GTLT3 USER MANUAL
GPS
Vehicle
Tracker
User Manual
V1.2
GTLT3
Page 1 of 12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GTLT3 and is the answer not in the manual?

Questions and answers

Related Manuals for Ascend Group GTLT3

Summary of Contents for Ascend Group GTLT3

  • Page 1 GTLT3 USER MANUAL Vehicle Tracker User Manual V1.2 GTLT3 Page 1 of 12...

  • Page 2: Table Of Contents

    GTLT3 USER MANUAL Table of Contents 1. Product Overview....................................…..3 2. Specification………………………………………………………………………………………………………………………………4 3. Wiring Installation......................................4 3.1. Product Parts List .....................................5 3.2. Precaution before Installation ................................5 3.3. Installation......................................5 4. SMS Command List....................................7 5. Track by 900D web based tracking software………………………………………………………………………..………………..9 ……………………………………..…………. Contacts……………………………………………………………...

  • Page 3: Product Overview

    1. Product Overview Thank you for your purchase of GTLT3 Vehicle GPS Tracker.The GTLT3 GPS/GSM Tracker is a vehicle remote position device with build-in GPS and GSM/GPRS modules. It is a small size, high accuracy remote location tracking device. Based on GPS satellite, it provides accurate position information under dynamic conditions.

  • Page 4: Specification

    GTLT3 USER MANUAL Otherwise, your privacy may be compromised along with other safety problem. 2. Specification GSM 850/900/1800/1900 quad-band GPRS:Class 12,TCP/IP GSM module GPS sensitivity -164dB C/A Code 1.023MHz chip rate Channels 210 channel all-in-view tracking GPS frequency L1,1575.42MHz GPS Position Accuracy...

  • Page 5: Product Parts List

    GTLT3 USER MANUAL 3.1. Product Parts List GPS Tracker Unit SOS Button and Socket cables Mic(Optional) Relay(Optional) 3.2. Precaution before Installation Check if all the parts are included. Prepare a SIM card for GSM communication. Use some other mobile phone to confirm that the PIN code has not been set and that it can dial out and receive telephone calls and SMS without problem.
  • Page 6 SIM card can make & receive phone calls without problem. Before install the SIM card to the GPS Tracker, please use a mobile phone to empty the SMS storage of the SIM card. 3.3.2 Wiring Description： 3.3.3 Description of GTLT3 LED : Page 6 of 12...

  • Page 7: Sms Command List

    "set success!” otherwise need to set again. Send the corresponding commands the device will reply the corresponding results. Description SMS Command Example Set control authority any,1# any,1# Remarks: if any,0# means is only center number can control GTLT3. Set the center number(Default null) admin123456,13812345678 admin123456,13812345678 Page 7 of 12...
  • Page 8 GTLT3 USER MANUAL Delete the center number noadmin123456,d noadmin123456,d Remarks: Default is no center number, any mobile phone can set GPS tracker by SMS command; once you set center number, only the center number can set GPS tracker by SMS command.
  • Page 9 GTLT3 USER MANUAL Cut off main power alarm Remarks: when the main power is off, GPS tracker will send main power off alarm and present location to 900d gps platform, and one alarm SMS to center number, and call the 3 sos specific phone numbers by turns( call 6 times total if no one answer the call, 6 minutes interval each time)

  • Page 10: Track By 900D Web Based Tracking Software

    Default language 0,time zone 0 For example: lang,0,zone,8 5.3 Set APN (if can not connect to 900D platform,so need set APN, if can connect to 900D platform,please omit this step.Because GTLT3 has been built-in Global APN,GTLT3 will automatically identify APN) Command...
  • Page 11 Terminal Type: Do not choose. SIM card: the SIM card phone number you put in GTLT3 or any number. Terminal ID: On the vehicle of GTLT3, you can find the “Terminal ID”.

  • Page 12: Contacts

    GTLT3 USER MANUAL Click "Submit", and then you add the GPS tracker GTLT3 successfully on the software 900D. Wait few seconds, and you will see the GPS Tracker online icon on software Put a check mark on the device, and right click, you will see the menu as below picture. Now you can track online.
