input ‘0’ here. Current QoS All existing QoS rules will be displayed here. Table (4): Add (5): Click ‘add’ button to add a new QoS rule, see section 4-1-2 ‘Add a new QoS rule’ below. Edit (6): If you want to modify the content of a specific rule, please check the ‘select’...
Page 102 Please click ‘Go Back’ to go back to previous setup menu, or click ‘Apply’ to reboot the router so the settings will take effect. Please wait 30-60 seconds for the router to reboot.
Page 103: Add A New Qos Rule
4-1-2 Add a New QoS Rule After you click ‘Add’ button in QoS menu, the following message will appear: Rule Name (1): Please give a name to this QoS rule (enter up to 15 alphanumerical characters) Bandwidth (2): Set the bandwidth limitation of this QoS rule. You have to select the data direction of this rule (Upload of Download), and the speed of bandwidth limitation in Kbps, then select the type of QoS: ‘guarantee’...
Page 104 Local Port Please input the range of local (source) port number Range (4): that will be affected by this rule. If you want to apply this rule on port 80 to 90, please input ’80-90’; if you want to apply this rule on a single port, input the port number, such as ‘80’.
Page 105 If you want to erase all values you entered, click the ‘Reset’ button.
Page 106: Network Address Translation (Nat)
4-2 Network Address Translation (NAT) Network Address Translations (NAT) solves the problem of sharing a single IP address to multiple computers. Without NAT, all computers must be assigned with a valid Internet IP address to get connected to Internet, but Internet service providers only provide very few IP addresses to every user.
Page 107: Basic Nat Settings (Enable Or Disable Nat Function)
4-2-1 Basic NAT Settings (Enable or disable NAT function) Please click ‘General Setup’ at the top of web management interface and click ‘NAT’ on the left hand column. To enable NAT function, please select ‘Enable’ for ‘Enable NAT module function’ (1); to disable, please select ‘Disable’. After you made the selection, please click ‘Apply’...
Page 108: Port Forwarding
4-2-2 Port Forwarding If you enable Network Address Translation (NAT), the Port Forwarding section will be available for configuration. This function allows you to redirect a single port or consecutive ports of Internet IP address to the same port of the IP address on local network. The port number(s) of Internet IP address and private IP address (the IP address on local network) must be the same.
Page 109 Private IP (2): Input the IP address of the computer on local network which provides internet service. Computer Name (3): Pull down the menu and all the computers connected to the router will be listed here. You can easily to select the computer name without checking the IP address of the computer.
Page 110 following message will be displayed on your web browser: Please click ‘Go Back’ to go back to previous setup menu, or click ‘Apply’ to reboot the router so the settings will take effect. Please wait 30-60 seconds for the router to reboot...
Page 111: Virtual Server
4-2-3 Virtual Server This function allows you to redirect a port on Internet IP address (on WAN port) to a specified port of an IP address on the local network. This allows you to setup an Internet service on the computer on the local network, without exposing it on the Internet directly.
Page 112 router will be listed here. You can easily to select the computer name without checking the IP address of the computer. Private Port (4): Input the port number of the IP address which provides Internet service. Type (5): Select the type of connection, TCP or UDP. If you’re not sure, please select ‘Both’.
Page 113 Please click ‘Continue’ to go back to previous setup menu, or click ‘Apply’ to reboot the router so the settings will take effect. Please wait 30-60 seconds for the router to reboot. If you want to reset all settings in this page back to previously saved value, please click ‘Cancel’...
Page 114: Port Mapping For Special Applications
4-2-4 Port Mapping for Special Applications Some applications require more than one connection at a time; these applications won’t work with simple NAT rules. In order to make these applications work, you can use this function to let these applications work. Please click ‘General Setup’...
Page 115 TCP Port to Open (4): This is the out going (Outbound) range of TCP port numbers for this particular application. UDP Port to Open (5): This is the out going (Outbound) range of UDP port numbers for this particular application. Comment (6): The description of this setting.
Page 116 Note: Only one LAN client can use a particular special application at a time. After you finish with all the settings, please click ‘Apply’ (14) button and the following message will be displayed on your web browser: Please click ‘Go Back’ to go back to previous setup menu, or click ‘Apply’ to reboot the router so the settings will take effect.
Page 117: Upnp Setting
4-2-5 UPnP Setting This function enables network auto-configuration for peer-to-peer communications, with this function, network devices will be able to communicate with other devices directly, and learn about information about other devices. Many network device and applications rely on UPnP function nowadays.
Page 118 Please click ‘Continue’ to go back to previous setup menu, or click ‘Apply’ to reboot the router so the settings will take effect. Please wait 30-60 seconds for the router to reboot.
Page 119: Alg Settings
4-2-6 ALG Settings Application Layer Gateway (ALG) is a special function of this router. It includes many preset routing rules for numerous applications which require special support. With these supports, those applications which required special support will be able to work with NAT architecture. Please click ‘General Setup’...
