Disposal / WEE declaration
Rechargeable Batteries and Batteries
The supplied rechargeable batteries or batteries are recyclable. Please
dispose of them at special waste collection points or your local dealer.
Only dispose of exhausted batteries or rechargeable batteries to ensure
environmental protection.
WEEE-Declaration
Your product is designed and manufactured with materials and
components of high quality, which are recyclable and can be reused.
The symbol means that your product should be disposed of separately
from household waste when it reaches its end of life. Please dispose of
this equipment at your local collection point or recycling center. Please
help to protect the environment in which we all live.
CE
All specifications and appearances are subject to change without
notice. All information was correct at time of printing. Musikhaus Kirstein
GmbH does not guarantee for the accuracy or completeness of any
description, photograph or statement contained in this manual. Printed
colors and specifications may vary slightly from product. Products from
Musikhaus Kirstein GmbH are only sold through authorized dealer.
Distributors and dealers are not agents of Musikhaus Kirstein GmbH
and have no authority to bind Musikhaus Kirstein GmbH legally in any
way. This manual is protected by copyright. Any copying or reprint, even
in excerpts, is only allowed with written consent of Musikhaus Kirstein
GmbH. The same applies to reproduction or copying of images, even in
altered form.
Pronomic PMX-1804FX
00024066
Version 01/2012
Users manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pronomic PMX-1804FX
Summary of Contents for Pronomic PMX-1804FX
- Page 1 Disposal / WEE declaration Rechargeable Batteries and Batteries The supplied rechargeable batteries or batteries are recyclable. Please Pronomic PMX-1804FX dispose of them at special waste collection points or your local dealer. Only dispose of exhausted batteries or rechargeable batteries to ensure environmental protection.
-
Page 2: Important Safety Symbols
PMX Series Mixer IMPORTANT SAFETY SYMBOLS CAUTION Physical RISK OF ELECTRIC SHOCK PMX1204FX DO NOT OPEN Dimensions (H x W x D) 251 x 324 x 89 mm 3.5 kg weight (net) The symbol is used to indicate that some hazardous live terminals are PMX1404FX involved within this apparatus, even under the normal operating conditions, Dimensions (H x W x D) - Page 3 · Ventilation PMX Series Mixer Do not block areas of ventilation opening. Failure to do could result in fire. Always install accordance with the manufacturer's instructions. Aux sends · Type 1/4" T S connector, unbalanced Object and Liquid Entry approx. 20 k Ω Impedance Objects do not fall into and liquids are not spilled into the inside of the apparatus Max.output level...
-
Page 4: Specifications
PMX Series Mixer PMX Series Mixer 5.SPECIFICATIONS TABLE OF CONTENTS Mono inputs Microphone inputs (XENYX Mic Preamp) 1.INTRODUCTION................2 Type XLR, electronically balanced, 1.1 General mixing console functions..............3 discrete input circuit 1.2 The user’ s manual...................3 Mic E.I.N. (20 Hz - 20 kHz) 1.3 Before you get started.................. - Page 5 PMX Series Mixer PMX Series Mixer Balanced use with XLR connectors 1.INTRODUCTION 1=groud / shield Congratulations! In purchasing the MX you have acquired a mixer whose small size belies its 2=hot (+ve) incredible versatility and audio performance. 3=cold (-ve) The MX Series represents a milestone in the development of mixing console technology. With the new microphone preamps including phantom power as an option.
-
Page 6: Installation
PMX Series Mixer PMX Series Mixer This also goes for mixing effects signals with the monitor mix. The main difference is that the mix radio 1.1 general mixing console functions is adjusted using the FX TO MON control. Of course, a signal has to be fed into the ef f ects processor via the FX control in the channel strip for both applications. -
Page 7: Digital Effects Processor
PMX Series Mixer PMX Series Mixer SPEAK OUTPUTS 2.1 Mono channels Min load 4Ω 2.4.3 AMP Output 2.1.1 Microphone and line inputs AMP OUTPUT This speakon socket is for stereo Amp L/R output. It's Each mono input channel offers a balanced microphone used to connect speaker cabinet by speakon NL 4FC. - Page 8 PMX Series Mixer PMX Series Mixer 2.1.3 Aux sends 2.4 Rear view of PMX1204FX/PMX1404FX/PMX1604FX/PMX1804FX Aux sends take signals via a control from one or more 2.4.1 main mix outputs, Alt 3-4 outputs and control room outputs channels and sum these signals to a so-called bus. This POST bus signal is sent to an aux send connector and then MAIN OUTPUTS...
- Page 9 PMX Series Mixer PMX Series Mixer CLIP-LED The PAN control in the channel strip offers a constant power characteristic. This means that The CLIP LED lights up when the input signal is driver too high. In this case, turn down the TRIM the signal is always at a constant level, irrespective of its position in the stereo panorama.
- Page 10 PMX Series Mixer PMX Series Mixer MAIN MIX 2.3 Connector panel and main section The MAIN MIX switch sends the main mix signal to the above-mentioned outputs and to the level metre. Whereas it was useful to trace the signal flow from top to bottom it order to gain an understanding of the channel strips, we now look at the mixing console from left to right.
- Page 11 PMX Series Mixer PMX Series Mixer You can now use the STEREO AUX RETURN MON control to adjust the level of the effects signal routed to the monitor mix. LEFT RIGHT /MONO 2.3.3 Stereo aux return connectors STEREO AUX RETURN 2 (FX) The STEREO AUX RETURN 2 control determines the level of signals fed into the AUX RETURN 2 STEREO AUX RETURN 1 connectors which are routed to the main mix.
