Page 1: Spray Gun
MODEL H8222 SPRAY GUN INSTRUCTION MANUAL COPYRIGHT © AUGUST, 2007 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. #TR9786 PRINTED IN CHINA... -
Page 2: Safety Instructions For Spray Guns
To reduce your risk, only use the spray gun in a well ventilated area with adequate supply of fresh air. Model H8222 Spray Gun SAFETY Indicates an imminently hazardous situation which, if not avoided, WILL result in death or serious injury. - Page 3 19. SOLVENTS. Always store solvents and shop towels soaked in solvent in approved containers. 20. LOCAL authorities regarding exhaust and waste disposal requirements. MATERIAL LABELS LAWS. Consult local Model H8222 Spray Gun...
-
Page 4: Specifications
INTRODUCTION Foreword The specifications, details, and photographs in this manual represent the Model H8222 as supplied when the manual was prepared. However, owing to Grizzly’s policy of continuous improvement, changes may be made at any time with no obligation on the part of Grizzly. - Page 5 1. Attach the gun body to the cup as shown in Figure 2. Connection Point Figure 2. Model H8222 gun body 2. Attach the air hose directly to the air fitting on the spray gun or with a female (not included).
- Page 6 Air Flow Control: Controls the fluid pressure inside the spray gun. Cup: Holds up to 1000cc of material for spraying. Model H8222 Spray Gun Cup Removal & Installation The cup is removed/installed by loosen- ing/tighting the cup lock cover and engag- ing/disengaging the cup pins in the cup cover groove (see Figure 4).
-
Page 7: Explosion Hazard
OPERATIONS The Model H8222 siphon feed spray gun set is designed to spray a wide variety of materials such as lacquers, stains, prim- ers, multi-component paints, clear coats, acrylics, epoxies etc. - Page 8 Model H8222 Spray Gun 10. Begin spraying 2-3 inches before the work and continue to the end of the work. Continue the motion for a few inches past the work until you are ready for the return stroke.
-
Page 9: Atomizing Cap And Fan Adjustments
Rotating the pattern adjustment knob (see Figure 3) changes the shape of the spray pattern from a wide spray to a narrow spray, as shown in Figure 9. Pattern Figure 9. Fan adjustment. Model H8222 Spray Gun... - Page 10 Features 200 PSI rating, 800 PSI bursting strength, and ⁄ " NPT ends. Figure 11. Red rubber air hose. Model H8222 Spray Gun H7274—Campbell Hausfeld™ Pressure Regulator Since PSI drops through lengths of air hose, attaching a regulator directly to the spray gun ensures accurate air regulation for the best results possible.
-
Page 11: Maintenance
DO NOT soak the spray gun body in solvent. Prolonged exposure to sol- vent will rapidly deteriorate the spray gun washers and seals. Ignoring this notice will void your warranty. EXPLOSION HAZARD! Solvents like Methylene NOTICE Model H8222 Spray Gun 1,1,1-... - Page 12 C. Trigger Pin D. Pattern Control E. Fluid Control Knob F. Air Flow Control Knob Allow the lubricant to coat threads, and run into gun body to lubricate all moving parts and seals. Figure 15. General lubrication points. Model H8222 Spray Gun...
-
Page 13: Troubleshooting
3. Thin material. 1. Increase volume. 2. Reduce inlet air pressure. 3. Increase fluid pressure. 4. Adjust material. 1. Check air supply. 2. Clean gun, remove any obstructions. 3. Open. 4. Refill. 5. Thin to manufacturer's rec- ommendations. Model H8222 Spray Gun... - Page 14 fluid tip. Contaminated 1. Water or oil in the air line. paint: fish eye appearance. Model H8222 Spray Gun Solution 1. Reduce fluid pressure. 2. Keep gun at recommended distance. 3. Slow down and maintain consistent, even parallel stroke.
- Page 15 PH8222046 BARBED HOSE FITTING PH8222047 BARBED FITTING NUT �� �� � �� � �� �� �� � �� �� �� �� �� � � � � � � � � DESCRIPTION O-RING 8.5 X 1.5 S9 Model H8222 Spray Gun...
