- Page 1 PROFESSIONAL LVLP SPRAY GUN MODEL H7666/H7667 INSTRUCTION MANUAL COPYRIGHT © JULY, 2005 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. #PC7425 PRINTED IN CHINA...
-
Page 3: Table Of Contents
Spraying ...11 Atomizing Cap and Fan Adjustments ...13 SECTION 5: ACCESSORIES...14 SECTION 6: MAINTENANCE ...15 Cleaning ...15 Lubrication ...16 Troubleshooting ...17 Notes ...19 Parts Breakdown H7666 ...20 Parts Breakdown H7667 ...21 WARRANTY AND RETURNS ...22 Model H7666/H7667 LVLP Spray Gun... -
Page 4: Section 1: Safety
USE THE RIGHT TOOL. Do not force tool or attachment to do a job for which it was not designed. INFLUENCE ALCOHOL. Model H7666/H7667 LVLP Spray Gun WORKSHOP CHILD UNDER DRUGS... -
Page 5: Safety Instructions For Pneumatic Tools
UNINTENTIONAL STARTING. Do not carry tool with hand on trig- ger and always disconnect from air when not in use. Model H7666/H7667 LVLP Spray Gun 17. DISCONNECT TOOLS before ser- vicing and changing accessories. 18. DO NOT OVERREACH. Keep proper footing/balance at all times. -
Page 6: Additional Safety Instructions For Lvlp Spray Guns
NOT exceed the recommended inlet air pressure. Excessive pres- sure could cause the spray gun to burst or cause other internal equip- ment damage. 14. LOCAL authorities regarding exhaust and waste disposal requirements. Model H7666/H7667 LVLP Spray Gun PRESSURE. LAWS. Consult local... -
Page 7: Section 2: Introduction
Foreword We are proud to offer the Grizzly Model H7666/H7667 LVLP Spray Gun. This spray gun is part of a growing Grizzly fam- ily of fine tools. When used according to the guidelines set forth in this manual, you can expect years of trouble-free, enjoyable operation, and proof of Grizzly’s commit-... -
Page 8: Tool Data Sheet
LESS THAN 10 PSI 600ml 230mm 0.585 kgs. 1.28 lbs. POLISHED METAL/ PLASTIC MEDIUM TO HIGH SOLIDS Model H7666/H7667 LVLP Spray Gun H7667 GRAVITY 1.5mm 3-3.9 CFM 2.0-3.5 BAR 28.8-51 PSI LESS THAN 10 PSI 600ml 230mm 0.618 kgs. 1.35 lbs. -
Page 9: Section 3: Set Up
When you are completely satisfied with the condition of the shipment, you should inventory the equipment. Model H7666/H7667 LVLP Spray Gun Inventory After you have unpacked the carton, you should find the following: Model H7666/H7667 Inventory (Figures 1 &... -
Page 10: Assembly
Trigger: Two stage trigger. Stage one only releases compressed air for blowing off the work piece. Stage two sprays material. Cup: 600ml plastic cup allows easy viewing of material level. Includes a vented cap. Model H7666/H7667 LVLP Spray Gun Pattern Control Fluid Control... -
Page 11: Section 4: Operations
Model H7666/H7667 LVLP Spray Gun Spraying The Model H7666/H7667 LVLP spray gun is designed to spray medium to high solid materials like lacquers, stains, primers, multi-component paints, clear coats, acryl- ics, epoxies etc. - Page 12 Page 15. HEALTH & CONTAMINATION HAZARD! Dispose of paint waste in a responsible manner! Follow manufacturer's recommendations and local laws regarding disposal. Failure to comply will result in con- tamination and possibly large fines and penalties. Model H7666/H7667 LVLP Spray Gun...
-
Page 13: Atomizing Cap And Fan Adjustments
Page 15). Holes Stroke Figure 7. Set up for horizontal stroke direction with vertical fan pattern. Model H7666/H7667 LVLP Spray Gun Stroke Figure 8. Set up for vertical spray stroke with horizontal fan pattern. Rotating the pattern adjustment control in Figure 8 will give you a range between the two patterns in Figure 9. -
Page 14: Section 5: Accessories
H3174—Air Blow Gun with 2 Tips This air blow gun includes a safety tip and rubber tip for all normal air cleaning jobs. ⁄ " NPT. Figure 13. H3174 Air Blow Gun with 2 Model H7666/H7667 LVLP Spray Gun ⁄ " NPT. pressure regulator. Tips. -
Page 15: Section 6: Maintenance
Fluid Tip Needle Atomizing Spring Figure 14. Disassembly for cleaning. Model H7666/H7667 LVLP Spray Gun 5. Unscrew the atomizing cap with your fingers and the fluid tip with the ser- vice wrench. The fully disassembled gun should look like Figure 14. -
Page 16: Lubrication
B. Air Valve Packing C. Trigger Pin D. Air Flow Control Valve E. Pattern Control F. Fluid Control Knob Allow the lubricant to coat threads, and run into gun body to lubricate all moving parts and seals. Model H7666/H7667 LVLP Spray Gun... -
Page 17: Troubleshooting
1. No pressure at gun. 2. Fluid passages dirty. 3. Fluid control closed. 4. Out of paint. 5. Material too thick. Model H7666/H7667 LVLP Spray Gun Troubleshooting Solution 1. Tighten fluid tip or replace seat with new one. 2. Add material. - Page 18 1. Lower inlet air pressure. 2. Keep gun at recommended distance. 3. Slow down and maintain consistent even parallel stroke. 1. Clean or replace both. 1. Install an in-line air filter. 2. Replace air line. Model H7666/H7667 LVLP Spray Gun...
-
Page 19: Notes
Notes Model H7666/H7667 LVLP Spray Gun... -
Page 20: Parts Breakdown H7666
�� �� �� �� �� �� �� �� �� �� � � � � � � � � � �� �� REF PART # Model H7666/H7667 LVLP Spray Gun �� �� �� �� �� DESCRIPTION PH7666021 CUP PH7666022 CUP LID... -
Page 21: Parts Breakdown H7667
PH7667014 NEEDLE SCREW PH7667015 NEEDLE SPRING PH7667016 NEEDLE ADJ. SCREW PH7667017 SWITCH POLE PH7667018 O-RING PH7667019 O-RING PH7667020 NEEDLE SLEEVE PH7667021 O-RING Model H7666/H7667 LVLP Spray Gun �� �� �� �� � � � � � � �� �� ��... -
Page 22: Warranty And Returns
WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance. - Page 23 ____20-29 ____50-59 How long have you been a woodworker/metalworker? ____0-2 Years How many of your machines or tools are Grizzly? ____0-2 Do you think your machine represents a good value? ____Yes Would you recommend Grizzly Industrial to a friend? ____Yes Would you allow us to use your name as a reference for our customers in your area? Note: We never use names more than 3 times.
