Digital Display Manual
By default, the Digital Display will cycle between the indoor, outdoor and auxiliary
temperature (about three seconds per value). Three small circular indicator
lights are located to the right of the temperature readout box, labeled "Indoor",
"Outdoor", and "Aux". These lights indicate which temperature value is currently
being displayed. To "freeze" the display on a particular value press the "Select"
button to the left of the temperature box when that value is being displayed.
Pressing the "Select" button again will return the display to cycling automatically
between all three values.
NOTE: Younger students may find it easier to read the display if the temperature
is "locked" in on the outdoor temperature.
To the right of the temperature box are trend arrows in the form of upward and
downward pointing triangles. Trends are available for each of the temperature
values. If the display is in automatic cycle mode, the appropriate trend arrows
will also cycle with it. If the upward pointing triangle is illuminated then the
temperature trend is rising (increasing). If the downward pointing triangle is
illuminated then the temperature trend is falling (decreasing). If neither of the
triangles are illuminated then the temperature is steady (not changing). To view
rates of change and daily minimum and maximum values for temperature, refer
to sections 3.3 and 3.4 of this manual.
Wind Chill / Heat Index
The wind chill / heat index values are displayed just beneath the temperature
box. Wind chill and heat index values can be displayed in the English units of
degrees Fahrenheit (F) or the Metric units of degrees Celsius (C). By default the
English units are displayed. To change the measurement units, refer to section
3.2 of this manual.
The Digital Display automatically determines which value to display. If the
outdoor temperature is below 60 degrees F then the wind chill index is displayed.
If the outdoor temperature is 60 degrees F or above then the heat index is
displayed. The two small circular lights to the right of the wind chill / heat index
box (labeled "Wind Chill" and "Heat Index") indicate which value is currently
being displayed.
Dew Point / Wet Bulb
The dew point and wet bulb temperatures share a readout box just below the
wind chill and heat index values. Dew point and wet bulb temperature values can
