- Page 1 Smart Dome Camera User Manual SCP-2250H...
- Page 2 overview CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit.
- Page 3 Continued use in such a condition may cause fire or electric shock. If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this product in any way. (SAMSUNG is not liable for problems caused by unauthorized modifications or attempted repair.) When cleaning, do not spray water directly onto parts of the product.
- Page 4 overview CAUTION Do not drop objects on the product or apply strong blows to it. Keep away from a location subject to excessive vibration or magnetic interference. Do not install in a location subject to high temperature (over 50°C), low temperature (below -10°C), or high humidity.
-
Page 5: Fcc Statement
FCC STATEmENT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : 1) This device may not cause harmful interference, and 2) This device must accept any interference received including interference that may cause undesired operation. -
Page 6: Important Safety Instructions
overview ImPORTANT SAFETy INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 7: Table Of Contents
CONTENTS OvERvIEW important safety instructions contents Features What’s Included At a Glance INSTALLATION & Optional Accessories for CONNECTION Installation Precautions Preparation Installation Initial Setup Connecting With Other Device SETUP How to use the keyboard controller Main Menu Profile Camera Set Intelligent Video Privacy Zone Preset... -
Page 8: Overview
overview FEATURES With the state-of-the-art digital signal processing technology, full digital image processing and special algorithm of 600-line high resolution implemented High performance surveillance camera, equipped with x25 zoom lens and digital zoom IC, enabling monitoring up to 400 times DAY/NIGHT to improve the sensitivity by automatic conversion into the black and ... -
Page 9: At A Glance
AT A GLANCE CAmERA HOOK HOOK LENS FRAmE SET RS-485 ALARM IN POWER INPUT ALARM OUT Wipe out a dirty surface of the lens softly with a lens tissue or cloth to which you have applied ethanol. English _... -
Page 10: Installation & Connection
installation & connection OPTIONAL ACCESSORIES FOR INSTALLATION For your easier installation, you can purchase appropriate optional accessories available. WALL MOUNT ADAPTOR (SCX-300WM) This is a wall mount adaptor, used for wall- mounted installation of SMART DOME CAMEA units. CEILING MOUNT ADAPTOR (SCX-300CM) This is a ceiling mount adaptor, used for installation of SMART DOME CAMEA units on a concrete ceiling. - Page 11 CORNER MOUNT ADAPTOR (SCX-300KM) This is an adaptor for WALL MOUNT ADAPTOR (SCX-300WM) installation on the corner of wall joint. PARAPET (LONG) MOUNT (SCX-300LM) This is a mounting kit used for installation of SMART DOME CAMEA units on a parapet. English _11...
-
Page 12: Preparation
installation & connection PRECAUTIONS Select an installation spot which can endure more than 4 times of the product weight. When installing, prevent peoples approaching to avoid personal injury. Move valuables to a safer place before installing. PREPARATION Run all the external cables through the bracket adaptor’s PIPE or mOUNT hole. Wrap around the HOUSING’s screw hole with the Teflon Tape. - Page 13 INSTALLATION Press the SNAP FIT of the ADAPTOR in the HOUSING to open the ADAPTOR part, and then insert all external cables into the HOUSING. Secure the HOUSING on the PIPE or mOUNT by turning it clockwise. (Secure two components tightly, to avoid loosened HOUSING.) PIPE OR PIPE OR MOUNT...
- Page 14 installation & connection Note that BUSHINGs are provided for outdoor installations where exposed to a moisture condition through the PIPE or mOUNT, install the HOUSING using the BUSHING to prevent moisture entering. - Apply grease of proper dose on the BUSHING before assembling, and run cables through each hole of the bushings.
- Page 15 Tie up the SAFETy WIRE of the CAmERA on the BRACKET WIRE of the FRAmE SET. Arrange the 22P CONNECTOR of the CAmERA in line with that of the ADAPTOR, push the HOOKs on either end of the CAmERA in the RACK direction of the FRAmE SET to secure the two.
