Declaration Of Conformity - Infinity Reference 1042W Instructions

S
PECIFICATIONS
840w
Diameter: 8" (200mm)
Sensitivity @ 2.83V/1m: 91dB
Power Handling (RMS): 200W
Power Handling (Peak): 800W
Frequency Response: 30Hz – 400Hz
Impedance: 4 ohms
Voice Coil Diameter: 2" (51mm)
Mounting Depth: 4-5/16" (110mm)
Overall Diameter: 8-1/4" (210mm)
Cut-Out Diameter: 7-1/16" (179mm)
A valid serial number is required for warranty coverage.
Features, specifications and appearance are subject to change without notice.
Infinity Systems • 250 Crossways Park Drive, Woodbury, NY 11797 USA
FAX 516.682.3523 • www.infinitysystems.com
© 2005 Harman International Industries, Incorporated • Part No. INFREFSUBS1/05
¤
1040w 1042w
10" (250mm) 10" (250mm)
91dB 91dB
250W 250W
1000W 1000W
25Hz – 400Hz 25Hz – 400Hz
4 ohms 2 or 8 ohms
2" (51mm) 2" (51mm)
4-9/16" (116mm) 4-9/16" (116mm)
10-3/8" (264mm) 10-3/8" (264mm)
9-1/8" (232mm) 9-1/8" (232mm)
1240w 1242w
12" (300mm) 12" (300mm)
93dB 93dB
300W 300W
1200W 1200W
23Hz – 400Hz 23Hz – 400Hz
4 ohms 2 or 8 ohms
2" (51mm) 2" (51mm)
5-1/16" (129mm) 5-1/16" (129mm)
12-7/16" (316mm) 12-7/16" (316mm)
11-3/16" (284mm) 11-3/16" (284mm)

Declaration of Conformity

We, Harman Consumer International
2, route de Tours
72500 Chateau-du-Loir
France
declare in own responsibility that the products described
in this owner's manual are in compliance with technical
standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Klaus Lebherz
Harman Consumer Group International
Chateau-du-Loir, France 1/05