Page 120 Please click ‘Go Back’ to go back to previous setup menu, or click ‘Apply’ to reboot the router so the settings will take effect. Please wait 30-60 seconds for the router to reboot.
Page 121: Firewall
4-3 Firewall Besides NAT, this router also provides firewall function to block malicious intruders from accessing your computers on local network. These functions include inbound attack prevention, and block outbound traffics, like block URLs which have pre-defined keywords. Please follow instructions to enable or disable firewall function: Please click ‘General Setup’...
Page 122 Please click ‘Go Back’ to go back to previous setup menu, or click ‘Apply’ to reboot the router so the settings will take effect. Please wait 30-60 seconds for the router to reboot...
Page 123: Access Control
4-3-1 Access Control This function allows or denies computers with specific MAC address from connecting to the network; it can also allow or deny computers with specific IP address, protocol, or port. Please click ‘General Setup’ at the top of web management interface and click ‘Firewall’...
Page 124 will be able to connect to the network, and rejecting all other network devices. Client PC Please input the MAC address of computer or network MAC Address (2): device here, dash ( - ) or colon ( : ) are not required. (i.e. If the MAC address label of your wireless device indicates ‘aa-bb-cc-dd-ee-ff’...
Page 125 be able to connect to the network, and rejecting all other network devices. IP Filtering All existing IP addresses in filtering table will be listed Table (10): here. Add PC (11): Click this button to add a new IP address to IP filtering table, up to 20 IP addresses can be added.
Page 126 4-3-1-1 Add PC After button is clicked, the following message will be displayed on your web browser:...
Page 127 Client PC Please input any text to describe this IP Description (1): address, up to 16 alphanumerical characters. Client PC IP Please input the starting IP address in the left address (2): field, and input the end IP address in the right field to define a range of IP addresses, or just input the IP address in the left field to define a single IP address.
Page 128: Url Blocking
4-3-2 URL Blocking If you want to prevent computers in a local network from accessing certain website (like pornography, violence, or anything you want to block), you can use this function to stop computers in a local network from accessing the site you define here.
Page 129 http://www.blocked-site.com or http://11.22.33.44), or the keyword which is contained in URL, such as pornography, cartoon, stock, etc.). Add (3): Click ‘Add’ button to add the URL / keyword to the URL / Keyword filtering table. Reset (4): Click ‘Reset’ to remove the value you inputted in URL/Keyword field.
Page 131: Dos Attack Prevention
4-3-3 DoS Attack Prevention Denial of Service (DoS) is a common attack measure, by transmitting a great amount of data or request to your Internet IP address and server, the Internet connection will become very slow, and server may stop responding because it is not capable of handling too much traffic.
Page 132 connection become very slow, even unusable. Check this box and the router will ignore all inbound PING request, but when you activate this function, you will not be able to ping your own router from internet, too. Port Scan (3): Some malicious intruder will try to use a ‘port scanner’...
Page 133 will be displayed on your web browser: Ping of Death (1): Set the threshold of when this DoS prevention mechanism will be activated. Please check the box of Ping of Death, and input the frequency of threshold (how many packets per second, minute, or hour), you can also input the ‘Burst’...
Page 134 After you finish with all settings, please click ‘Apply’ (5) button and the following message will be displayed on your web browser: Please click ‘Go Back’ to go back to previous setup menu, or click ‘Apply’ to reboot the router so the settings will take effect. Please wait 30-60 seconds for the router to reboot...
Page 135: Demilitarized Zone (Dmz)
4-3-4 Demilitarized Zone (DMZ) Demilitarized Zone (DMZ) refers to a special area in your local network. This area resides in the local network, and all computers in this area use private IP addresses, too. However, these private IP addresses are mapped to a certain Internet IP address, so other users on the Internet can fully access those computers in DMZ.
Page 136 address (2): If you select ‘Dynamic IP’, you have to select an Internet connection session from dropdown menu; if you select ‘Static IP’, please input the IP address that you want to map to a specific private IP address. Client PC IP Please input the private IP address that the Internet IP address (3): Address will be mapped to.
Page 137 Please click ‘Go Back’ to go back to previous setup menu, or click ‘Apply’ to reboot the router so the settings will take effect. Please wait 30-60 seconds for the router to reboot.
Page 138: System Status
4-4 System Status The functions described here will provide you with system related information. To enter system status menu, please either click ‘Status’ link located at top of web management interface. 4-4-1 System information and firmware version You can use this function to know the system information and firmware version of this router.
Page 139: Internet Connection Status
4-4-2 Internet Connection Status You can use this function to know the status of current Internet connection. Please click ‘Status’ menu at the top of web management interface, and then click ‘Internet Connection’ on the left hand column. The following message will be displayed on your web browser: NOTE: Information displayed here may vary.
