Yaesu FP-29 User Manual

Visit http://www.fotango.org
for the FT-1000MP MARK-V HF Transceiver
The FP-29 is an external AC power supply for use with the FT-1000MP MARK-V HF Transceiver, providing 30
Volts DC at up to 15 amperes for extended periods.
Excellent regulation and conservative design assure the owner of many years of trouble-free operation. A ther-
mally-switched cooling fan automatically activates during long periods of high current demand, to maintain a
safe operating temperature in the power supply.

Specifications

DC Output Voltage:
DC Output Current:
Input Voltage:
Current Consumption (Approx.): AC 100-120 V: 9 A, AC 200-240 V: 5 A
Operating Temperature Range:
Case Size ( W x H x D ):
Weight (Approx.):
Specifications are subject to change without notice or obligation.
Supplied Accessory
DC Power Cable: T9022299 (length: 2 meters) ............................................................................................ 1
AC Power Cable.......................................................................................................................................... 1
Operating Manual (this sheet) ..................................................................................................................... 1
Warranty Card ............................................................................................................................................ 1
YAESU MUSEN CO., LTD.
4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan
YAESU U.S.A.
17210 Edwards Rd., Cerritos, CA 90703, U.S.A.
YAESU EUROPE B.V.
P.O. Box 75525 1118 ZN, Schiphol, The Netherlands
YAESU UK LTD.
Unit 12, Sun Valley Business Park, Winnall Close
Winchester, Hampshire, SO23 0LB, U.K.
YAESU GERMANY GmbH
Am Kronberger Hang 2, D-65824 Schwalbach, Germany
YAESU HK LTD.
11th Floor Tsim Sha Tsui Centre, 66 Mody Rd.,
Tsim Sha Tsui East, Kowloon, Hong Kong
E A A 9 7
YAESU FP-29

AC POWER SUPPLY

+30 V , +13.8 V
+30 V: 15A; +13.8 V: 3A
AC 100-120V, 50 - 60 Hz
AC 200-240 V, 50 - 60 Hz
–10 °C ~ +50 °C
106 x 135.5 x 331 mm (4.2 x 5.3 x 13 inch)
3.2 kg (7 lbs)
