WCW100 Wireless Camera
Wireless Antenna (WCW100 Only)
Rotate the wireless antenna onto the threaded post to ensure clear wireless
communication. Antenna can be adjusted to obtain a better signal. Best results
are usually obtained by positioning the antenna vertically.
Camera Stand
Install the camera stand to provide a steady base for the camera.
1.
Loosen the plastic nut on the back of the camera.
2.
Rotate the threaded post upwards.
3.
Rotate the camera onto the threaded post until it stops.
4.
Tighten plastic washer against camera to secure.
Camera User Guide
There are two cameras available for use with Schlage
LiNK.
WCW100
The WCW100 is a wireless camera that communicates
with the LiNK system through your existing wireless
router.
WCE100
The WCE100 is a wired camera that communicates with
the LiNK system through your existing router.
DO NOT connect Ethernet or power before
!
enrolling the camera.
For indoor use ONLY!
WCE100 Wired Camera
Attaching the Antenna
Threaded
Post
Attaching the Camera to the Stand
W ER
PO
O RK
TW
NE
Plastic
Washer
Plastic
Nut
Advertisement
Related Manuals for Schlage LiNK WCW100
Summary of Contents for Schlage LiNK WCW100
-
Page 1: Camera Stand
Camera User Guide There are two cameras available for use with Schlage LiNK. WCW100 The WCW100 is a wireless camera that communicates with the LiNK system through your existing wireless router. WCE100 W ER W ER O RK O RK The WCE100 is a wired camera that communicates with the LiNK system through your existing router. -
Page 2: Privacy Button
Power, Ethernet and MAC ID DO NOT connect power and Ethernet until instructed to do so by the web site, during the enrollment process. WCW100 MAC ID is located on the label on the back of the camera. XXXXXXXXXX XXXXXXXXXX... -
Page 3: Rebooting The Camera
Enrolling the Camera Camera enrollment is done using the www.schlagelink.com web site. You must have an active account before enrolling the camera. Make sure Ethernet and power are not plugged in to the camera. Log on to your account at www.schlagelink.com. Click the Cameras tab. -
Page 4: Troubleshooting And Faq
Troubleshooting and FAQ I am having trouble entering my SSID into the web interface (www.schlagelink.com). The SSID is case-sensitive. If there is a space in your SSID, change the SSID so there is no space and try again. If your SSID is not showing up on the web interface, it may not be broadcast. Reference the instructions that came with your router for more information. - Page 5 Can I use cameras from other manufacturers? Not at this time. The Schlage LiNK camera is designed to provide a secure video connection, along with easy plug and play installation, not currently available with other cameras. Check link.schlage.com for updates.