-
Page 16: Initial Setup
SW604 (x100) (x10) (x1) Communication Protocol Setup Use pins #1~#4 of SW603 to specify the communication protocol. A : SAMSUNG HALF Pin1 Pin2 Pin3 Pin4 Pin7 comp B : SAMSUNG FULL <Bottom of the camera holder> 1_ installation & connection... -
Page 17: Baud Rate Setup
Baud Rate Setup Use pins #5, #6 of SW603 to set the baud rate. BAUD RATE PIN 5 PIN 6 4800 BPS 9600 BPS 19200 BPS 38400 BPS The factory default is 9600 BPS. Setting RS-422A/RS-485 Termination As it is shown in the structure map, when Controller and RS-422A/RS-485 is connected, it should be terminated according to the Cable feature of impedance on the each end of the transmitting line to transfer the signals in long distance by controlling the reflection of the signals to the lowest. - Page 18 installation & connection n < 32 Termination SW1-ON Controller SW2-ON Termination CAM 1 CAM 2 CAM n-1 CAM n <RS-422A/RS-485 Full Duplex Organization> A communication error may occur if you connect multiple cameras that are assigned the same address in the network. 1_ installation &...
-
Page 19: Connecting With Other Device
CONNECTING WITH OTHER DEvICE MONITOR CONTROLLER/DVR ALARM IN POWER SOURCE ALARM OUT Connecting to a monitor Connect one end of the BNC video cable connector to the Video Output Terminal (VIDEO OUT). Connect the other end of the Video terminal on the connector to the Video Input rear of monitor Terminal of the monitor. - Page 20 installation & connection To connect ALARm IN Connect one end of the external device's signal line to a corresponding ALARM IN port of the monitor. Connect the other end of the signal line to the earth-grounding [GND] port. To connect ALARm OUT Connect one end of the external device's signal line to a corresponding ALARM OUT port of the monitor.
-
Page 21: Power Supply
Connecting the adaptor cable Adaptor Board Power Supply Connect the cables as necessary, and turn on the camera to check if it works properly. Connect the adaptor to the power terminal of the camera. Plug the power cord of the adaptor into the wall outlet. English _1... -
Page 22: Setup
setup Connect the camera to the keyboard controller or DVR, with which you can manipulate and change the settings of the camera. HOW TO USE THE KEyBOARD CONTROLLER Follow the steps below to set the camera menu using the controller. Open the Camera Setup screen. -
Page 23: Main Menu
mAIN mENU This is the first screen you ever see when you turn on the camera where you can set the camera environment to your needs. For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22) PROFILE ... -
Page 24: Profile
setup PROFILE You can select one from the pre-determined configurations as appropriate to your specific camera installation environment. Your selection on each item in PROFILE will affect all other settings of the camera. STANDARD PROFILE Automatically optimizes the camera settings to the normal environment. - Page 25 CAmERA SETUP mENU STANDARD BACKLIGHT DAy/NIGHT GAmING Parent menu Sub-menus MEDIUM MEDIUM MEDIUM MEDIUM MEDIUM AUTO AUTO AUTO NIGHT BURST DAy/NIGHT BURST DAY/NIGHT DAY/NIGHT mODE ATW2 ATW1 ATW1 ATW1 ATW1 BLUE WHITE BAL NIGHT BRIGHTNESS Custom Setting MEDIUM Custom Setting MEDIUM Custom Setting mODE...
-
Page 26: Camera Set
setup CAmERA SET You can configure the general settings of the camera module. For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22) Select <mAIN mENU> - <CAmERA SET>. The Camera Setup menu appears. CAMERA SET ... - Page 27 IRIS The IRIS menu is useful if you set to adjust the intensity of radiation incoming to the camera. [ 00 ] ----I---- LEVEL ALC : Adjust the open and close of the iris. BACKLIGHT - LEVEL : Select an overall brightness level. AREA USER <SIZE>...
- Page 28 setup As long as the DAY/NIGHT menu is set to AUTO in Camera Setup, the AGC menu is not available. As long as FLICKERLESS is set to ON, the FIX mode is not available. mOTION You can specify a level of AGC for controlling the camera motion. This is available only of the SENSE UP menu is set to AUTO.
- Page 29 FLICKERLESS This will prevent possible screen distortion due to a mismatch between the vertical sync frequency and the blinking frequency of the lighting; if set to <ON>, the shutter speed will be fixed to 1/100 second. If SHUTTER is set to FIX, SENSE UP to FIX, and AGC to FIX, the <FLICKERLESS> menu is not available.
- Page 30 setup NIGHT DAY DWELL TIME : Time required to determine the filter switch. MASK AREA : If there exists a bright MASK AREA spot light source in a night scene, you can specify the size and position as <SIZE> <LOCATION>...
