GTLT2 USER MANUAL
GPS
Vehicle
Tracker
User Manual
V6.4
GTLT2
Page 1 of 21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GTLT2 and is the answer not in the manual?

Questions and answers

Related Manuals for Ascend Group GTLT2

Summary of Contents for Ascend Group GTLT2

  • Page 1 GTLT2 USER MANUAL Vehicle Tracker User Manual V6.4 GTLT2 Page 1 of 21...

  • Page 2: Table Of Contents

    GTLT2 USER MANUAL Table of Contents 1. Product Overview....................................…..3 2. Specification………………………………………………………………………………………………………………………………4 3. Wiring Installation......................................5 3.1. Product Parts List .....................................5 3.2. Precaution before Installation ................................5 3.3. Installation......................................5 4. SMS Command List....................................8 5. Track by 900D web based tracking software………………………………………………………………………..………………..18 6.Troubleshooting………………………………………………………………………………………………………………………….20 ……………………………………..………….

  • Page 3: Product Overview

    1. Product Overview Thank you for your purchase of GTLT2 Vehicle GPS Tracker.The GTLT2 GPS/GSM Tracker is a vehicle remote position device with build-in GPS and GSM/GPRS modules. It is a small size, high accuracy remote location tracking device. Based on GPS satellite, it provides accurate position information under dynamic conditions.

  • Page 4: Specification

    GTLT2 USER MANUAL off state by the customer, it cannot ensure successful transmission. For safety reason, do not tell the other people your GTLT2 mobile number, without taking precautions. Otherwise, your privacy may be compromised along with other safety problem.

  • Page 5: Wiring Installation

    Check if all the wiring has been connected correctly; then connect the GPS Tracker unit to the power supply. We don't provide the SIM card 3.3. INSTALLATION 3.3.1 Step 1: Install SIM Card Remove the back cover of GTLT2. Insert the SIM card by sliding it into the card slot. Page 5 of 21...
  • Page 6 GTLT2 USER MANUAL Connect battery Put back the back cover. Make sure to turn off the power before install the SIM card. Make sure to deactivate the PIN code, so that the SIM card can operate without PIN protection. Before install the SIM card to the GPS Tracker, please use a mobile phone to make sure the SIM card can make &...
  • Page 7 GTLT2 USER MANUAL ------ 3.3.2 Wiring Description： 3.3.3 Description of GTLT2 LED : LED State Description Green LED--- indicate the GPS signal state State Means No Lighting Working, but no location or GPS module has turn off. Flashing Working and has located...

  • Page 8: Sms Command List

    (1) Receiving SOS alert message: After press SOS button, GTLT2 will send sms alert and location coordinates to the first authorize phone number. (2) Receiving Geo fence alert message: when the GTLT2 is in or out of the preset square, GTLT2 will send send sms alert and location coordinates to the first authorize phone number.
  • Page 9 X=0-999,in the unit of seconds (2) X=0, close history data uploading function (3) GTLT2 can store 3000 waypoints, each waypoint is 100B(Byte). If more than 3000 waypoints, the new waypoint will override the old waypoint directly. (4) If GTLT2 is in power saving mode, and remain still. The history data uploading function will close automatically, until GTLT2 is activated by incoming sms/phone call.
  • Page 10 GTLT2 USER MANUAL Remarks: The password will be changed from 0000 to 1234 Track on Demand-Reply with longitude, 666**** 6660000 latitude, speed and date Remarks: Get the current location of the tracker, send this SMS or make a telephone call directly to the tracker and it will report its longitude and...
  • Page 11 GTLT2 USER MANUAL Date: 2008-04-25 Time: 16:39:45 BS: 25ee0dff Fix: V ID: 353686009002030 STATE: SMS Note: If in the cold start and GPS no position, it will return to the void of information: eg: ERROR GPS GPRMC FRAME DATA BS: 27971054”...
  • Page 12 ACC detecting charge function Remarks:GTLT2 via external ACC cable to check car ACC state, when car moving (ACC ON), GTLT2 built-in battery will charge by car battery, when car stops (ACC OFF),GTLT2 built-in battery will stop charge by car battery.
  • Page 13 Remark: S030 means the GPS module of GTLT2 will close for 30minutes first L01 means the gps module of GTLT2 will open for 1 minute in this stage, if the GTLT2 can get location in 1 minute, then it will not go into the next stage;...
  • Page 14 (2) zzz.z is the radius from 0.1KM to 999.9KM, If the decimal point of Rzzz.z is 0, you cannot omit the 0. For example,radius is 1KM, you need to send 0050000R1.0 (3) After set successfully, the GTLT2 will reply: SET GEO-FENCE OK Example: 0030000E11406.0024N2233.4230R0.5 Set Single Geo-fence Alarm: The second 005****Rzzz.z...
  • Page 15 (1) 211****: Turn on single geo-fence alarm When the GPS tracker is in/out of the preset square, GTLT2 will send sms alert and location coordinates to the first authorize phone number, Meanwhile, GTLT2 will call the first authorized phone number first; if failed, then call the second authorized phone number; if failed once again, then call the third authorized phone number.
  • Page 16 GTLT2 USER MANUAL UP:0000 (GPS Tracker user Password) SC:,0000 (SMS platform Number,Password) *RCONF# *RCONF# Read All Parameters Remarks: This is the command to read all the present parameters including sms/gprs mode,interval,ip,port.etc. Information explain: IMEI: (IMEI Number) MOD: SMS P2P(SMS mode) /SMS SC(SMS platform mode)/GPRS(GPRS mode)
  • Page 17 GTLT2 USER MANUAL List of default state: Parameter Default State Working Mode Pre-set phone numbers Null GPS Tracker user Password 0000 ACC Switch status Prompt Send regularly location information The number of returned base station Press SOS button to call out...

  • Page 18: Track By 900D Web Based Tracking Software

    (3)Upload location data interval=T*N N=0, close upload data by preset interval, the gps tracker will reply ”GPRS Timer Stop” 805 : Command code For example: #805#0000#30#1## 0000: password, default 0000 In this example: GTLT2 will send location every 30 Page 18 of 21...
  • Page 19 809 : Command code For example: #809#0000#1800#1## 0000: password, default 0000 In this example: GTLT2 will send location every half an hour, 1 location reports per time when car stop。(ACC OFF) http://www1.igpstracking.net/ 5.6. Please go to Enter the user name and password we provided.
  • Page 20 SIM card: the SIM card phone number you put in GTLT2. Terminal ID: On the packing box of GTLT2, you can find the a white label writes “Terminal ID". Terminal ID is cf8866fefca898ef here. Click "Submit", and then you add the car successfully on the software 900d Wait few seconds, and you will see the GPS Tracker online icon on software Put a check mark on the device, and right click, you will see the menu as below picture.

  • Page 21: Troubleshooting

    GPRS function of GTLT2 is turned off Turn on GPRS function of GTLT2. Incorrect IP address or PORT Get the right IP address and PORT and reset to GTLT2 GSM signal is weak Move the unit to a location with good GSM reception.
