Declaration Of Conformity - Infinity reference 1050w Instructions

S
PECIFICATIONS
850w
Diameter: 8" (200mm)
Sensitivity @ 2.83V/1m: 91dB
Power Handling (RMS): 200W
Power Handling (Peak): 800W
Frequency Response: 30Hz – 400Hz
Impedance: 4 ohms
Voice-Coil Diameter: 2" (51mm)
Mounting Depth: 4-5/16" (110mm)
Overall Diameter: 8-1/4" (210mm)
Cutout Diameter: 7-1/16" (179mm)
A valid serial number is required for warranty coverage.
Features, specifications and appearance are subject to change without notice.
These products are designed for mobile applications and are not intended for connection to the mains.
Infinity Systems • 250 Crossways Park Drive, Woodbury, NY 11797 USA
FAX 516.682.3523 • www.infinitysystems.com
© 2005 Harman International Industries, Incorporated. All rights reserved. • Part No. INFREFSUBS 11/05
¤
1050w 1052w
10" (250mm) 10" (250mm)
91dB 91dB
250W 250W
1000W 1000W
25Hz – 400Hz 25Hz – 400Hz
4 ohms 2 or 8 ohms
2" (51mm) 2" (51mm)
4-9/16" (116mm) 4-9/16" (116mm)
10-3/8" (264mm) 10-3/8" (264mm)
9-1/8" (232mm) 9-1/8" (232mm)
1250w 1252w
12" (300mm) 12" (300mm)
93dB 93dB
300W 300W
1200W 1200W
23Hz – 400Hz 23Hz – 400Hz
4 ohms 2 or 8 ohms
2" (51mm) 2" (51mm)
5-1/16" (129mm) 5-1/16" (129mm)
12-7/16" (316mm) 12-7/16" (316mm)
11-3/16" (284mm) 11-3/16" (284mm)

Declaration of Conformity

We, Harman Consumer Group International
2, route de Tours
72500 Château-du-Loir
France
declare in own responsibility that the products described
in this owner's manual are in compliance with technical
standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Klaus Lebherz
Harman Consumer Group International
Château-du-Loir, France 11/05
