Right View; Rear View - Acer Extensa 5620 User Manual

Icon Item
8 ExpressCard/54
slot
9 PC Card slot eject
button
10 PC Card slot

Right view

# Item
1 Optical drive
2 Optical disk
access indicator
3 Optical drive
eject button
4 Emergency eject
hole

Rear view

Icon Item
1 Three USB 2.0
ports
2 Modem (RJ-11)
port
Description
Accepts one ExpressCard/54 module.
Ejects the PC Card from the slot.
Accepts one Type II PC Card.
Description
Internal optical drive; accepts CDs or DVDs
Lights up when the optical drive is active.
Ejects the optical disk from the drive.
Ejects the optical drive tray when the computer is
turned off.
Description
Connect to USB 2.0 devices (e.g., USB
mouse, USB camera).
Connects to a phone line.
17
