1000 Watt • 2500 Watt • 4500 Watt
PURE SINE WAVE INVERTER
1000 Watt • 2500 Watt • 4500 Watt
ONDULEUR À ONDE SINUSOÏDALE PURE
1000 Watt • 2500 Watt • 4500 Watt
INVERSORES ONDA SINUSOIDAL PURA
Models / Modèles / Modelos: 11240; 11260; 11264
12 Volt DC to 110-120 Volt AC
1000/2500/4500 Watt Continuous Output
2000/5000/9000 Watt High Surge Capacity
De 12 volts CC à 110-120 volts CA
Puissance continue de 1000/2500/4500 watts
Puissance de pointe 2000/5000/9000 watts
De 12 V CC a 110-120 V CA
1000/2500/4500 W Potencia Continua de salida
2000/5000/9000 W Potencia pico
User's Manual
Notice D'utilisation
Manual del Usario
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sunforce Pro Series 11240
Summary of Contents for Sunforce Pro Series 11240
- Page 1 ONDULEUR À ONDE SINUSOÏDALE PURE 1000 Watt • 2500 Watt • 4500 Watt INVERSORES ONDA SINUSOIDAL PURA Models / Modèles / Modelos: 11240; 11260; 11264 12 Volt DC to 110-120 Volt AC 1000/2500/4500 Watt Continuous Output 2000/5000/9000 Watt High Surge Capacity De 12 volts CC à...
-
Page 2: Important Safety Precautions
Thank you for choosing Sunforce Products Pro Series Pure Sine Wave Inverters. Our inverters have been carefully engineered and manufactured to give you a dependable power source. A Pure Sine Wave Inverter converts low voltage, direct current (DC) to 110 volt alternating household current (AC) depending on the model and its rated capacity. - Page 3 State of Charge Specific Gravity Voltage 100% 1.265 12.7 6.3 *75% 1.225 12.4 6.2 1.190 12.2 6.1 1.155 12.0 6.0 Discharged 1.120 11.9 6.0 Working with Inverters • Do not expose the inverter to moisture, including rain, snow, spray mist, or excessive humidity.
-
Page 4: Important Cable Information
Overload temperature Short circuit shutdown Getting Started Before installing and using the Sunforce Products Pro Series Pure Sine Wave Inverter please read all instructions and cautionary markings on the inverter, batteries and all appropriate section of this manual. When you turn on an appliance, or a tool that operates using a motor or a tube (such as a... -
Page 5: Wiring Specifications
In most cases the start up load of the appliance or power tool determines whether your Inverter has the capability to power it. To determine whether the Sunforce Products Pro Series Pure Sine Wave will operate a particular piece of equipment or appliance, it is advisable to run a test. All Pure Sine Wave inverters are designed to automatically shut down in the event of a power overload. - Page 6 AWG Wire Sizes Conductor Conductor AWG gauge Diameter Inches Diameter mm OOOO 0.46 11.684 0.4096 10.40384 0.3648 9.26592 0.3249 8.25246 0.2893 7.34822 0.2576 6.54304 0.2294 5.82676 0.2043 5.18922 0.1819 4.62026 0.162 4.1148 0.1443 3.66522 0.1285 3.2639 0.1144 2.90576 0.1019 2.58826 0.0907 2.30378 0.0808...
- Page 7 Use #0 gauge wire to make the connections to the Inverter, may require a "0 to 4 Gauge Adapter". This adapter is available through most electrical supply stores. Heavy gauge cables sold separately Connections Make sure the ON/OFF Switch located on the front panel of the Inverter is in the OFF (O) position.
- Page 8 Never attempt to operate the Sunforce Products Pro Series Pure Sine Wave Inverter from any power source other than a 12 volt battery. The inverter is not to be used in conjunction with 6 volt or 24 volt batteries.
- Page 9 The remote control is included with your inverter and located on a keychain. To use the remote control the receiver must first be plugged in to the inverter. The receiver box is attached to a cord that can be plugged into a jack on the face of the inverter near the AC Outlets. In the event the remote control is lost, disconnect the Remote Control Receiver from the inverter by unplugging the cord from the jack.
-
Page 10: Troubleshooting
Abnormal Display 1. Over Temperature 2. AC Overload or Shortage 3. Battery Voltage Too Low 4. Battery Voltage Too High 5. Inverter Defective Normal Display Voltage Reading Example Trouble Shooting Trouble Shooting Problem Reason Solution Battery voltage may be low. Recharge or replace battery. -
Page 11: Specifications
LIMITED WARRANTY: This product is covered by a two year limited warranty. Sunforce Products Inc warrants to the original purchaser that this product is functional and free from defects in materials and workmanship for the period of two year from date of purchase.
