Preset Skip
Set the preset memory block (from A to G) you do not want to display.
Setting items
Block A – Block G On : Display the selected preset memory block.
Select a block to be skipped SKIP : Do not display the selected preset memory block.
from among preset blocks
(from A to G).
TUNER
Source Level
This function corrects the playback level of the selected input source's audio input.
Make this setting if there are differences in the input volume levels between the different sources.
Setting items
Source Level –12dB – +12dB (0dB)

Input Select

Set the audio input mode and decode mode of each input source.
The input modes available for selection may vary depending on the input source.
Setting items
Input Mode Auto : Automatically detect input signal and perform playback.
Set the audio input modes HDMI : Play only signals from HDMI input.
for the different input Digital : Play only signals from digital input (OPTICAL/COAXIAL).
sources. Analog : Play only signals from analog input.
It is normally recommended
• At time of purchase, the settings of the different input sources are as
to set the audio input mode
shown below.
to "Auto".
Input source
Default setting
Input source
Default setting
DVD
Default settings are underlined.
Setting details
Default settings are underlined.
Setting details
Default settings are underlined.
Setting details
CBL/SAT DVD Blu-ray GAME
Auto Analog HDMI HDMI
AUX TV AUDIO PORTABLE
HDMI Digital Analog
Setting items
Input Mode
(Continued)
• "Digital" can be set for the input source assigned to "OPTICAL" or
"COAXIAL" under "Input Assign" in the menu.
• If the input source is set to "Blu-ray", "GAME", "AUX" or "TV AUDIO",
it cannot be set to "Analog".
• If an input source is "TUNER" or "PORTABLE" the setting is fixed to
"Analog".
• When digital signals are properly input, the
the display. If the
connector assignment and the connections.
Decode Mode Auto : Detect type of digital input signal and decode and play automatically.
PCM : Decode and play only PCM input signals.
Set the audio decode mode
for input source. DTS : Decode and play only DTS input signals.
CBL/SAT DVD
• This item can be set for input sources for which "OPTICAL" or
Blu-ray GAME
"COAXIAL" is assigned at "Input Assign" (vpage 32).
AUX TV AUDIO
• This item can be set for HDMI input sources (CBL/SAT, Blu-ray, GAME
PORTABLE
or AUX).
• Normally set this mode to "Auto". Set "PCM" and "DTS" when
inputting the corresponding input signal.
Video Source
Video of another input source is played back combined with the playing audio.
Setting items
Default : Play the picture and sound of the input source.
Video Select
CBL/SAT / DVD : Select video input source to view. The video of the
selected input source is played along with the audio currently being
played. This can be set for individual input sources.
NOTE
It is not possible to select HDMI input signals.
33
Inputs
Setting details
indicator lights on
indicator does not light, check the digital input
Default settings are underlined.
Setting details