-
Page 31: White Bal
WHITE BAL If you need to adjust the color according to the ambient illumination, you can use the <WHITE BAL> function. For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22) Illumination is generally referred to as color temperature, which is represented in a measurement of kelvin (K). - Page 32 setup Select <CAmERA SET> - <WHITE BAL>. Select a mode where you set the <WHITE BAL>. DAY : You can set the RED, and BLUE value in DAY mode. WHITE BAL The screen will be displayed in colors DAY/NIGHT according to your settings.
-
Page 33: Focus Mode
FOCUS mODE You can select a focus mode according to the angle that you adjusted for camera recording. DAY/NIGHT AUTO - AF : This will monitor the screen continuously WHITE BAL to focus automatically. If you adjust the focus FOCUS MODE ZOOM SPEED manually, that will operate the same as in DISPLAY ZOOM... -
Page 34: Digital Zoom
setup DISPLAy P/T You can set to display the operation status of pan/tilt when it is active. It will disappear in about 3 seconds if the pan/tilt position has no further change. However, the allowable error is ± 2°. DIGITAL ZOOm You can set the maximum allowable digital zoom ratio. -
Page 35: Intelligent Video
If more than one PRIVACY ZONE is specified, and PRIVACY SET to <ON>, the PIP function is not available. As long as SENSE UP is set to FIXED, PIP menu is not available. According to the luminance, PIP will disappear if the SENSE UP menu is set to AUTO. DIS (Digital Image Stabilization) If you set it to <ON>... -
Page 36: Alarm Out
setup ADvANCED You can detect motions and mark the video that contains such motion, and enables tracking of the movement. (The auto PTZ function is not supported for tracking an object.) Selecting the <FIxED/mOvED> option will mark a region if an existing object disappears, or a new object appears and fixed for a certain period of time. -
Page 37: Privacy Zone
PRIvACy ZONE You can set up to 12 privacy zones that will be hided for privacy of the subject when recording. Zone Setup For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22) Select <mAIN mENU>-<PRIvACy ZONE>. -
Page 38: Preset
setup PRESET This function provides preset camera settings such as pan, tilt, zoom and focus so to enable quicker and easier accessing and monitoring, which supports up to 512 presets. For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22) Select <mAIN mENU>-<PRESET>. - Page 39 Select <PRESET SPEED> and adjust the pan/tilt speed of the preset. Set the <DWELL TImE> that defines the camera's hold duration and <ImAGE HOLD> of the preset. If you set the <IMAGE HOLD> to <ON>, the video image will be held still until the camera reaches the preset position.
-
Page 40: Auto Set
setup AUTO SET You can set the AUTO PAN, PATTERN, and AUTO PLAY. If you upload/download the menu setting using SSC-1000, 2000 or 5000, the settings for AUTO PAN, PATTERN, SCAN, and PRESET may differ from the menu settings so define them again after the operation. Auto Pan Setup Set the starting and ending positions to patrol between points at specified speed. -
Page 41: Pattern Setup
Select each item and set appropriately. AUTO PAN 1 POSITION : Set the starting and ending positions for the <AUTO PAN>. POSITION DIRECTION LEFT Move to the setting screen and adjust ENDLESS pan/tilt to the desired starting position, [10] SPEED and then press [ENTER]. -
Page 42: Scan Setup
setup Select the <START> and move the PATTERN SET 1 camera using pan/tilt/zoom. <POSITION> Your manual camera actions will be START recorded for up to 2 minutes, and returns to the previous menu automatically. To stop manual recording and return to the previous menu before 2 minutes, press [ENTER]. -
Page 43: Auto Play Setup
Auto Play Setup AUTO PLAY runs configured AUTO PAN, PATTERN, and SCAN functions automatically. For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22) Select <mAIN mENU>-<AUTO SET>. AUTO SET Select the <AUTO PLAy> and select a number. -
Page 44: Zone Set
setup ZONE SET You can set the north direction and the zone coverage. For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22) Select <mAIN mENU>-<ZONE SET>. MAIN MENU PROFILE CAMERA SET INTELLIGENCE PRIVACY ZONE PRESET... -
Page 45: Alarm Set
ALARm SET It provides 8 alarm inputs and 3 alarm outputs. Detects alarm inputs from the external sensors cooperating with configured presets, patterns, and scan functions, and produces alarm outputs. Alarm’s dwell time is defined by the corresponding preset’s <DWELL TImE> and its alarm action. For selecting and saving each menu item, refer to “How to use the keyboard controller”. - Page 46 setup ALARM IN SET : Select the alarm sensor AUTO SET operation between <NO>, <NC> and ALARM1 <OFF>. ALARM2 ALARM3 ALARM OUT SET : Set the alarm out ALARM4 port matched to the alarm input port. ALARM5 ALARM6 AUTO SET : Sets the pattern and scan ...
