Setting items
Set Defaults Yes : Reset to the defaults.
The "Levels" settings are No : Do not reset to the defaults.
returned to the default
When you select "Set Defaults" and press
settings.
ENTER
, the "Return settings to the default?"
prompt is displayed. Select either "Yes" or
"No", and press
Crossovers
Set the maximum frequency of the bass signal output from each channel to the subwoofer.
Set the Crossover Frequency to suit the bass reproduction capability of the speaker being used.
Setting items
40Hz / 60Hz / 80Hz / 90Hz / 100Hz / 110Hz / 120Hz / 150Hz / 200Hz /
Front / Center / Surround
Select speaker for setting of 250Hz : Set the crossover frequency.
crossover frequency.
• "Crossovers" can be set when the "Bass" – "SW Mode" (vpage 36)
setting is "LFE+Main", or when you have a speaker that is set to
"Small".
• The default crossover frequency is "80Hz", which will work best with the
widest variety of speakers. When using very small speakers, however,
you can choose a higher setting based on the specified frequency
response of the speakers. If the speaker has a specified frequency
response of 120 Hz – 20 kHz (as an example), then choose the 120 Hz
crossover frequency.
• For speakers set to "Small", low frequency content below the crossover
frequency is attenuated to the speakers and the low bass content is then
re-delivered to the subwoofer(s), or the front (L/R) speakers if they have
been set to Large.
DVD
Setting details
ENTER
ENTER
.
BACK SETUP
Default settings are underlined.
Setting details
Bass
Set subwoofer and LFE signal range playback.
Setting items
80Hz / 90Hz / 100Hz / 110Hz / 120Hz / 150Hz / 200Hz / 250Hz : Set LFE
LPF for LFE
Set LFE signal playback signal range playback.
range. Set this when you
want to change the playback
frequency (low pass filter
point) of the subwoofer.
SW Mode LFE : The low range signal of the channel set to "Small" speaker size is
Select low range signals added to the LFE signal output from the subwoofer.
to be reproduced by LFE+Main : The low range signal of all channels is added to the LFE
subwoofer. signal output from the subwoofer. This is usually the best setting for most
systems.
• "SW Mode" can be set when "Speaker Config." – "Subwoofer"
(vpage 35) is set to other than "No".
• Play music or a movie source and select the mode offering the strongest
bass.
• Select "LFE+Main" if you want the bass signals to always be produced
from the subwoofer.
NOTE
If "Front" and "Center" for "Speaker Config." are set to "Large", and
"SW Mode" is set to "LPF for LFE", no sound may be output from the
subwoofers, depending on the input signal or selected surround mode.
36
Speakers
Default settings are underlined.
Setting details