Page 140: Home Network
4-4-3 Home Network You can use this function to know the status of your router. Please click ‘Status’ menu at the top of web management interface, and then click ‘Home Network’ on the left hand column. NOTE: Information displayed here may vary.
Page 141: System Log
4-4-4 System Log All important system events are logged. You can use this function to check the event log of your router. Please click ‘Status’ menu at the top of web management interface, and then click ‘System Log’ on the left hand column. The system events will be displayed in this page, and here are descriptions of every buttons: Save (1):...
Page 142: Security Log
4-4-5 Security Log All information about network and system security is kept here, and you can use this function to check the security event log of your router. Please click ‘Status’ menu at the top of web management interface, and then click ‘Security Log’...
Page 143: Active Dhcp Client List
4-4-6 Active DHCP client list If you’re using the DHCP server function of this router, you can use this function to check all active DHCP leases issued by this router. Please click ‘Status’ menu at the top of web management interface, and then click ‘Active DHCP Client’...
Page 144: Statistics
4-4-7 Statistics You can use this function to check the statistics of wireless, LAN, and WAN interface of this router. Please click ‘Status’ menu at the top of web management interface, and then click ‘Statistics’ on the left hand column. You can click ‘Refresh’...
Page 145: Tools
4-5 Tools You can backup all configurations of this router to a file, so you can make several copied of router configuration for security reason. To backup or restore router configuration, please follow the instructions: Please click ‘Tool’ menu at the top of web management interface, and then click ‘Configuration Tools’...
Page 146 settings.
Page 147: Firmware Upgrade
4-6 Firmware Upgrade The system software used by this router is known as ‘firmware’, just like any applications on your computer, when you replace the old application with a new one; your computer will be equipped with new function. You can also use this firmware upgrade function to add new functions to your router, even fix the bugs of this router.
Page 148 Click ‘Browse’ button, and you’ll be prompted to provide the filename of the firmware upgrade file. Please download the latest firmware file from the Hawking Technologies website at www.hawkingtech.com, and use it to upgrade your router. After a firmware upgrade file is selected, click ‘Apply’ button, and the router will start firmware upgrade procedure automatically.
Page 149: System Reset
4-7 System Reset If you think you network performance is bad, or you find the behavior of the router is strange, you can perform a router reset. Sometimes it will solve the problem. Please click ‘Tool’ menu at the top of web management interface, and then click ‘Reset on the left hand column.
Page 150: Chapter V: Appendix
Chapter V: Appendix 5-1 Hardware Specification CPU + Wireless Chipsets：Realtek RTL8196C+RTL8192CE Flash: 2MB SDRAM: 16MB WAN Port: 10/100M UTP Port x 1 LAN Ports: 10/100M UTP Port x 4 Antenna: 2x 3dBi Dipole antennas Power: 12VDC, 1A Switching Power Adapter Output Power spec: 11n (40MHz)@MCS15: 23+/-1.5dBm 11n (20MHz)@MCS15: 23+/-1.5dBm...
Page 151: Troubleshooting
5-2 Troubleshooting If you find that the router is working improperly or stops responding, check some of the FAQs below. You can also contact our support by email or phone. Scenario Solution Router is not a. Please check the connection of power cords responding to me and network cables of this router.
Page 152 directly before, try to do that again, and check if you can get connected to Internet with your computer directly attached to the device provided by your Internet service provider. d. Check PPPoE / L2TP / PPTP user ID and password again.
Page 153 really slow. e. If this has never happened before, call your Internet service provider to know if there is something wrong with their network. I can’t log onto web a. Make sure you’re connecting to the correct management interface: IP address of the router! password is wrong b.
Page 154: Glossary
5-3 Glossary Default Gateway (Router): Every non-router IP device needs to configure a default gateway’s IP address. When the device sends out an IP packet, if the destination is not on the same network, the device has to send the packet to its default gateway, which will then send it out towards the destination.
Page 155 1’s followed by consecutive trailing 0’s, such as 11111111.11111111.11111111.00000000. Therefore sometimes a network mask can also be described simply as “x” number of leading 1’s. When both are represented side by side in their binary forms, all bits in the IP address that correspond to 1’s in the network mask become part of the IP network address, and the remaining bits correspond to the host ID.
Page 156 Port: Network Clients (LAN PC) uses port numbers to distinguish one network application/protocol over another. Below is a list of common applications and protocol/port numbers: Application Protocol Port Number Telnet SMTP POP3 H.323 1720 SNMP SNMP Trap HTTP PPTP 1723 PC Anywhere TCP 5631 PC Anywhere UDP...
Page 157 Subnet Mask: A subnet mask, which may be a part of the TCP/IP information provided by your ISP, is a set of four numbers (e.g. 255.255.255.0) configured like an IP address. It is used to create IP address numbers used only within a particular network (as opposed to valid IP address numbers recognized by the Internet, which must be assigned by InterNIC).