-
Page 47: Clock Set
CLOCK SET Sets whether to display the clock on the screen and its time format. For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22) Select <mAIN mENU>-<CLOCK SET>. CLOCK SET Select <DISPLAy>... -
Page 48: Factory Defaults
setup Language Select <LANGUAGE> and use the left/right OTHER SET button to select a preferred display language. LANGUAGE ENGLISH FACTORY DEFAULTS OSD COLOR PROPORTIONAL P/T P/T SPEED AUTO CAL. D-FLIP PASSWORD FACTORy DEFAULTS When selected, the <FACTORy DEFAULTS> screen appears and you can reset all settings to the factory default settings by selecting the <OK>. -
Page 49: Communication
Select each item and set appropriately. RS485 PRIORITY : Set the priority by selecting PRIORITY <HW> or <SW>. PROTOCOL SAMSUNG-E When selected <HW>, the protocol, HALF BAUD RATE 9600 baud rate and address settings will ADDRESS follow those settings of the adaptor switch. -
Page 50: System Info
For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 22) Select <mAIN mENU>-<SySTEm INFO>. SYSTEM INFO The current system information is displayed. 4 _ 25PTZ _ NOR _ P TYPE PROTOCOL SAMSUNG-E ADDRESS COMM. TYPE HW, RS485, HALF BAUD RATE 9600 SERIAL NO. 000000000000000 v2.00 _ 100501 CAMERA VER. -
Page 51: Appendix
appendix SHORTCUT KEyS Function DAY/NIGHT - DAY [PRESET] + [5] + [1] + [2] + [ENTER] DAY/NIGHT - NIGHT [PRESET] + [5] + [1] + [3] + [ENTER] DAY/NIGHT - AUTO [PRESET] + [5] + [1] + [4] + [ENTER] DAY/NIGHT - EXT [PRESET] + [5] + [1] + [5] + [ENTER] CAmERA SET... -
Page 52: Specifications
appendix SPECIFICATIONS Item Description SMART DOME CAMERA Product Type AC 24 V (50 Hz) Power Source Use an adaptor over 3A when the heater works. Power Consumption 16.3W(Camera, Fan) / 47W(Heater ON) Tv Standard NTSC / PAL STANDARD COLOR SYSTEM Super-HAD IT CCD Image Sensor PAL-752(H) ×... - Page 53 Item Description PAN range : 360˚Endless Preset Pan Speed : 600˚/sec, maximum Manual Pan Speed : 0.01˚~ 180˚/sec Tilt range : -6˚~186˚ TILT Preset Tilt Speed : 600˚/sec, maximum Manual Tilt Speed : 0.01˚~ 180˚/sec RS485(Half&Full Duplex)/RS422, Remote Control Data on Coaxial Cable Alarm Inputs : 8 IN Alarm Alarm Outputs : 3 OUT (2 Open collector 1 relay)
-
Page 54: Product Appearance
appendix PRODUCT APPEARANCE Ø216mm (Housing Body) Ø228mm (Shield Sun) _ appendix... - Page 55 Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.
- Page 56 TEL : +82-70-7147-8740~60 FAX : +82-31-8018-3745 SAMSUNG TECHWIN AMERICA Inc. SAMSUNG TECHWIN EUROPE LTD. 1480 Charles Willard St, Carson, CA 90746, UNITED STATES Samsung House, 1000 Hillswood Drive, Hillswood Business Park Tol Free : +1-877-213-1222 FAX : +1-310-632-2195 Chertsey, Surrey, UNITED KINGDOM KT16 OPS www.samsungcctvusa.com TEL : +44-1932-45-5300 FAX : +44-1932-45-5325 www.samsungtechwin.com...
